FROST NOVA2 Installationsanleitung

TOILET ROLL HOLDER 9

Fitting instruction

NOVA2

Exclusion of liability

FROST accepts no liability whatsoever

for damage to persons or property that

occurs or has occurred as a result of

improper installation or maintenance,

particularly if the safety instructions and

other points to note listed are not or have

not been observed in full.

Warning and hazard notices

Improper mounting or use can lead to

accidents and serious injuries.

TOILET ROLL HOLDER 9

Material: Stainless steel, AISI 304

Design: Bønnelycke mdd.

Manufacturer: FROST A/S, Bavne Alle 32,

DK-8370 Hadsten

www.frost.dk

O1972 N1972

N1972-C N1972-BOC

N1972-GO N1972-BMG

N1972-B N1972-BCB

N1972-W

Cleaning and maintenance

Stainless steel surfaces should be

cleaned with a micro bre cloth, glass

cleaner or other non abrasive and gentle

agents.

Attention

Never use solvents or aggressive house-

hold cleaners like bleach, acids (e.g.

descalers) or ammonia-based bathroom

cleaner to clean the product. Steel wool

and hard brushes can permanently

damage the surfaceof the steel.

Ø310 mm

15 mm

128 mm

10 mm

180 mm

124,8 mm

217 mm

WWW.FROST.DK 1

112 mm

11 mm

101,5 mm

R3,5 mm

1. 2. 3.

5. 6.7.

Use enclosed key to open. Mark placements of screw holes.

Ø6 x 30

6x Ø6

Ø4 x 30

Drill the marked holes and insert wall plugs.

Ø4 x 30

WWW.FROST.DK 2

Jumbo Paper

Max diameter: Ø290 mm

Max projection: 100 mm

Paper isnot included and must

be purchaged from another

supplier.

Use 2 screws to secure the toilet roll holder on the wall.

Slide the toilet roll holder down for a thight fit.

Use the 4 last screws to fully secure the toilet roll holder. Insert the jumbo paper and close the front with

the enclosed key.
