Freestyle Nomad Bedienungsanleitung

S4 S1

S3 S2

FEATURES:

• 30metersH2O

• Day/date/calendar

• Compasswithdegreesanddirection

• Barometerwithpressuretrend

• Altimeterwithcumulativeascentand

 descent

• 99lapmemorychronograph

• Countdowntimer

•5Alarms

•ELbacklight

CONTROL BUTTONS

S1–Start/splitButton

S2–Stop/resetButton

S3–ModeButton

S4–Light/adjustButton

ENGLISH

NOMAD

DISPLAY MODES

Thewatchhaseightdisplaymodes:TIME,COMPASS

(COMP),ALTIMETER(ALTI),BAROMETER(BARO),CHRO-

NOGRAPH(CHRO),TIMER,ALARMandTEMPERATURE(TE

OPENING SCREEN FOR EACH MODE

Tochangefromonedisplaymodetoanother,pressS3

buttononce.Themodedescriptionwillappearforaround2

secondsbeforetheselectedmodeisactivated.

TO USE THE BACKLIGHT

PressS4buttontoturnonthebacklightfor3-5seconds.

OTHERS

Inanysetting/viewingmode,ifthereisnokeymanipulation

foraround1-2minutes,thewatchwillautomaticallysave

theentereddataandexitthesetting/viewingmode.

TO SET THE TIME AND CALENDAR



Sea level

pressure trend

Time

Day

Month

Date & Year

1.PressS3buttontoselectTIMEmode.

2.PressS4buttonforaround3seconds.Themessage

 “Set-Time”willbedisplayed.

3.PressS3buttononce,thehourdigitswillblink.

4.PressS1/S2buttontosetthehourdigits.Holdingdown

 thebuttonwillspeeduptheprocess.

5.PressS3buttononce,theminutedigitswillblink.

6.PressS1/S2buttontosettheminutedigits.

7.Followthesamepatterntosetthesecond,year,month,

 dateandhourformat.

8.Tosettheseconddigits,pressS1/S2buttontoresetthe

 seconddigitsto00.

9.Tosetthehourformat,pressS1/S2buttontotoggle

 between12-hourand24-hourformat.TheP.M.

 indicatormaybedisplayedtoindicatethetimeperiod

 12:00A.M.–11:59P.M.in12-hourformat.

10.Afternishmakingallthesettings,pressS4buttonto

 conrm.

TO SET NIGHT, CHIME AND BEEP

1.InTIMEmode,pressS4buttonforaround3seconds.

 Themessage“Set-Time”willbedisplayed.

2.PressS1/S2buttontoselectoptionmode.Themessage

 “OPTION”willbedisplayed.

3.PressS3buttoncontinuouslytoselectamongNIGHT,

 CHIMEorBEEPmode.

4.PressS1/S2buttontoactivateordeactivateeachmode.

5.Afternishmakingallthesettings,pressS4buttonto

 conrm.

NOTE:WhenNIGHTmodeisactivated,theNIGHTmode

icon willappear.Thebacklightwillturnonfor3-5sec-

ondswhenanybuttonispressed.NIGHTmodewillturnoff

automaticallyafter8hours.

TO SHOW DUALTIME (T1 OR T2)

1.InTIMEmode,pressandholdS2buttontoviewT1orT2

 timezone.

2.PressandholdS2buttonforaround4secondstoswich

 todisplayT1orT2timezone.

3.FollowthesamepatterntotogglebetweendisplayingT1

 andT2timezones.

TO SHOW CALENDAR OR TEMPERATURE

1.InTIMEmode,pressandholdS1buttontoviewcalendar

 ortemperature.

2.PressandholdS1buttonfor4secondstoswitchto

 displaycalendarortemperature.

3.Followthesamepatterntotogglebetweentemperature

 andcalendardisplays.



TO USE THE COMPASS

ThismovingdotrepresentsthedirectionofNorth(N).



Direction

Degree (0º to 360º)

Time

1.PressS3buttontoselectCOMPASSmode.Thedirection,

 degreeandtimewillbedisplayed.

NOTE:InCOMPASSmode,ifthereisnokeymanipulation

foraround30seconds,thecompasssensorwillbedeacti-

vatedforpowersaving.PressS1/S2/S4buttontore-activate

thecompasssensor.Ifthecompasssensorisdeactivated

foraround10minutes,thewatchwillautomaticallyreturn

toTIMEmode.

NOTE:Ifthecompassdoesnotseemtoworkwell,for

example:whenitdisplaysthewrongcompassdirectionor

itdisplays“DISTORT”onthescreen,thenyouhavetocali-

bratethecompass.Youshouldalsocalibrateitafterreplac-

ingthebattery.Ifyourwatchhasbeenexposedtostrong

electromagneticelds,suchaselectriclines,magnetsor

loudspeakers,thenyouhavetocalibrateitagain.

Calibratethecompassbeforeusingitforthersttimeand

beforealongtrip.

Becauseofthedifferencebetweentruenorthandmagnetic

north,youhavetocompensateitbyadjustingthecompass

declination.Thedeclinationangleforyourlocalareamay

befoundbelow:

City  Declination

   Angle

  

Anchorage 22E

Atlanta 4W

Bombay 1W

Boston 16W

Calgary 18E

Chicago 3W

Denver 10E

Jerusalem 3E

London 4W

LittleRock 3E

Livingston,MT 14E

Munich 1E

NewYorkCity 14W

Orlando 5W

Oslo 2W

Paris 2W

RioDeJaneiro 21W

SanFrancisco 15E

Seattle 19E

Shanghai 5W

Toronto 11W

Vancouver 20E

WashingtonDC 10W

Waterbury,CT 14W

TO SET THE DECLINATION ANGLE

1.InCOMPASSmode,pressandholdS4buttonforaround

 3seconds.Themessage“CALIB”willbedisplayed.

2.PressS1/S2buttontoselectdeclinationanglesetting

 mode.Themessage“DECLIN”willbedisplayed.

3.PressS3button,Ewillblink.

4.PressS1/S2buttontotogglebetweenE(East)&W(West).

5.PressS3button.Thedeclinationanglewillblink.

6.PressS1/S2tosetthedegreefrom0˚to90˚.

7.Afternishmakingallthesettings,pressS4buttonto

 returntoCOMPASSmode.

TO CALIBRATE THE COMPASS

1.InCOMPASSmode,pressandholdS4foraround3

 seconds.Themessage“CALIB”willbedisplayed.

2.PressS3buttontostartthecalibration.

3.Whenthemessage“2-TURN”isdisplayed,aseriesof

 movingdotswillbedisplayedattherimofthedisplay

 andincreaseinclockwisedirection.Rotatethewatch

 horizontallyincounter-clockwisedirectioninorderto

 freezethelastmovingblinkingdottostayat12-hour

 position.

4.Whenthewatchisrotatedcompletelyfor360degrees,

 themessage“1-TURN”willbedisplayed.Rotatethe

 watchagainincounter-clockwisedirection.

5.Tointerruptandstopthecalibration, 

 pressS4button.Themessage“DISTORT”willbedis

 playedandthewatchwillreturntoCOMPASS 

 modeafter3seconds.

6.Whenthecalibrationisdone,themessage“DONE”will

 bedisplayedandthewatchwillreturntoCOMPASS

 modeafter2seconds.

TO TAKE A NEW “MARK ANGLE”

InCOMPASSmode,Youmustmoveyourwatchhorizontally

untilthechosendegreeisdisplayed,thenpressS1button

totakea“markangle”.Anewmarkwillblinktoindicate

themarkeddirectionandanew“markangle”(indegree)

willbedisplayed.

1.PressS1buttontotakeanother“markangle”.

2.PressS2buttontoreturntoCOMPASSmode.

NOTE:Markanglehelpsyoutofollowacertaindirectionor

degree.Themarkanglealwaysremembersthelastdirec-

tionordegreeselected.Thedefaultmarkangleis0°.

TO SHOW THE LAST “MARK ANGLE” OR TIME

1.InCOMPASSmode,pressS2buttontodisplaytodisplay

 thepreviousmarkangle”.Amarkwillblinktoindicate

 thepreviouslymarkeddirectionandtheprevious“mark

 angle”(indegree)willbedisplayed.

2.PressS2buttonagaintoreturntoCOMPASSmode.

TO USE THE ALTIMETER



Altitude (bar chart)

Time

Altitude

(current value

=197Ft)

1.PressS3buttontoselectALTIMETERmode.

2.Thelatestaltitudewillbedisplayedinnumericand

 graphicformats.

NOTE:Altitudeismeasuredbyusinganairpressure

sensor.Airpressurechangesconstantlyduetovarying

weatherconditions.Therefore,measuredaltitudesinthe

samepositionmayvary.Pressurevariationsduetoweather

conditions,orindoorair-conditioning,mayaffectaltitude

readings.Calibratethealtimeteratregularintervalsto

makesureitremainsaccurate.

NOTE:Thepressuresensorrangeis:(-1600Ft)to(29,500Ft)

or(-500M)to(9,000M).

USEFULDEFINITIONS:

ASCENT:

ThecumulativeascentsincetheAltitudeDatawascleared.

DESCENT:

ThecumulativedescentsincetheAltitudeDatawascleared.

DIFFER:

Itdisplaysthedifferenceinaltitudesincethelastresetof

thefunction.

RATE:

Itdisplaystheascent/descentrateintheselectedunit,it

willupdatethevalue1timeperminute.

LOGDATE:

ItdisplaysthetimeanddateatlasttimeAltitudeDatawas

cleared.

HIGHEST:

Thehighestaltitude,timeanddatesincetheAltitudeData

wascleared.

LOWEST

Thelowestaltitude,timeanddatesincetheAltitudeData

wascleared.

TO SET UP THE ALTIMETER

1.InALTIMETERmode,pressandholdS4buttonforaround

 1second.Themessage“SET-ALTI”willbedisplayed.

2.PressS1/S2buttontoselectamongaltitudesetting
