PRODUCT NO. BASE MODEL NO. SERIES COLOR

FDS252RBS0 FDS252RB 18" Portable white

MARKET

North America

Publication No.

5995370862

020423

-EN/SERVICE /ECL

821

18" Portable

DISHWASHER

Model No.

FDS252RB

FACTORY PARTS CATALOG

DISHWASHER

SERVICE DATA SHEET # - 154384501

OWNER’S GUIDE # - 154418701

ENERGY GUIDE LABEL # - 154399019

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

04/02 2

Publication No. FDS252RBS0

5995370862

CONTROL PANEL

# = Fast Moving Part 3 04/02

* = Non-Illustrated Part

FDS252RBS0 Publication No.

5995370862

CONTROL PANEL

POS. NO PART NO DESCRIPTION

1 154357602 Panel,control ,white

2 154418601 Insert,control panel ,white

3 # 154376202 Timer

8 # 154220401 Switch,selector ,5 button

8* 154242201 Shield,switch

8* 5303318719 Screw,mtg.

11 5304428149 Lens,light

12 154236502 Pushbutton,white

13 154239504 Knob,timer ,white

* # 154421901 Wiring Harness

* 154416601 Shield,wire ,white

* 154399019 Label,energy guide

04/02 4

Publication No. FDS252RBS0

5995370862

DOOR

# = Fast Moving Part 5 04/02

* = Non-Illustrated Part

FDS252RBS0 Publication No.

5995370862

POS. NO PART NO DESCRIPTION

1 154237401 Spring,door ,(2)

2 154093301 Screw,arm assy ,(4)

3 5303270031 Arm Assy,RH & LH

3* 154221401 Cover,arm assy

3* 5303298513 Pin,arm assy

4 5300805884 Pad,door spring

5 154079601 Nut,arm assy ,(4)

7 154352201 Door,inner assy

9 154230101 Dispenser,det/rinse aid ,includes #22

9* 154294701 Screw,#7 plas .375 ,(6) ,disp. assy.

10 154419401 Screw,access panel ,white

11 # 154221101 Baffle,door ,white

12 # 154361201 Latch assy,white

15 154103702 Screw,latch mtg ,(2)

20 154416101 Panel,outer door assy ,white

21 154411301 Panel,access ,white

22 154388801 Cap,Rinse aid

28 154400301 Trim,access panel ,white

30 154026601 Speednut,door baffle

43 154229301 Cover,vent

43* 154229401 Screw,vent cover ,(2)

44 154221001 Gasket,vent cover

51 154320301 Clamp,drip loop ,wire

* # 154227808 Thermostat,temp boost

* 154395501 Retainer,thermostat

DOOR

04/02 6

Publication No. FDS252RBS0

5995370862

TUB

# = Fast Moving Part 7 04/02

* = Non-Illustrated Part

FDS252RBS0 Publication No.

5995370862

POS. NO PART NO DESCRIPTION

1 # 154218701 Tub assy,w/gasket

2 154211601 Strike,door

3 # 154219501 Gasket,tub

4 154200601 Screw,#10-16 x 3/8

5 154333902 Roller,tub

6 5303943103 Screw,w/washer ,(8)

22 154239801 Tubing,water inlet

23 5303318539 Clamp,tubing ,(2)

25 # 154209701 Float

26 154242302 Trim-tub flange,RH

26 154242303 Trim-tub flange,LH

* 154238301 Insulation,tub

TUB

04/02 8

Publication No. FDS252RBS0

5995370862

MOTOR & PUMP

# = Fast Moving Part 9 04/02

* = Non-Illustrated Part

FDS252RBS0 Publication No.

5995370862

POS. NO PART NO DESCRIPTION

1 # 154220901 Heater

1* 154289801 Shield,heater terminal

2 154359701 Bracket,heater ,(2)

3 154106201 Nut,heater ,(2)

7 154365101 Macerator

10 154365302 Cover,volute

12 154365401 Impeller,lower drain

12A 154365501 Slinger,pump

14 154364802 Housing,pump

15 # 154367701 Check valve

16 154246502 Retainer,sump

18 # 154384301 Motor

22 154200201 Screw,pump housing

23 154234301 Nut,spray arm

24 154219201 Spray arm,lower

24* 154232601 Shield,heat ,spray arm

27 154377501 Screw,upper impeller

28 154370601 Impeller,upper

34 154064901 Washer,insulating

35 154200901 Screw,motor mtg

36 154387601 Sleeve & seal assy.

38 154367402 Diffuser

42 154365601 Gasket,pump

44 154122502 Base,tower

45 154122601 Middle,tower

46 154122701 Tip,tower

52 154365201 Cover,pump housing

* 154106801 Clamp,hose ,(2)

* 154200601 Screw,#10-16 x 3/8

MOTOR & PUMP

04/02 10

Publication No. FDS252RBS0

5995370862

FRAME
