Freedom Scientific RUBY 7 Bedienungsanleitung
440826-001 Rev. B
RUBY®7 HD
Handheld Video Magnifier
User’s Guide
Freedom Scientific, Inc.
www.FreedomScientific.com
ii
Freedom Scientific, Inc., 11800 31st Court North, St. Petersburg, Florida 33716-1805, USA
www.FreedomScientific.com
© 2016 Freedom Scientific, Inc. All Rights Reserved. RUBY®is a registered trademark of Freedom Scientific, Inc. in
the United States and other countries.
Information in this document is subject to change without notice. No part of this publication may be reproduced or
transmitted in any form or any means electronic or mechanical, for any purpose, without the express written
permission of Freedom Scientific.
Visit www.FreedomScientific.com/Forms/ProductRegistration to register your product and validate your
warranty.
iii
Table of Contents
Overview..............................................................................................................................1
Quick Start ..........................................................................................................................3
Hardware Description ........................................................................................................5
Button Descriptions.........................................................................................................7
Charging the Unit / Battery LED Status ............................................................................8
Battery LED Descriptions................................................................................................9
Camera Positions ............................................................................................................. 10
Reading Position...........................................................................................................10
Hobby Position..............................................................................................................11
Distance Position ..........................................................................................................12
Self-view Position..........................................................................................................13
Spotting Position ...........................................................................................................14
General Operation ............................................................................................................15
Changing Magnification.................................................................................................15
iv
Freezing an Image ........................................................................................................16
Saving a Frozen Image .................................................................................................16
Panning Still Images......................................................................................................17
Changing Color Modes..................................................................................................18
Switching Between the Last Used Color Mode and Full Color......................................19
Turning LED Lights Off..................................................................................................20
Using Reading Line or Reading Masks.........................................................................20
Color Modes......................................................................................................................23
Adding and Removing Color Modes..............................................................................24
Restoring Default Color Modes.....................................................................................25
Managing Images ............................................................................................................. 26
Storage Mode................................................................................................................26
Saving and Deleting an Image ......................................................................................26
Viewing Saved Images..................................................................................................27
Saving an Image When Memory is Full.........................................................................27
Storage Mode Icons......................................................................................................28
v
Transferring Images......................................................................................................29
Displaying a Slide Show................................................................................................31
Connecting the Unit to an HDTV or Monitor...................................................................33
Troubleshooting ...............................................................................................................35
Technical Specifications..................................................................................................39
Service and Support.........................................................................................................41
1
Overview
RUBY™7 HD is a lightweight, handheld video magnifier that can magnify an object from two to
24 times its size. It has a 5-megapixel, auto-focus camera that provides sharp HD quality
images that are easily viewed on its full color, 7-inch LCD screen. RUBY 7 HD supports five
default color modes, and 15 additional contrasting color modes that can easily be enabled.
Other features include:
PivotCam™ – a 5-megapixel, auto-focus camera that easily rotates through a wide range
of viewing modes: reading, hobby, distance, self-view, and spotting
Panning button to easily pan horizontally or vertically across a still or saved magnified
Unit can be used to view items up to 15-feet away
Large and easy-to-use buttons
Full size HDMI port that allows connection to HDTVs and HD monitors
Save and store up to 105 images that can easily be copied to a computer through a
simple USB connection
2
Micro-USB port to transfer images between the unit and computer
Multiple LED lights
Reading line and masks to quickly locate and maintain your place while viewing an image
or reading text on the LCD screen
What’s in the Box?
RUBY 7 HD with PivotCam
Power adapter
Micro-USB cable for file transfer
HDMI-HDMI cable for HDTV connection
Microfiber lens cloth
User documentation
Carrying case
3
Quick Start
Below are steps to quickly set up and use RUBY 7 HD for the first time.
1. Make sure the unit is fully charged.
2. Power the unit on by pressing the green/yellow Power button or by opening the
reading stand.
3. Do one of the following:
Hold the unit similar to a tablet to view items both near and far. This is useful when
you want to magnify and read objects such as labels or details on cans, packages, pill
bottles, and more. You can also use this position for self-viewing.
Open the reading stand to place the unit on a flat document such as a newspaper or
magazine, a bill or receipt, a letter, and so on.
Note: When you close the reading stand, the unit automatically powers off. Press the
green/yellow Power button to power the unit on again.
4
4. Adjust the magnification using the yellow Plus or Minus buttons ( or ).
5. Select a color mode ( or ) for contrasting colors that best suit your vision needs.
6. Freeze the image on the LCD screen so that you may take your time reading details
in the image.
7. Pan horizontally or vertically to see more of the magnified image.
8. Save the image or return to live view .
Once you become comfortable using RUBY 7 HD, try the following advanced features.
Turn the LED reading lights on or off to adjust for glare and reflections when viewing
photographs or glossy magazine pages.
Use the reading line or reading masks to help you maintain your place while reading text.
Save, view, and delete images stored on the unit.
For additional storage, you can transfer images from the unit to your computer.
