Default password:
1234
Change password
Esc Manual calibration:
A.Calibration on ESC Mainboard:(Do not use for Tegu with case and waterproof)
- Step 1: Please make sure to plug the battery to your esc
- Step 2: Press and hold the button of ESC (wait for 6 secs and the ESC LED indicator will start blinking
followed by a motor beeping sound)
- Step 3:Set to 0% Throttle or lowest speed (please make sure that your radio throttle stick at
NEUTRAL POSITION, press the ESC button, ESC LED indicator will blink 1 time and motor will beep 1 time)
- Step 4: Set to 100% Throttle or Maximum speed (move your radio throttle stick FORWARD and press the ESC
button, ESC LED indicator will blink 2 times and motor will beep 2 times)
- Step 5: Setting up of your BRAKE (move the radio throttle stick BACKWARD and press the ESC button, ESC
LED indicator will blink 3 times and motor will beep 3 times)
- Step 6: When your ESC show 4 blinking LED light and your motor beep 4 times mean you successfully
CALIBRATED your Furitek ESC
B.Calibrattion via App: (Your esc need a Bluetooth to communicate with app)
- Step 1: Please make sure to plug your battery to esc and open FURICAR app on android or IOS device
- Step 2: Please click “MENU” and click “THROTTLE”
- Step 3: Please click ”CALIB” and then click “YES”
Bluetooth:
- Default password to connect via Bluetooth "1234"
*Change password:
- Step 1: Please make sure to plug your battery to esc and open FURICAR app on android or IOS device
- Step 2: Please Click the Setting icon (see picture)
- Step 3: Please Click ”Change Password” menu, a new window pops up, type your new password
and then click “OK”
*Follow intructions on the app screen till fishnish calibration
TEGU Manual V1.0
