Freefly M?VI Controller Bedienungsanleitung
P2
Freefly represents the intersection of art and technology. Our team consists of industry leading
specialists all focused on one task—inventing solutions to allow unrestricted camera movement.
Freefly initially created the CineStar line of multi-rotor camera platforms, which allowed smooth,
stable and dynamic low-altitude aerial imagery. After years of research and development in
camera stability, Freefly has created the MōVI stabilized camera gimbal. Our goal with the MōVI
is to empower a new era of stabilized cinematography on a variety of platforms, from handheld
to helicopters and everything in between.
P3
The MōVI Controller is compatible with the MōVI M5, M10, and
M15 running firmware version 3.08 or later.
Download the latest MōVI firmware and update instructions at
www.freeflysystems.com.
See Follow-Focus Integration section for information on wireless
lens control system compatibility.
COMPATABILITY
P4
POWER INPUTS:
External DC Supply or Battery Controller Only (No Monitor), Power Level 4
Controller and Monitor, Max
13.0 V - 20.0 V 0.2A
13.0 V - 20.0 V 3.2A
USB Controller only (No monitor), Power Level 4 4.75 V - 5.25 V 0.4A
POWER OUTPUTS:
12V DC OUTPUT Input 13.0 - 20.0V, Output Current < 3.0A
Max. Current Output
11.4 V - 12.6 V
3.0A
USB 5V OUTPUT Input 13.0 - 20.0V, Output Current < 2.0A
Max. Current Output
4.50 V - 5.25 V
2.0A
MōVI CONTROLLER PHYSICAL:
Weight Including Antenna, Excluding Monitor and Battery Plate 950 g
Dimensions Including Antenna and Joystick, Excluding Monitor and Battery Plate 300mm X 175mm X 120mm
RECIEVER OUTPUTS:
Weight Excluding Wires and Mounting Tape 15 g
Dimensions Excluding Wires, Mounting Tape, Antenna 33mm X 38mm X 15mm
RADIO TRANSMITTER:
Frequency All Channels 2.410 - 2.465 Ghz
Transmission Power Power Level 0 (EU)
Power Level 4
+10 dBm
+1B dBm
Range Power Level 0 (EU), Outdoor Line-of-Sight 1200 ft / 300 m
CONTROLLER SPECIFICATIONS
P5
CONTROLLER SPECIFICATIONS
Any MōVI M5, M10, or M15 can be configured to work with the MōVI Controller.
The MōVI must have firmware version 3.08 or later. The latest MōVI firmware,
release notes, and update instructions are available at www.freeflysystems.com
Once running firmware v3.08 or later, change the MōVI Radio Type from the
default (DSMX 2048) to MōVI Controller. This can be done from any of the
Freefly Configurator apps (PC, Mac, Android) in the Remote Controller Config
menu.
The values of the other parameters in this menu (Map Remote Mode, etc.) do
not matter for this Radio Type and can be left at
their defaults.
After installing the MōVI Controller Reciever (see Reciever Installation section
below, or the Quick Start Guide included in the package) and configuring the
MōVI Radio Type as above, the MōVI Controller is ready to send commands and
recieve data from the MōVI. As the Spektrum DX7/DX8 remote controller, the
feel of the joystick can be adjusted from the Remote Operator Config menu.
P6
MōVI CONTROLLER LAYOUT
MōVI CONTROLLER // FULL CONTROLL AT YOUR FINGERS
12V DC Output
(2-Pin LEMO)
Pan
Speed
Tilt
Speed
Roll
Speed
Zoom
Speed
Power
Switch
User 3
Switch Tilt Direction Mode
Record
Start/Stop
Menu Select
Knob Menu Set
Knob
User 1
Knob
User 2
Knob
Neck Strap
Eyelet
Roll Trim
Buttons
Focus Knob Pan/Tilt
Joystick
Iris Knob
Zoom
Rocker
Dual Operator
Majestic Mode
Kill
13-20V DC Input
2x USB Ports
2.4 Ghz
Antenna
Monitor Mount / Tripod Mount
Tripod Mount
Menu Display
Auxiliary Data Port
(7-Pin LEMO)
P7
RECEIVER LAYOUT
2.4 Ghz Antenna
Channel Switch Bind Button
Firmware Update (FW) Button
5-Pin MōVI Data Port
3-Pin Spektrum Remote Port
Shutter/Record Output Port
Status LED
P8
RECEIVER SPEKTRUM / RECORD OUTPUT PORT
3-pin JST ZH
ZHR-3
1 - 3.3V Input
2 - GNO
3 - Shutter/Record of Spektrum Date Out
(3.3V digital output)
RECEIVER DATA PORT
5-pin JST ZH
ZHR-5
1 - GND
2 - 5V Input
3 - Data In (3.3V digital input, 5V tolerant)
4 - Data Out (3.3V digital output)
5 - GPIO1
RECEIVER DATA PORT
7-pin LEMO
FGG.08.307.CLAD52
1 - GND
2 - 5V Output, 1A max.
3 - GPI01 (0.0V - 3.3V)
4 - GPI02 (0.0V - 3.3V)
5 - GPIO3 (0.0V - 3.3V)
6 - Auxillary Data Out (3.3V digital output)
7 - Auxillary Data In (3.3V digital input, 5V tolerent)
CONNECTORS AND PINOUTS
13-20V DC INPUT
5.5mm 0D
2.1mm ID Barrell Jack Connector
Center Positive
e.g. CUI Inc PP3-002A
12V DC OUTPUT
2-pin LEMO
FGG.08.302.CLAD52
(LOOKING IN TO RECEIVER SIDE CONNECTER)
(LOOKING IN TO CONTROLLER SIDE CONNECTER)
(LOOKING IN TO CONTROLLER
SIDE CONNECTER)
12V DC OUTPUT, 3A MAX
GNO
307
307
TYPE
TYPE
(LOOKING IN TO RECEIVER SIDE CONNECTER)
12345
123
1
7
2
4
3
1
2
P9
DISPLAY LAYOUT
HOME ICON Return to the Home menu at any time by scrolling (with the Menu Select knob) to and clicking on the Home
icon in the top left corner of the display.
MENU TITLE The title of the currently active menu is displayed here.
MoVI Status
Booting
Error
Connected
When connected to a MōVI, this icon will display the MōVI Status:
The MōVI is starting up. Keep the camera stationary while this icon is displayed for the IMU to properly initilize.
The MōVI is connected, but an error has occured. Check the MōVI Monitor menu for more information on the error, or try
restarting the MōVI.
The MōVI is connected and running, and the MōVI Controller is receiving live telemetry.
GPS STATUS When the MōVI acquires GPS lock, the GPS icon () is displayed and the GPS-based acceleration compensation
(to minimize horizon drift during high-acceleration movement) is active.
MōVI BATTERY LEVEL The state of charge of the MōVI battery. Check the MōVI Monitor menu for the exact battery voltage.
1
1 1
2
2 2
3
3 3
4
4 4
5
5 5
HOME SCREEN TYPICAL MENU SCREEN
6 6
8 8
9 9
107
P10
DISPLAY LAYOUT
TRANSMITTER
BATTERY LEVEL
The state of charge of the MoVI Controller battery. See Power section for details on what batteries can be used with the MōVI
Controller.
MENU DESCRIPTION A brief description of each menu accessible from the Home menu.
MENU LIST A list of menu items. The highest-level menus appear on the Home menu. Individual menu items appear within their respective
menu. Scroll through and select a menu item using the Menu SelectKnob.
SCROLL BAR The scroll bar always appears on the left side of the display and shows the current scroll position, indicating if there are more
menu items above or below the ones currently displayed.
MENU ITEM DETAILS
Within a menu, details for each menu item are shown on the right side of the display. These include status indicators and
bar graphs for menu items that are read-only and adjustable values or options for menu items that can be modified. Use the
Menu Select Knob to change values or select options where applicable. Refer to the individual menu descriptions in the Menu
Structure section for details on each menu item.
6
7
8
9
10
HOME SCREEN TYPICAL MENU SCREEN
1 1
2 2
3 34 45 5
6 6
8 8
9 9
107
