PREMIUM INDOOR CAMERA
Get Started
PRE-INSTALLATION CHECKLIST
• Premium Indoor Camera (included)
•AC power adapter (included)
•Broadband Internet connection
•A computer, tablet or smartphone with WiFi is required if the
router does not have the WiFi Protected Setup (WPS) feature
COMPLETE THE FOLLOWING STEPS PRIOR TO
INSTALLING THE CAMERA IN ITS FINAL LOCATION
!
PREMIUM INDOOR CAMERA GUIDE
ADD THE CAMERA TO A
FRONTPOINT SECURITY ACCOUNT
STANDARD WIFI SETUP
1Connect the camera’s AC power adapter and plug it
into an outlet.
2 Wait 1–2 minutes until the camera’s light ashes WHITE.
3Using a phone or tablet, connect to the WiFi network
“ADC-V622 (XX:XX:XX)” where XX:XX:XX are the last six
digits of the camera’s MAC address, which is located on the
back of the device near the power cord.
4Go to http://FPsetup.
5Follow the on-screen instructions to add the camera to
the WiFi network. The LED will be solid GREEN when the
connection is complete.
To ensure a suicient WiFi signal, complete these steps with the camera near
its nal location but prior to mounting.
Menu
Call-Out Button
Volume Down
(Menu Scroll
)
Volume Up
(Menu Scroll
)
To pair with Bluetooth, push the Menu button and use the
Volume buttons to scroll to Bluetooth Mode.
6Log into your my.frontpoint.com account
using a laptop or a desktop.
If this is the rst camera connected to your
Frontpoint account, click the Video tab to
add your camera to your account. Select the
camera from the video device list or type in its
MAC address to begin adding the camera. The
camera’s MAC address is located on the back
of the camera near the power cable.
If you already have a camera connected to your
Frontpoint account, click Settings, then scroll
down to click Add Video Device.
7 Follow the on-screen instructions to nish
adding the camera. You may congure camera
settings from the Settings tab under Video.
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
1
3
34
1
5
If you already have a camera connected to your
Frontpoint account, click Settings, then scroll
down to click Add Video Device.
6 Follow the on-screen instructions to nish
adding the camera. You may congure camera
settings from the Settings tab under Video.
WIFI PROTECTED SETUP
1Connect the camera’s AC power adapter and plug it into an
outlet.
2Press the Menu button and use the Volume buttons to scroll to
WPS Mode. Then follow the audio prompts.
3Press the Menu button to activate WPS Mode. The LED will
ash BLUE.
4Activate the WPS Mode on the router. The camera will begin to
connect to your WiFi network. The camera’s LED will be solid
GREEN when the connection is complete.
Log into your my.frontpoint.com account using a laptop or
a desktop.
If this is the rst camera connected to your Frontpoint account,
click the Video tab to add your camera to your account. Select
the camera from the video device list or type in its MAC address
to begin adding the camera. The camera’s MAC address is
located on the back of the camera near the power cable.
Menu
Call-Out Button
Volume Down
(Menu Scroll
)
Volume Up
(Menu Scroll
)
2
3
To pair with Bluetooth, push the Menu button and use the
Volume buttons to scroll to Bluetooth Mode.
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
5
56
ETHERNET SETUP
1
2
4
1Using an Ethernet cable, connect the camera to the network.
2Connect the camera’s AC power adapter and plug it into a
non-switched outlet (unless you are using a PoE connection).
Wait 1–2 minutes until the LED turns solid green, then proceed
to the next step.
3Add the device by logging into my.frontpointsecurity.com
on your desktop. Once logged in, navigate to the Video tab,
then click on Settings and select the Add Video Device
option.
4Select the camera from the video device list or type in its
MAC address to begin adding the camera. The camera’s MAC
address is located on the back of the camera near the power
cable.
5 Follow the on-screen instructions to nish adding the camera.
You may congure camera settings from the
Settings tab under Video.
Menu
Call-Out Button
Volume Down
(Menu Scroll
)
Volume Up
(Menu Scroll
)
To pair with Bluetooth, push the Menu button and use the
Volume buttons to scroll to Bluetooth Mode.
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
78
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
PREMIUM INDOOR CAMERA GUIDE
LED REFERENCE GUIDE
910
Warning: This will restore factory-default settings to the camera.
If already installed, the camera may need to be removed from the
Frontpoint.com account and re-added after a factory reset.
!
LED REFERENCE GUIDE
Green | Solid
Internet connection—Local network and Internet connection
Green | Flashing
Local network connection—Local network connection only, no Internet
Red | Solid
No network connection—No local network or Internet connection
Red | Flashing
System booting—Camera is booting
Blue | Flashing
WiFi Protected Setup—To enter WiFi Protected Setup, push the Menu
button and use the Volume buttons to scroll to WiFi Protected Setup. See
instructions on page 5 to add the camera to your router and account using
WiFi Protected Setup.
STATUS
White | Flashing
Standard WiFi Mode—To enter Standard WiFi Mode, push the
Menu button and use the Volume buttons to scroll to Standard WiFi
Mode. See instructions on page 3 to add the camera to your router
and account using Standard WiFi Mode.
Yellow | Flashing
Bluetooth pairing—To pair with Bluetooth, push the Menu button
and use the Volume buttons to scroll to Bluetooth Mode.
Red & Green | Flashing
Factory Reset—To perform a factory reset, push the Menu button
and use the Volume buttons to scroll to the Factory Reset option.
Follow the audio prompts to initiate Factory Reset. If factory reset
does not work the rst time you try it, please contact Customer Care
before trying again.
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
11 12
If you have issues connecting the camera to the account, power
cycle the camera. If using the AC adapter, unplug the power
jack from the camera and then plug it back in to restore power.
If using PoE, unplug the Ethernet jack from the camera and then
plug it back in to restore power.
TROUBLESHOOTING
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
13 14
