Friedrich PTAC ZONEAIRE PREMIER Leitfaden

1 PB

Service/ Parts Manual

PTAC

ZONEAIRE® PREMIER

Standard Chassis Models

7K PDE07K3SG, PDE07R3SG

PDH07K3SG, PDH07R3SG

PDE12K3SG, PDE12R3SG

PDH12K3SG, PDH12R3SG

12K

94141400_01

PDE09K3SG, PDE09R3SG

PDH09K3SG, PDH09R3SG

15K PDE15K5SG, PDE15R5SG

PDH15K5SG, PDH15R5SG

2 PB

INTRODUCTION 4

Important Safety Information 4

Personal Injury Or Death Hazards 5

Operation of Equipment in During Construction 7

Model Number Reference Guide 8

Serial Number Reference Guide 9

SPECIFICATIONS 10

General Specications 7-9k Electric Heat 10

General Specications 7-9k Heat Pump Models 11

General Specications 12-15k Electric Heat 12

General Specications 12-15k Heat Pump 13

Electrical Data 15

OPERATION 17

Function and Control 17

Dip Switch Function #1 21

Dip Switch Function #2 22

Dip Switch Function #3&4 23

Dip Switch Function #5&6 24

Dip Switch Function #7 25

Refrigeration Sequence Of Operation 26

Refrigerant System Diagram 27

Routine Maintenance 28

REMOVAL PROCEDURE 29

Remove The Chassis 29

Remove The Chassis 31

UNIT DISASSEMBLY 39

Indoor Motor, Wheel, & Heating Element Assembly 39

Outdoor Motor, Blade, & Shroud Assembly 48

Electronic Board & Electrical Component Replacement 50

INSTALLATION 60

PTAC Installation Recommendations 60

Wall Sleeve Installation Instructions (PDXWS) 61

Alternate Wall Installations 62

PXDR10 Drain Kit Installation 65

External Drain 66

PXGA Standard Grille 67

Electrical Wiring for 265 Volt Models 68

Chassis Install Preparation 70

Chassis Installation 72

How To Connect 73

Thermostat 74

Final Inspection & Start-up Checklist 76

R-410A SEALED SYSTEM REPAIR 77

Refrigerant Charging 78

Undercharged Refrigerant Systems 79

Overcharged Refrigerant Systems 80

Restricted Refrigerant System 81

Sealed System Method of Charging/ Repairs 82

COMPONENT TESTING 83

Hermetic Components Check 83

Reversing Valve Description And Operation 84

Testing The Reversing Valve Solenoid Coil 85

Checking The Reversing Valve 86

Touch Test Chart : To Service Reversing Valves 88

Compressor Checks 89

Compressor Replacement -Special Procedure in Case of Compressor Burnout 92

PCB Printed Diagram Board 1 93

PCB Printed Diagram Board 2 94

Testing Component Voltage at Electronic Control Board 95

TABLE OF CONTENTS

3PB

Testing Line Voltage 96

TROUBLESHOOTING 97

Basic Troubleshooting 97

Error Codes 99

Malfunction of Temperature Sensor 102

Maintenance Method for Normal Malfunction 103

WIRING DIAGRAMS 106

PDE07 106

PDH07 107

PDE09, PDE12, PDE15 108

PDH09, PDH12, PDH15 109

PARTS CATALOG 110

PDE07K, PDE07R, PDE09K, PDE09R, PDE12K, PDE12R, PDE15K, PDE15R 111

PDH07K, PDH07R, PDH09K, PDH09R, PDH12K, PDH12R, PDH15K, PDH15R 117

ACCESSORIES 123

APPENDIX 125

Reference Sheet of Celsius and Fahrenheit 125

Resistance Table of Indoor Ambient Temperature Sensor (15K) 126

Resistance Table of Tube Temperature Sensors for Indoor and Outdoor(20K) 127

Resistance Table of Discharge Temperature Sensor for Outdoor(50K) 128

WARRANTY 129

FRIEDRICH AUTHORIZED PARTS DEPOTS 130

TABLE OF CONTENTS

4 PB

Your safety and the safety of others is very

important.

We have provided many important safety messages in this manual and on your appliance. Always

read and obey all safety messages.

This is a safety Alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you

and others.All safety messages will follow the safety alert symbol with

the word “WARNING”or “CAUTION”. These words mean:

Indicates a hazard which, if not avoided, can result in severe personal

injury or death and damage to product or other property.

Indicates a hazard which, if not avoided, can result in personal injury

and damage to product or other property.

All safety messages will tell you what the potential hazard is, tell you

how to reduce the chance of injury, and tell you what will happen if

the instructions are not followed.

Indicates property damage can occur if instructions are not followed.

WARNING

Refrigeration system

under high pressure

Do not puncture, heat, expose to ame or

incinerate.

Only certied refrigeration technicians

should service this equipment.

R410A systems operate at higher pressures

than R22 equipment. Appropriate safe ser-

vice and handling practices must be used.

Only use gauge sets designed for use with

R410A.

Do not use standard R22 gauge sets.

NOTICE

CAUTION

WARNING

The information in this manual is intended for use by a qualied technician who is familiar with the safety procedures

required for installation and repair, and who is equipped with the proper tools and test instruments required to

service this product.

Installation or repairs made by unqualied persons can result in subjecting the unqualied person making such

repairs as well as the persons being served by the equipment to hazards resulting in injury or electrical shock

which can be serious or even fatal.

Safety warnings have been placed throughout this manual to alert you to potential hazards that may be encountered.

If you install or perform service on equipment, it is your responsibility to read and obey these warnings to guard

against any bodily injury or property damage which may result to you or others.

Important Safety Information

INTRODUCTION

5 PB

SAFETY

FIRST

WARNING AVERTISSEMENT ADVERTENCIA

Do not remove, disable

or bypass this unit’s

safety devices. Doing so

may cause re, Doing so

may cause re, injuries,

or death.

Ne pas supprime, désacti-

ver ou contourner cette

l´unité des dispositifs de

sécurité, faire vous risque-

riez de provoquer le feu, les

blessures ou la mort.

No eliminar, desactivar o

pasar por alto los dispositi-

vos de seguridad de la

unidad. Si lo hace podría

producirse fuego, lesiones

o muerte.

ELECTRICAL HAZARDS:

• Unplug and/or disconnect all electrical power to the unit before performing inspections, maintenance, or service.

• Make sure to follow proper lockout/tag out procedures.

• Always work in the company of a qualied assistant if possible.

• Capacitors, even when disconnected from the electrical power source, retain an electrical charge potential

capable of causing electric shock or electrocution.

• Handle, discharge, and test capacitors according to safe, established, standards, and approved procedures.

• Extreme care, proper judgment, and safety procedures must be exercised if it becomes necessary to test or

troubleshoot equipment with the power on to the unit.

• Do not spray water on the air conditioning unit while the power is on.

• Electrical component malfunction caused by water could result in electric shock or other electrically unsafe

conditions when the power is restored and the unit is turned on, even after the exterior is dry.

• Use air conditioner on a single dedicated circuit within the specied amperage rating.

• Use on a properly grounded outlet only.

• Do not cut or modify the power supply cord or remove the ground prong of the plug.

• Never operate the unit on an extension cord.

• Follow all safety precautions and use proper and adequate protective safety aids such as: gloves, goggles,

clothing, properly insulated tools, and testing equipment etc.

• Failure to follow proper safety procedures and/or these warnings can result in serious injury or death.

INTRODUCTION

Personal Injury Or Death Hazards

6PB

• REFRIGERATION SYSTEM REPAIR HAZARDS:

• Use approved standard refrigerant recovering procedures and equipment to relieve high pressure before

opening system for repair.

• Do not allow liquid refrigerant to contact skin. Direct contact with liquid refrigerant can result in minor to

moderate injury.

• Be extremely careful when using an oxy-acetylene torch. Direct contact with the torch’s ame or hot surfaces

can cause serious burns.

• Make certain to protect personal and surrounding property with re proof materials and have a re extinguisher

at hand while using a torch.

• Provide adequate ventilation to vent off toxic fumes, and work with a qualied assistant whenever possible.

• Always use a pressure regulator when using dry nitrogen to test the sealed refrigeration system for leaks,

ushing etc.

• MECHANICAL HAZARDS:

• Extreme care, proper judgment and all safety procedures must be followed when testing, troubleshooting,

handling, or working around unit with moving and/or rotating parts.

• Be careful when, handling and working around exposed edges and corners of the sleeve, chassis, and other unit

components especially the sharp ns of the indoor and outdoor coils.

• Use proper and adequate protective aids such as: gloves, clothing, safety glasses etc.

• Failure to follow proper safety procedures and/or these warnings can result in serious injury or death.

• PROPERTY DAMAGE HAZARDS

• FIRE DAMAGE HAZARDS:

• Read the Installation/Operation Manual for the air conditioning unit prior to operating.

• Use air conditioner on a single dedicated circuit within the specied amperage rating.

• Connect to a properly grounded outlet only.

• Do not remove ground prong of plug.

• Do not cut or modify the power supply cord.

• Do not use extension cords with the unit.

• Be extremely careful when using acetylene torch and protect surrounding property.

• Failure to follow these instructions can result in re and minor to serious property damage.

• WATER DAMAGE HAZARDS:

• Improper installation, maintenance or servicing of the air conditioner unit can result in water damage to personal

items or property.

• Insure that the unit has a sufcient pitch to the outside to allow water to drain from the unit.

• Do not drill holes in the bottom of the drain pan or the underside of the unit.

• Failure to follow these instructions can result in damage to the unit and/or minor to serious property damage.

INTRODUCTION

Personal Injury Or Death Hazards

7 PB

INTRODUCTION

Operation of Equipment in During Construction

• OPERATION OF EQUIPMENT MUST BE AVOIDED DURING CONSTRUCTION PHASES WHICH

WILL PRODUCE AIRBORNE DUST OR CONTAMINTES NEAR OR AROUND AIR INTAKE

OPENINGS:

• Wood or metal framing;

• Drywalling or sheathing,

• Spackling or applying joint compound.

• Sanding or grinding.

• Moulding or trimwork.

NOTICE

Operating the equipment during any phase of active construction noted above can

void the equipment’s warranty, also leading to poor performance and premature

failure

8 PB

INTRODUCTION

IMPORTANT: It will be necessary for you to accurately identify the unit you are servicing, so you can be certain of a

proper diagnosis and repair.

Figure 103

This service manual is designed to be used in conjunction with the installation and operation manuals provided

with each air conditioning system.

This service manual was written to assist the professional service technician to quickly and accurately diagnose

and repair malfunctions.

Installation procedures are not given in this manual. They are given in the Installation and Operation Manual which

can be aquired on the Friedrich website (www.friedrich.com).

Model Number Reference Guide

MODEL NUMBER

07 = 7,000 Btuh

Nominal Capacity

09 = 9,000 Btuh

12 = 12,000 Btuh

15 = 15,000 Btuh

Series

PD = FriedrichDigital PTAC

System

X = Accessory

E = Cooling with or without electric heat

H = Heat Pumpwith Auxiliary Heat

* 5.0 kw only available on 9,000 12,000 and 15,000 BTU models

Voltage

K = 230/208V - 1 Ph. - 60 Hz.

R = 265V - 1 Ph. - 60 Hz.

Chassis

S = Standard

Nominal Heater Size (230V or 265V)

2 = 2.5 KW 3 = 3.5 KW 5 = 5.0 KW*

Engineering Digit

Design Series

Note: All PTAC models with a C design series or

later come standard with Diamonblue seacost

protection and digital controls.

9 PB

INTRODUCTION

Serial Number Reference Guide

Figure 104

YEAR OF MANUFACTURE

17 = 2017 18 = 2018

19 = 2019 20 = 2020

21 = 2021 22 = 2022

MONTH OF MANUFACTURE

01 = JANUARY

02 = FEBRUARY

03 = MARCH

04 = APRIL

05 = MAY

06 = JUNE

07 = JULY

08 = AUGUST

09 = SEPTEMBER

10 = OCTOBER

11 = NOVEMBER

12 = DECEMBER

MANUFACTURING LOCATION

NUMERIC SEQUENCE

FIRST UNIT OF EACH MONTH = 00001

17 12 M 00001

Refer to the Chart below for Serial Numbers beginning with an Alpha Sequence

A K A M 00001

LJ = 2009 AE = 2015

AK = 2010 AF = 2016

AA = 2011 AG = 2017

AB = 2012

AC = 2013

AD = 2014

A = Jan D = Apr G = Jul K = Oct

E = May H = Aug L = NovB = Feb

C = Mar F = Jun J = Sep M = Dec

PTAC Serial Number Identification Guide

PRODUCT LINE

M = PRODUCT CODE

MONTH MANUFACTURED

SERIAL NUMBER

PRODUCTION RUN NUMBERYEAR MANUFACTURED

10 PB

SPECIFICATIONS

General Specications 7-9k Electric Heat

Figure 201 (General Specs)

PTAC Electric Heat models

PDE07K PDE07R PDE09K PDE09R

PERFORMANCE DATA:

Cooling Btu 7200/7000 7200 9400/9200 9400

Cooling Watts 550/535 550 775/760 775

Energy Efciency Ratio, EER 13.0/13.0 13.0 12.1/12.1 12.1

Moisture Removal (pints/hr.) 1.7 1.7 2.1 2.1

Sensible Heat Ratio 0.86 0.86 0.85 0.85

ELECTRICAL DATA:

Voltage (1 PHASE, 60 Hz) 230/208 265 230/208 265

Volt Range 253-187 292-239 253-187 292-239

Current (Amps) 2.7/2.9 2.4 3.7/3.9 3.3

Power factor 0.97 0.97 0.97 0.97

Compressor LRA 13.0 12.5 19.5 13.5

Compressor RLA 2.5 2.2 3.5 3.0

Outdoor Fan Motor, HP 0.080 0.080 0.080 0.080

AIRFLOW DATA:

Indoor CFM, HIGH 345/315 345 355/325 355

Indoor CFM, LOW 270/255 270 300/275 300

Vent CFM 75 75 75 75

PHYSICAL DATA:

Sleeve Dimensions (H x W x D) 16” x 42” x 13 3/4” (all models)

Dimensions with Front (H x W x D) 16”x 42”x 21 1/2” (all models)

Cut Out Dimensions (H x W x D) 16 1/4”x 42 1/4” (all models)

Net Weight (lbs.) 106 107 115 115

Shipping Weight (lbs.) 126 127 135 135

R-410A CHARGE (oz.) 23 23 24 24

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Friedrich Klimaanlage Handbücher

Friedrich

Friedrich SH15 Bedienungsanleitung

Friedrich

Friedrich MW09TC3E Bedienungsanleitung

Friedrich

Friedrich ZoneAir P-09 Bedienungsanleitung

Friedrich

Friedrich MW24C3F Bedienungsanleitung

Friedrich

Friedrich HEAT&COOLING MODEL INVERTER (REVERSE CYCLE) ROOM AIR CONDITIONER WALL MOUNTED... Bedienungsanleitung

Friedrich

Friedrich P/N9359944072-01 Bedienungsanleitung

Friedrich

Friedrich ZoneAire P09B Leitfaden

Friedrich

Friedrich ZStar ZQ08 Bedienungsanleitung

Friedrich

Friedrich Hazardgard SH15L30-A Leitfaden

Friedrich

Friedrich MS36Y3F Bedienungsanleitung

Friedrich

Friedrich WallMaster WS08 Bedienungsanleitung

Friedrich

Friedrich MULTI ZONE MR24DY3JMA Produkthandbuch

Friedrich

Friedrich Breeze BR1224W3A Bedienungsanleitung

Friedrich

Friedrich A-SERIES Original Betriebsanleitung

Friedrich

Friedrich VHA24K25 Series Original Betriebsanleitung

Friedrich

Friedrich Z-Star ZQ05C10 Bedienungsanleitung

Friedrich

Friedrich ZoneAir P-12 Bedienungsanleitung

Friedrich

Friedrich MW18TC3E Bedienungsanleitung

Friedrich

Friedrich S36YF Bedienungsanleitung

Friedrich

Friedrich Wall Master PE07K**B Bedienungsanleitung

Friedrich

Friedrich DVKA Bedienungsanleitung

Friedrich

Friedrich VERT-I-PAK VEA09 Original Betriebsanleitung

Friedrich

Friedrich ZoneAire P09A Bedienungsanleitung

Friedrich

Friedrich 9370937039-02 Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
