Fridgemaster MC55210S Bedienungsanleitung

MC55210S

MC55210

Contents

Safety and warning information_ __ _ _ _ _

Using your appliance_ _ _ _ __ _ _ _ _ _ _ _

Cleaning and Care _ _ _ _ _ _ _ _ _ _ _ _ _

Troubleshooting ___________

Disposal of the appliance_ _ _ _ _ _ _ _ _ _

Description of the appliance _ _ _ _ _ _ _ _

Operation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Helpful hints and tips__ _ _ _ _ _ _ _ _ _ _ _

For your safety and correct

usage before installing and

first using the appliance, read

this user manual carefully,

including its hints and

warnings. To avoid

unnecessary mistakes and

accidents, it is important to

make sure that all people

using the appliance are

thoroughly familiar with its

operation and safety

features. Save these

instructions and be sure that

they remain with the

appliance if it is moved or

sold, so that a using it

its life will be

properly informed on

appliance usage and

safety.

For the safety of life and

property, keep the

precautions of these user's

throughout

its

correct

instructions as the

manufacturer is not

responsible for damages

caused by omission.

This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance shall not be

made by children without

supervision.

Keep all packaging away

Safety for children and others

who are vulnerable people

This appliance is in accordance with the following EU guidelines: LVD 2014/35/EU

and EMC 2014/30/EU and 2009/125/EC and EC.643/2009 and 2002/96/EC

Installing your new appliance_ _ _ _ _ _ _ _ 7

from children as there is risk

of suffocation.

If you are discarding the

appliance, pull the plug out of

the socket, cut the

connection cable (as close to

the appliance as you can)

and remove the door to

prevent children playing from

suffering an electric shock or

from closing themselves

inside it.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you discard

the old appliance. This will

prevent it from becoming a

death trap for a child

General safety

This

appliance is intended

WARNING —

to be used in household

and similar applications

such as

-staff kitchen areas in

shops, offices and other

working environments;

-farm houses and by clients

in hotels, motels and other

residential type

environments;

-bed and breakfast type

environments;

-catering and similar non-

retail applications

WARNING — Do not store

explosive substances such

as aerosol cans with a

flammable propellant in

this appliance.

WARNING — If the supply

cord is damaged, it must be

replaced by the

manufacturer, its service

agent or similarly qualified

persons in order to avoid a

hazard.

WARNING — Keep

ventilation openings, in the

appliance enclosure or in

the built-in structure, clear

of obstruction.

WARNING — Do not use

mechanical devices or

other means to accelerate

the defrosting process,

other than those

recommended by the

manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances inside

the food storage

compartments of the

appliance, unless they are

of the type recommended

by the manufacturer.

WARNING — The

refrigerant and insulation

2. Make sure that the power

plug is not or

damaged. A or

damaged power plug may

overheat and cause a fire.

3. Make sure that you can

plug of the

appliance.

4. Do not pull the main

cable.

5. If the power plug socket

is loose, do not insert the

power plug. There is a risk

of electric shock or fire.

6.You must not operate the

The power cord must not

be lengthened.

crushed

access the main

Electrical safety

blowing gas are

flammable. When

disposing of the appliance,

do so only at an authorized

waste disposal centre. Do

not expose to flame.

The refrigerant isobutene

(R600a) is contained within

the refrigerant circuit of the

appliance, a natural gas

with a high level of

environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the

appliance, ensure that

none of the components of

the refrigerant circuit

becomes damaged.

The refrigerant (R600a) is

flammable.

Refrigerant

-Thoroughly ventilate the

room in which the

appliance is situated.

It is dangerous to alter the

specifications or modify

this product in any way.

Any damage to the cord

may cause a shortcircuit,

fire, and/or electric shock.

If the refrigerant circuit

should be damaged:

-Avoid opening flames and

sources of ignition.

Caution:risk of fire/flammable

appliance without the interior

lighting lamp cover.

7.The fridge is only applied

with power supply of single

phase alternating current of

220~240V/50Hz. If fluctuation

of voltage in the district of

user is so large that the

voltage exceeds the above

scope, for safety sake, be

sure to apply A.C. Automatic

voltage regulator of more

than 350W to the fridge. The

fridge must employ a special

power socket instead of

common one with other

electric appliances. Its plug

must match the socket with

ground wire.

Do not store flammable

gass or liquids in the

appliance,There is a risk

of an explosion.

Do not operate any

electrical appliances

inthe

appliance(e.g.electric ice

cream makers,mixers

etc.).

When unplugging always

pull the plug from the

mains socket,do not pull

on the cable.

Do not place hot items

Daily use

near the plastic

components of this

appliance.

Store pre-packed frozen

food in accordance with the

frozen food manufacture’s

instructions.

The appliances

manufactures storage

recommendations should

be strictly adhered to.Refer

to relevant instructions for

Do not place carbonated of

fizzy drinks in the freeze

compartment as it creates

pressure on the

container,which may cause

it to explode,resulting in

damage to the appliance.

Keep buring candles,lamps

and other items with naked

flames away from the

appliance so that do not set

the appliance on fire.

The appliance is intended

for keeping food stuff

and/or beverages in

normal household as

explained in this

instruction booklet.

storage.

Frozen food can cause

frost burns if consumed

straight from the freezer

compartment.

Do not place the appliance

in direct sunlight.

For electrical connection

carefully, follow the

instructions given in this

manual.

Unpack the appliance and

check if there are damages

on it. Do not connect the

It is advisable to wait at least

four hours before connecting

the appliance to allow the oil

to flow back in the

appliance if it is damaged.

Report possible damages

immediately to the place you

bought it. In this case retain

packing.

compressor.

The appliance is

heavy.Care should be

taken when moving it.

Do not remove nor touch

items from the freezer

comartment if your hands

are damp/wet,as this could

cause skin abrasions or

frost/freezer burns.

Never use the base,

drawers, doors etc. to

stand on or as supports.

Never transport the

appliance in a horizontal

position, because the oil in

the compressor may

flow into the refrigerant

circuit.

Frozen food must not be

refrozen once it has been

thawed out.

Do not consume ice

popsicles or ice cubes

straight from the freezer as

this can cause freezer burn

to the mouth

and lips.

To avoid items falling and

causing injury or damage

to the appliance, do not

overload the door racks or

put too much food in the

crisper drawers.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils, organic

solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Installation Important!

caution!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

Adequate air circulation

should be around the

appliance, lacking this leads

to overheating. To achieve

sufficient ventilation, follow

the instructions relevant to

installation.

Wherever possible the back

of the product should be

against a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation.

The appliance must not be

locate close to radiators or

cookers.

Service

Any electrical work required

to do the servicing of the

appliance should be carried

out by qualified electrician or

competent person.

This product must be

serviced by an authorized

Service Center, and only

genuine spare parts must be

used.

1)If the appliance is Frost

Free.

2)If the appliance contains

freezer compartment.

Make sure that the mains

plug is accessible after the

installation of the appliance.

671

1057

931

135

Description of the appliance

View of the appliance

1.Lamp switch

3.Storage shelf.

4.Crisper box Cover

5.Crisper box

9.Upper door shelf

10.Lower door shelf

11.Ice tray

12.Door gasket

13.Adjustable feet

.Temperature regulator

Upper freezer drawer

Middle freezer drawer

Lower freezer drawer

To get more space in the freezer, you can remove drawers(except the bottom drawer

in freezer!)

()

Operation

Starting up and temperature regulation

The temperature selector knob is located

on the top of the refrigerator compartment.

Setting 0 means:

Setting 1 means:

Setting 7 (end-stop) means:

Off.

Clockwise rotate the knob to turn on the

appliance

Highest temperature, warmest setting.

Lowest temperature, coldest setting.

Turning the temperature control to “0"

position stops the cooling cycle, but does not

shut off the power to the refrigerator.

Turning clockwise in direction refrigerating

unit on, the latter then operating

automatically. If the unit is unplugged, power

lost, or turned off, you must wait 3 to 5

minuters before restarting the unit. If you

aattempt to restart before this time delay, the

refrigerator will not start.

Insert the plug of the connection lead into

the plug socket with protective earth

contact. When the refrigerator

compartment door is opened, the internal

lighting is switched on.

Important!

Reason:

Normally we advise you select

setting of 2 or 3 or 4, if you want the

temperature higher or colder please turn the

knob to warmer or colder setting accordingly.

When you turn the knob to er which can

lead to the more energy efficiency.

Otherwise, it would result the energy-

consuming.

High ambient temperatures (e.g.

on hot summer days) and a cold setting

(position 6 to 7) may cause the compressor

to run continuously or even non-stop!

when the ambient temperature is

high, the compressor must run continuously

to maintain the low temperature in the

appliance

cold

Then remove the controller box.

Temperature regulator

Sketch map

Operation

Remove the crisper box cover and the

crisper box

Warning: Don’t force removal the crisper cover

and crisper box, avoid the refrigerator being

damaged.

To remove the crisper box and the crisper box,

the below steps can be followed:

Pull the crisper until remove it. raise the

inside of the crisper box, then pull the

crisper box outward.

Remove the freezer drawer

Pull the freezer drawer until meet the limit

block, raise it and get out.

Remove and install the door shelf

Remove the door shelf

press inwardly

Install the door shelf

Firstly tilt the left side of the door

shelf ,and make sure the notch has

been fastened to the door .Then

press the right side inwardly ,push

it down to the right place.

Press the right side of the door shelf

inwardly ,while holding the left side .

When the notch of the shelf has been

detachesd from the refrigerator door ,

remove the rack obliquely upwardly .

Warning:The door shelf must not removed

and installed by the user! If the door shelf

is damaged ,contact the customer helpline

for assistance .To replace the door shelf,

the below steps can be followed:

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Fridgemaster Kühlschrank Handbücher

Fridgemaster

Fridgemaster MS83430BFF Bedienungsanleitung

Fridgemaster

Fridgemaster MBUR60121MF Bedienungsanleitung

Fridgemaster

Fridgemaster MTL55250 Betriebsanleitung

Fridgemaster

Fridgemaster MBUL60133 Bedienungsanleitung

Fridgemaster

Fridgemaster MS91518FFS Betriebsanleitung

Fridgemaster

Fridgemaster MUR49100 Bedienungsanleitung

Fridgemaster

Fridgemaster MBC54260F Technisches Handbuch

Fridgemaster

Fridgemaster MC55274DF/SA Betriebsanleitung

Fridgemaster

Fridgemaster MC50165F Betriebsanleitung

Fridgemaster

Fridgemaster MC55251MB Bedienungsanleitung

Fridgemaster

Fridgemaster MS91515DFF Betriebsanleitung

Fridgemaster

Fridgemaster MTL55242 Betriebsanleitung

Fridgemaster

Fridgemaster MUL4892E Bedienungsanleitung

Fridgemaster

Fridgemaster MTRR 108A Betriebsanleitung

Fridgemaster

Fridgemaster MC60283DFFB Bedienungsanleitung

Fridgemaster

Fridgemaster MUL55137 Bedienungsanleitung

Fridgemaster

Fridgemaster MTL55249 Bedienungsanleitung

Fridgemaster

Fridgemaster MUL4892MF Betriebsanleitung

Fridgemaster

Fridgemaster MUL49102 Bedienungsanleitung

Fridgemaster

Fridgemaster MC55196 Bedienungsanleitung

Fridgemaster

Fridgemaster MTM48120R Bedienungsanleitung

Fridgemaster

Fridgemaster MTRR102A Bedienungsanleitung

Fridgemaster

Fridgemaster MC55174FF Bedienungsanleitung

Fridgemaster

Fridgemaster MTTR4442 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
