Frigidaire FEB27S5A Bedienungsanleitung
PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
FEB27S5ABA FEB27S5A 38254731E1061 black North America
FEB27S5ASA FEB27S5A 38254731E1011 white North America
Publication No.
5995363180
020102
-EN/SERVICE /ECL
377
ELECTRIC
WALL OVEN
Model No.
FEB27S5A
©2002 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046208
OWNER’S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200181
INSTALLATION INSTRUCTIONS - # 318201507
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
01/02 2
Publication No. FEB27S5A
5995363180
CONTROL PANEL
# = Functional Parts 3 01/02
* = Non-Illustrated Parts
FEB27S5A Publication No.
5995363180
CONTROL PANEL
A = FEB27S5A (FEB27S5ASA)
B = FEB27S5A (FEB27S5ABA)
POS. NO PART NO DESCRIPTION
18 5303311208 A - End Cap,white ,RH
18 5303311231 - B End Cap,black ,RH
18A 5303311209 A - End Cap,white ,LH
18A 5303311232 - B End Cap,black ,LH
19 318030032 A - Panel,control ,white
19 318030033 - B Panel,control ,black
20 # 318010900 A B Clock/Timer,EOC
21 5303311212 A - Trim,canopy ,white ,top
21 5303301310 - B Trim,canopy ,black ,top
23 318111602 A B Bracket,clock & relay
42 5303318709 A - Trim,vent ,white
42 5303316983 - B Trim,vent ,black
78 5303302394 A - Cover,oven vent ,white
78 5303302396 - B Cover,oven vent ,black
80 # 318111500 A B Relay,convection ,oven light ,(2)
99 5303316956 A - Screw,6-32 x 3/8 ,white ,(2)
99 5303307406 - B Screw,6-32 x 3/8 ,black ,(2)
* 3201861 A B Screw,6 x 0.375
* 5303211311 A B Screw,8 x 0.500
01/02 4
Publication No. FEB27S5A
5995363180
BODY
# = Functional Parts 5 01/02
* = Non-Illustrated Parts
FEB27S5A Publication No.
5995363180
BODY
A = FEB27S5A (FEB27S5ASA)
B = FEB27S5A (FEB27S5ABA)
POS. NO PART NO DESCRIPTION
1 318066700 A B Back,main
2 318102001 A B Shield,oven top
2A 318071501 A B Shield,oven top
6 5303299719 A B Rack,oven
6B 318025202 A B Shelf,oven
9 5303317977 A B Pan,broiler
10 5303317976 A B Insert,broiler pan
12 318089910 A B Switch,oven light ,door frame
14 # 5308011085 A B Receptacle,oven light
15 # 3201908 A B Light,oven
16 3201911 A B Cover,oven light ,glass
17 5304400195 A B Retainer,light cover
37 # 316111203 A B Sensor,oven temp probe
41 5303310526 A B Cover,hinge cutout
54 5303310514 A B Housing,oven light
56 5303302711 A - Trim,bodyside ,white
56 5303298951 - B Trim,bodyside ,black
58A 318133750 A B Insulation,oven wrapper
58B 318133749 A B Insulation,oven back
59 318072510 A B Tube,oven vent
62 # 5303310518 A B Terminal Block
66 # 5303322963 A B Element,broil
67 # 5303299718 A B Element,bake
68 5304403015 A B Support,element hanger
70 5303300142 A B Shield,insulation
71 318071102 A B Shield,rear wall
76 318056104 A B Front,oven
80 318192400 A B Spring,oven
82 318071801 A B Shield,oven bottom
83 318089517 A B Liner,oven
86 5303310524 A B Receptacle,hinge
88 5303311222 A B Rod,latch
89 # 318095934 A B Motor,latch assy ,w/brkt & switch
89*# 318120710 A B Switch,cooktop shutoff
98 318029900 A B Trim-side,inner,RH
98A 318029901 A B Trim-side,inner,LH
99 318055420 A B Support,adjustable
101 318039512 A - Bracket,trim ,white
101 318039511 - B Bracket,trim ,black
102 318070700 A B Cap,top panel ,RH
102A 318070701 A B Cap,top panel ,LH
103 318028701 A - Trim,base ,white
103 318028700 - B Trim,base ,black
103* 318028801 A - Trim,base ,white ,(under counter)
103* 318028800 - B Trim,base ,black ,(under counter)
108# 318073001 A B Motor,fan
119# 318004900 A B Switch,thermal
124 318076902 A B Box,vent
127 5303310542 A B Adapter,vent tube ,with converter
128 5303311163 A B Bushing
129 5303311164 A B Spring
131 318102202 A B Cover,control housing
132 318101700 A B End,cover ,RH ,control housing
132A 318101701 A B End,cover ,LH ,control housing
150 318072207 A B Bracket,support ,RH ,access cover
150A 318072206 A B Bracket,support ,LH ,access cover
185 318014700 A B Spacer,oven shield
187 318013501 A B Tube,latch rod
188 08007817 A B Spacer,(6)
264 318143811 - B Shield,wire
* # 318078511 A B Box & wires assy
* 5303211311 A B Screw,8 x 0.500
* 5303302745 A B Screw,10-16x1-1/8 ,square drive
01/02 6
Publication No. FEB27S5A
5995363180
DOOR
# = Functional Parts 7 01/02
* = Non-Illustrated Parts
FEB27S5A Publication No.
5995363180
DOOR
A = FEB27S5A (FEB27S5ASA)
B = FEB27S5A (FEB27S5ABA)
POS. NO PART NO DESCRIPTION
3 318026110 A - Trim,oven door ,white
3 318026600 - B Trim,oven door ,black
4 318210504 A - Glass,oven door ,white ,outer
4 318210505 - B Glass,oven door ,black ,outer
6 318073502 A B Shield,air wash
7 318133751 A B Insulation,oven door
9 318048503 A B Liner,oven door
10 5303311217 A B Screw,handle ,door
12 318053100 A B Seal,oven door
16 318042300 A B Glass,oven door ,heat barrier ,(2)
17 318042000 A B Spacer,glass
18 318053000 A B Seal,rope
20 318014301 A - Spacer,handle ,white ,(2)
20 318014300 - B Spacer,handle ,black ,(2)
22 5303310511 A B Bar,glass retainer
23 5303310506 A B Hinge,oven door ,assembly
29 318014400 A B Spacer,door
31 318065102 A B Latch,door
39 316091107 A - Handle,door ,white ,oven
39 316091106 - B Handle,door ,black ,oven
54 5303308456 A B Screw,8-18 x 0.531 ,black ,door frame
59 3202113 A B Plug,button
* 5303211311 A B Screw,8 x 0.500
* 5303302745 A B Screw,10-16x1-1/8 ,square drive
* 5303323277 A B Screw (8-18X13/32)
01/02 8
Publication No. FEB27S5A
5995363180
WIRING DIAGRAM
