Fujitsu Siemens Computers D1120 Bedienungsanleitung

SYSTEMBAUGRUPPE D1120

SYSTEMBAUGRUPPE D1120SYSTEMBAUGRUPPE D1120

SYSTEMBAUGRUPPE D1120

SYSTEM BOARD D1120

SYSTEM BOARD D1120SYSTEM BOARD D1120

SYSTEM BOARD D1120

TECHNISCHES HANDBUCH

TECHNISCHES HANDBUCHTECHNISCHES HANDBUCH

TECHNISCHES HANDBUCH

TECHNICAL MANUAL

TECHNICAL MANUALTECHNICAL MANUAL

TECHNICAL MANUAL

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an:

• einen unserer Servicepartne

• Ihren zuständigen Vertriebspartne

• Ihre Verkaufsstelle

Die Adressen Ihrer Servicepartner finden Sie im Garantieheft oder im Service-Adressenheft.

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Is there ...

... any technical problem or other

question you need clarified?

Please contact:

• one of our service partners

• your sales partne

• your sales outlet

The addresses of your service partners are contained in the guarantee booklet or in the service

address booklet.

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.: A26361-D1120-Z120-1-7419

A26361-D1120-Z120-1-7419A26361-D1120-Z120-1-7419

A26361-D1120-Z120-1-7419

Printed in the Federal Republic of Germany

AG 0100 01/00

A26361-D1120-Z120-1-7419

SYSTEMBAUGRUPPE D1120

SYSTEM BOARD D1120 TECHNISCHES HANDBUCH

TECHNICAL MANUAL

Systembaugruppe

D1120

System Board D1120

Technisches Handbuch

Technical Manual

Deutsch

lish

Ausgabe Januar 2000

January 2000 edition

Intel, Pentium und Celeron sind eingetragene Warenzeichen und MMX und OverDrive sind

Warenzeichen der Intel Corporation, USA.

Microsoft, MS, MS-DOS und Windows sind eingetragene Warenzeichen der Microsoft

Corporation.

PS/2 und OS/2 Warp sind eingetragene Warenzeichen von International Business Machines,

Inc.

Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen

der jeweiligen Inhaber und werden als geschützt anerkannt.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Intel, Pentium and Celeron are registered trademarks and MMX and OverDrive are

trademarks of Intel Corporation, USA.

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.

All other trademarks referenced are trademarks or registered trademarks of their respective

owners, whose protected rights are acknowledged.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved. Delivery subject to availability.

Right of technical modification reserved.

A26361-D1120-Z120-6-7419

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................1

Important notes .................................................................................................................................1

Information on boards................................................................................................................2

Features............................................................................................................................................3

Interfaces and connectors .........................................................................................................5

PCI bus interrupts......................................................................................................................7

Possible screen resolution.........................................................................................................7

Settings with switches .......................................................................................................................8

Recovering System BIOS - switch 2..........................................................................................8

Write protection for floppy disks - switch 3.................................................................................9

Clear CMOS - switch 4..............................................................................................................9

Add-on modules..............................................................................................................................10

Installing / removing processor................................................................................................11

Upgrading main memory..........................................................................................................12

Replacing the lithium battery....................................................................................................13

Glossary..........................................................................................................................................14

A26361-D1120-Z120-6-7419 English - 1

Introduction

This system board is available in different configuration levels. Depending on the

hardware configuration of your device, it may be that you cannot find several options in

your version of the system board, even though they are described.

You may find further information in the description "BIOS Setup".

Further information to drivers is provided in the readme files on hard disk or on the supplied drivers

diskettes or on the "Drivers & Utilities" or "ServerStart" CD.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to texts marked with this symbol. Failure to observe this warning

endangers your life, destroys the system, or may lead to loss of data.

Supplementary information, remarks and tips follow this symbol.

Ê Texts which follow this symbol describe activities that must be performed in the order shown.

ËThis symbol means that you must enter a blank space at this point.

ÚÚ

ÚThis symbol means that you must press the Enter key.

Texts in this typeface are screen outputs.

Texts in this bold typeface are the entries you make via the keyboard.

Texts in italics indicate commands or menu items.

"Quotation marks" indicate names of chapters and terms that are being emphasized.

Important notes

Store this manual close to the device. If you pass on the device to third parties, you should also

pass on this manual.

!Be sure to read this page carefully and note the information before you open the device.

You cannot access the components of the system board without first opening the device.

How to dismantle and reassemble the device is described in the Operating Manual

accompanying the device.

Please note the information provided in the chapter "Safety" in the Operating Manual of

the device.

Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore

essential to observe the instructions in the chapter "Add-on modules“-"Replacing the

lithium battery“.

Important notes

2 - English A26361-D1120-Z120-6-7419

The shipped version of this board complies with the requirements of the EEC

directive 89/336/EEC "Electromagnetic compatibility".

Compliance was tested in a typical PC configuration.

When installing the board, refer to the specific installation information in the

Operating Manual or Technical Manual of the receiving device.

Connecting cables for peripherals must be adequately insulated to avoid interference.

!Components can become very hot during operation. Make sure you do not touch

components when making extensions to the system board. There is a danger of burns!

The warranty is invalidated if the device is damaged during the installation or

replacement of system expansions. Information on which system expansions you can

use is available from your sales outlet or the customer service center.

Information on boards

To prevent damage to the system board or the components and conductors on it, please take great

care when you insert or remove boards. Take care above all to ensure that extension boards are

slotted in straight without damaging components or conductors on the system board, or any other

components, for example EMI spring contacts.

Be especially careful with the locking mechanisms (catches, centering pins etc.) when you replace

the system board or components on it, for example memory modules or processors.

Never use sharp objects (screwdrivers) for leverage.

Boards with electrostatic sensitive devices (ESD) are identifiable by the

label shown.

When you handle boards fitted with ESDs, you must observe the following

points under all circumstances:

• You must always discharge yourself (e.g. by touching a grounded

object) before working.

• The equipment and tools you use must be free of static charges.

• Pull out the power plug before inserting or pulling out boards containing

ESDs.

• Always hold boards with ESDs by their edges.

• Never touch pins or conductors on boards fitted with ESDs.
