Frigidaire FWA2107RN Bedienungsanleitung

Remote Control Model:

FWA2107RN, FWA2109R

FWA2112R, FWA2118R

Please read this operating manual care-

fully before operating the unit ……

Our design is based on the best efficiency and the lowest noise operation and it can keep the room

comfortable. Please read this operating manual carefully before operating the unit and keep it for consultation.

CONTENTS

Function

Operating condition

Power requirement

Installation

Notes for installation

7Part identification

7Air direction adjustment

Main switch operation procedure (Applicable to Mechanical Models ONLY)

51Operation tips

61Caution

71Care and maintenance

81Trouble shooting guide

Str uctur e mechanism and Installation

9Operation of wireless remote control (Applicable to Remote Control Models ONLY)

Operation procedure

Care and maintenance

The figures in this manual may be different with the material objects,

please refer to the material objects for reference.

91After service

Function

Introduction

Window type room air conditioners can regulate the room

temperature and dry the room. It is convenient for your work,study

and life. It can be widely used in residence, shop, hotel, office, library

and laboratory, and so on.

Room

temp.

Spring

Summer

Autumn

Wind

direction

Winter

Cooling in summer

In hot summer, Air conditioner can cool down

the room air by transferring heat out.

Without reducing the room temp., air conditioner

can dehumidify and make the room air dry and

comfortable.

Dehumidifying in rainy or

humid season

Exchange fresh air

Open storm door to keep the fresh air in the room.

Dry

Fresh Air

Heating in winter

In cold winter, Air conditioner can heat up room air.

(Only for heat unit)

Operating Condition

Please operate air conditioner in the correct conditions as following.

Power requirement

COOL mode operation

DRY mode operation

Outdoor temperature should be in range of 18 to 43 ,

otherwise it is possible for air conditioner to breakdown.

Outdoor temperature should be in range of 18

to 43 , otherwise it is possible for air conditioner

to breakdown.

Room humidity should be lower than 90%.

Otherwise, it is possible for air conditioner to dew

at air conditioner surface and even drop water af-

ter running for so much time. But this is normal.

Water pipe

Rated voltage and voltage range: 230V 10%

The electric components will be damaged when the voltage is too high.

If the voltage is too low, the compressor will vibrate violently to dam-

age the refrigerant system and easily cause the compressor and elec-

tric components not work.

The ground must be connected.

Special socket must be used. Furthermore, the socket and wiring

must conform to the wiring regulations. And the earthing method

must be reliable.

In fixed circuit, there must be electricity leakage protection switch

of enough power capacity and air switch with enough space.

Earth wire To ensure the reliable earthing, please do not connect earth wire to the following places:

The indoor distance from obstructions should be 300mm (above), 1500mm (below),

500mm (left), 500mm (right) and 1500mm (front).

The outdoor distance from obstructions should be over 150mm (above, left, right)

and over 500mm (back). Please refer to the drawing below.

Installation

Installation precaution:

Window type conditioner is so valuable and the improper installa-

tion of it will cause a lot of damage! Please associate the profes-

sional technician to install the unit and don’t install it by yourself.

Otherwise, we are not responsible for the damage like this.

Location:

The condensation water must be drained away conveniently.

Install air conditioner unit far away from TV set or radio

etc. to avoid disturbing video or voice.

In salt and coastal area or place where is near thermal springs

and polluted by sulphurous gas, or other special areas, please

contact the seller before use.

Avoid a place where is possible for inflammable gas to leak out.

Avoid other heat sources or direct sun light.

Avoidaplace where is easy for children to touch.

For window type air conditioner with remote

control, install in a location where is strong elec-

tromagnetic disturbance, you should contact the

seller in advance to avoid the malfunction in use.

How to install:

Choose a location where there are no any obstacle surrounding

the unit, and the plug is accessible.

Prepare the installation hole slightly bigger than unit size.

Choose the installation space according to the following diagram.

Don't use the unit in the immediate surrondings of

a laundry,a bath,a shower or a swimming pool.

•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

•The appliance shall be installed in accordance with national wiring regulations or similarly qualified persons in order

to avoid a hazard.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent.

•Please read this operating manual carefully before operating the unit.

The figures in this manual may be different with the material objects, please refer to the material objects for reference.

Notice:

Sunshade board

Wall

Wooden frame

Rubber plate

Support

Horizontal line

Installation procedure:

1) Remove the sticker from the front panel.

2) Put the unit into the installation hole.

When installing the unit, it should be slanted

down to the back to avoid the enlargement of

noise or vibration. (Slant between 6-10mm.)

(Shown at right figure.)

The installation place should be strong enough

to avoid the enlargement of noise or vibration.

3) Fill up sews in the cabinet with sponge or foam.

Installation assistance:

Use iron support

The installation hole should be strong enough to

support the air conditioner. If it cannot, iron sup-

port has to be used outdoors.

Iron support should be fixed on the building (Shown

at right figure.)

Use sunshade board

Air conditioner should avoid anything to be dropped

into it and avoid direct sunshine. If there is no cover

on it, you should contact the seller for installing

the sunshade board. When installing the sunshade

board, don’t let it block the air inlet at the side grille.

Note:

Drain pan and drain hose must be installed before using reverse cycle models.

Drain hose or tubing can be purchased locally to satisfy your particular needs.

Drain water for another style:

To get the maximum cooling efficiency, the air conditioner is designed to splash the condensation water on the

condenser coil.

To the cooling only unit,If the splashing sound annoys you, you can provide an outside drain by using the follo

-wing procedure, whichmay however cause a small loss of performance.

1. Slide out the chassis from the cabinet.

2. Remove the rubber plug from the body base plate.

3. Install the drain pan to the corner of the cabinet with 2 screws.

4. Connect the drain hose to the outlet on the drain pan bottom.

5. Slide the chassis into its original place in the cabinet.

Drain water for one style:

To get the maximum cooling efficiency,the air conditioner is designed to splash the condensate on the

condenser coil.

If the splashing sound annoys you, you can provide an outside drain by using the following procedure,

which may however cause a small loss of performance.

1.There is a drainage outlet at the back of the unit.

2.Remove cover from the drainage outlet , and then connect drainage joint to it with screw.

3.Connect the drain hose to the outlet.

Note:

Drain hose or tubing can be purchased locally

to satisfy your particular needs.

Drainage outlet

Washer

Drainage joint

Install

Cover

Remove

Notes for installation

Remove

Before removing air conditioner to the other place, you should

contact the seller firstly.

Then it must be done under the direction of the professional

technician. In addition, the charge of this must be paid.

Noise

Electric wiring

Install in a location where is firm enough to avoid the enlargement of noise

and vibration.

Don’t put anything in front of the outlet of outdoor unit to avoid increasing

noise.

Be sure that hot air ornoise will not inconvenience neighbors.

Please contact the seller as soon as there is strange noise during operation.

Please use the safety support.

Must connect with ground reliably.

The exclusive circuit must be used. But removable socket can’t be used because poor

contact of it can cause over heat or fire.

If the supply cord is damaged,it must be replaced by the manufacturer or your dealer

In fixed circuit, there must be electricity leakage protection switch and leakage current

is less than 30mA.

Air switch (thermal-magnetic breaker) should be installed in the circuit.

Don’t pull the power cord strongly.

or a qualified person to avoid a hazard.

All The dectrical work must be done according to the local wiring regulations.

An all-pole disconnection switch having a contact separation of at least 3mm in all poles

should be connected in fixed wiring

Connecting method between air conditioners and power cord and interconnecting method

of each individual element with one another should accord with wiring diagram on the unit.

The air conditioner should be installed in accordance with national wiring regulation.

Parts identification

Vertical airflow direction vane

(Airflow direction adjustment up and down).

The vertical airflow direction vane is controlled by

positioning the vane to discharge the air upwards,

downwards or straight out.

Air direction adjustment

Air filter

(behind the front intake grille)

Front intake grille

Control panel

Power cord

Front grille

Air inlet louver

Cabinet

Mechanical Model

Remote Control Model

Front grille

Air inlet louver

Cabinet

Air filter

(behind the front intake grille)

Front intake grille

Remote control panel Power cord

Panel outlook picture, just for reference, please take the real unit as standard.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Frigidaire Klimaanlage Handbücher

Frigidaire

Frigidaire FAS186N2 Bedienungsanleitung

Frigidaire

Frigidaire FAS183K2A2 Bedienungsanleitung

Frigidaire

Frigidaire FAC085M7A1 Bedienungsanleitung

Frigidaire

Frigidaire FAS156N1 Bedienungsanleitung

Frigidaire

Frigidaire FRA256SV2 Bedienungsanleitung

Frigidaire

Frigidaire FRA104CV111 Bedienungsanleitung

Frigidaire

Frigidaire CRA102BT110 Betriebsanleitung

Frigidaire

Frigidaire FRA102BT1 Bedienungsanleitung

Frigidaire

Frigidaire FAH14ER2T - 14,000-BTU Through-the-Wall Air... Bedienungsanleitung

Frigidaire

Frigidaire FRA155MT112 Betriebsanleitung

Frigidaire

Frigidaire FAC052K7A3 Bedienungsanleitung

Frigidaire

Frigidaire FAC064K7A1 Bedienungsanleitung

Frigidaire

Frigidaire ELECTRONIC CONTROL AIR CONDITIONER Bedienungsanleitung

Frigidaire

Frigidaire CRA050XT728 Betriebsanleitung

Frigidaire

Frigidaire LRA127CT110 Betriebsanleitung

Frigidaire

Frigidaire CRA093PT10 Bedienungsanleitung

Frigidaire

Frigidaire LRA12HZT211 Bedienungsanleitung

Frigidaire

Frigidaire GAL123K1A2 Bedienungsanleitung

Frigidaire

Frigidaire FAA051N7A Bedienungsanleitung

Frigidaire

Frigidaire FRA122CV1 Bedienungsanleitung

Frigidaire

Frigidaire FAP094P1Z - 9,000-BTU Portable Air... Kurzanleitung

Frigidaire

Frigidaire FHSC102WB1 Bedienungsanleitung

Frigidaire

Frigidaire FAA052N7A1 Kurzanleitung

Frigidaire

Frigidaire FFRE103WA1 Betriebsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Samsung

Samsung AS09HM3N Bedienungsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung

Webasto

Webasto Frigo Top 25 DS Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MSC-GE20VB Bedienungsanleitung
