STEALTH RACE VTx
Video Transmitter
USER MANUAL VERSION 1.0
1
Contents
Contents..................................................................................................................................................1
Introduction ............................................................................................................................................2
Connections ............................................................................................................................................5
Using Fortini F4 OSD: ..............................................................................................................5
Using Fortini F4: ......................................................................................................................7
Using Radiance Dshot Version: ...............................................................................................8
Using Kombini Dshot Version: ................................................................................................9
Using KISS FC:........................................................................................................................10
Setup .....................................................................................................................................................11
LEDs Status........................................................................................................................................11
Set frequency and power for Stealth Race VTx ...............................................................................11
Option 1: Configure FuriousFPV Stealth Race VTx by button ...............................................11
Option 2: Configure FuriousFPV Stealth Race VTx by app on Smartphone.......................... 12
Option 3: Configure FuriousFPV Stealth Race VTx by Transmitter Taranis ..........................15
Hardware Requirement ....................................................................................................................15
Hardware Connection.......................................................................................................................15
Update Taranis OpenTX Firmware....................................................................................................16
Download LUA Script for Betaflight ..................................................................................................16
Betaflight Configurator Settings .......................................................................................................17
Extra Steps for VTx setup..................................................................................................................17
Setting up LUA script on telemetry page..........................................................................................17
2
Introduction
Stealth Race VTx - Blink, and It's Gone.
At Furious FPV, we're massively excited to debut our flagship model that's destined to push the
boundaries of FPV VTx technology. Nano sized & micron light, the all new Stealth Race VTx is a game
changer, inside & out.
At half the size of competitive based VTx systems, the Stealth Race VTx will blow your mind when it
comes to how much we have packed into this stamp sized beast. Able to fit in just about any racing
quad on the market, the Stealth VTx boasts full size features in the smallest platform we have ever
designed.
Incorporating a built in microphone for in flight audible feedback, Smart Audio support, built in LC
filter for ultra clean video, thermal protection, and the ability to be powered up to 6S 22.2V input
power, the Stealth Race VTx brings plenty to the table with a zero compromise layout. Combine this
with an adjustable VTx power output of 0.1mW / 25mW / 200mW output, this VTx is an all in one
FPV game changer that you can't live without.
Functionality is the game and simplicity is the key. With the Stealth Race VTx, the Furious team has
been hard at work, incorporating intuitive setup capability via Bluetooth technology. This brilliant
system offers a dedicated Furious FPV app for iOS & Android, allowing users to adjust channels &
other functionality with ease via ultra simplified smart phone setup. It just doesn't get much more
simple than that.
The Stealth Race VTx is ultra-compatible and incredibly easy to use. Simple, powerful and amazingly
functional, the Stealth Race VTx is the ultimate VTx solution in a no compromise, ultra-brilliant
design.
Features:
- Supports Smart Audio or IRC Tramp Functionality.
- Fully Adjustable via Bluetooth Capable Smart Phone App
- Built-In LC Filter for Ultra Clean Imagery
- Adjustable VTx Power Output with Pit Mode
- Flexible VTx Power for Race & Freeride Flight
- Stealth Power Up Capable
- Built-In Full Thermal Protection
- High Voltage Ready with 6S Input Power Capability
Specifications:
Dimensions: 15x25x6 mm
Weight: 2.9 gram (without antenna)
Voltage Range: 2-6S Li-Po
VTx Power: 0.1mW / 25mW / 200mW
Micron Small - Half the Size, Triple the Features.
3
At half the size of traditional VTx units, the sheer mico sized layout of the Stealth Race VTx is simply
mind blowing. And then, you begin to see what this system packs - nothing short of magic via pure
design brilliance.
Built In Bluetooth Capability - Power In the Palm of Your Hands.
Incredibly simple to setup and utilize, Furious FPV brings the next evolution of functionality &
brilliance to the table with full up smart phone adjustments. By downloading the Furious FPV iOS /
Android app via your smart phone, you now can adjust your VTx in ultimate style. Like a boss, we
might add.
Built In LC Filter - Keeping It Clean.
Ultra clean imagery is paramount, helping you avoid clipping gates and ending your race in shame &
defeat. By incorporating a built in LC filter, your video imagery is kept clean and focused so you can
push your FPV to the ragged edge & beyond.
Adjustable VTx with Pit Mode Technology - The Ultimate In Setup Flexibility.
Whether setting up your aircraft, pushing hard laps in the race, or relaxing with some epic freeride
flight, the Stealth Race VTx offers it all. Utilizing Pit Mode Technology, you can now setup your gear
while others are in flight by transmitting at an ultra low 0.1mW output. Time to race? Dial it up to
25mW, and after your laps, push it to 200mW for some epic freeride flight.
Stealth Power Up - Keeping the Airwaves Clean.
Protect other racers from signal interference with Stealth Power Up technology, allowing you to
power up your aircraft while keeping your VTx output power at zilch - just where it needs to be.
Built In Thermal Protection - Keeping It Cool.
Crank up the speed without the heat. With built in thermal protection, the Stealth Race VTx keeps
temps under control with built in thermal protection. So, go ahead and push it to the max - the
Stealth Race VTx can take it.
High Voltage Ready - Power to the Max.
With the ability to handle a full 6S 22.2V input power, the Stealth Race VTx can handle all the voltage
you can throw at it, offering ultimate voltage flexibility.
4
Pinout
Dimensions
5
Connections
Using Fortini F4 OSD:
6
7
Using Fortini F4:
You can buy FORTINI F4 right here: https://goo.gl/TPd5kB
8
Using Radiance Dshot Version:
You can buy Radiance DShot Vesion right here: https://goo.gl/RBXrJ6
9
Using Kombini Dshot Version:
You can buy Kombini DShot Vesion right here: https://goo.gl/EzQnak
