Before you get started:

• Make sure all optical ends

are clean to avoid poor in-

sertion loss readings and

prevent contamination of

the optical ports on the test

units.

• Annual calibration is

recommended.

CAUTION:

Never look directly into the

output ports of the light

source or the ends of a fiber

optic connector. he light may

not always be visible, but can

still cause damage to the eye.

• urn on LIGHT SOURCE by

pulling up on the TOGGLE

SWITCH and moving it to

the left or the right, select-

ing appropriate wavelength.

NOTE:

o turn off light source, pull

up on toggle switch and move

to center position.

• Insert ST®CONNECTOR

end of LAUNCH JUMPER

into appropriate wavelength

port on Light Source.

• Insert other connector end of

Launch Jumper into Adapter

Cap on Power Meter.

• Zero the Power Meter by

pressing and holding down

the Ref button until HELD

and 0.0 dB is displayed.

NOTE:

It is recommended to re-zero

the Power Meter at least every

30 minutes.

• Disconnect connector end

of Launch Jumper from

adapter cap on Power

Meter and insert into

SPLICE BUSHING.

• Insert one connector end of

the DEVICE UNDER TEST

(DUT) into the Splice Bush-

ing.

• Insert the other connector

end of the DU into the

Adapter Cap on the Power

Meter.

• he number on the Power

Meter display represents the

insertion loss due to the

connector at the Splice

Bushing plus the attenuation

through the length of cable.

• urn on POWER METER by

pressing button.

NOTE:

o disable the 5-minute,

automatic-shutdown battery

saver feature, hold down the

button until Pis displayed.

• On the Power Meter press

the dB/dBm button until dB

is displayed.

• On Power Meter press “λ"

button until appropriate

wavelength is displayed.

• Install appropriate

ADAPTER CAP onto Power

Meter.

• Allow 2 minutes for test set

to stabilize.

echnical Support 888.438.9936 | www.ofsoptics.com

Test Kit Quick Start Guide (Procedure illustrates insertion loss by single-ended test method. efer to booklet for loss by substitution method.)

Before you get started:

• Make sure all optical ends

are clean to avoid poor in-

sertion loss readings and

prevent contamination of

the optical ports on the test

units.

• Annual calibration is

recommended.

CAUTION:

Never look directly into the

output ports of the light

source or the ends of a fiber

optic connector. he light may

not always be visible, but can

still cause damage to the eye.

• urn on LIGHT SOURCE by

pulling up on the TOGGLE

SWITCH and moving it to

the left or the right, select-

ing appropriate wavelength.

NOTE:

o turn off light source, pull

up on toggle switch and move

to center position.

• Insert ST®CONNECTOR

end of LAUNCH JUMPER

into appropriate wavelength

port on Light Source.

• Insert other connector end of

Launch Jumper into Adapter

Cap on Power Meter.

• Zero the Power Meter by

pressing and holding down

the Ref button until HELD

and 0.0 dB is displayed.

NOTE:

It is recommended to re-zero

the Power Meter at least every

30 minutes.

• Disconnect connector end

of Launch Jumper from

adapter cap on Power

Meter and insert into

SPLICE BUSHING.

• Insert one connector end of

the DEVICE UNDER TEST

(DUT) into the Splice Bush-

ing.

• Insert the other connector

end of the DU into the

Adapter Cap on the Power

Meter.

• he number on the Power

Meter display represents the

insertion loss due to the

connector at the Splice

Bushing plus the attenuation

through the length of cable.

• urn on POWER METER by

pressing button.

NOTE:

o disable the 5-minute,

automatic-shutdown battery

saver feature, hold down the

button until Pis displayed.

• On the Power Meter press

the dB/dBm button until dB

is displayed.

• On Power Meter press “λ"

button until appropriate

wavelength is displayed.

• Install appropriate

ADAPTER CAP onto Power

Meter.

• Allow 2 minutes for test set

to stabilize.

echnical Support 888.438.9936 | www.ofsoptics.com

Test Kit Quick Start Guide (Procedure illustrates insertion loss by single-ended test method. efer to booklet for loss by substitution method.)

Inse tion-Loss-Quick-Sta t-Guide_Layout 1 9/18/15 3:14 PM Page 1

V-System®F07 ST SMA

Single-Ended Method Substitution Method Single-Ended Method Single-Ended Method Single-Ended Method

Connector Factor 2.0 4.0 2.0 1.5 1.5

Expected Insertion Loss for 200 and 400 µm HCS®Cab e Assemb ies

To ca cu ate expected insertion oss (ILMAX) va ues for cab e assemb y engths not in tab e:

For Length in Feet For Length in Meters

@ 660 nm: ILMAX = Connector Factor + (0.0037 x Length in feet) @ 660 nm: ILMAX = Connector Factor + (0.012 x Length in meters)

@ 850 nm: ILMAX = Connector Factor + (0.0024 x Length in feet) @ 850 nm: ILMAX = Connector Factor + (0.008 x Length in meters)

Assembly Len th

Part #: P9930-02 Rev. H

1See "Insertion Loss Test Kit Instruction Manual" for detailed explanation of insertion loss methods. HCS is a registered trademark in the USA of OFS Fitel, LLC. V-System is a registered trademarks of OFS Fitel, LLC.

V-System®F07 ST SMA

Single-Ended Method Substitution Method Single-Ended Method Single-Ended Method Single-Ended Method

Connector Factor 2.0 4.0 2.0 1.5 1.5

Expected Insertion Loss for 200 and 400 µm HCS®Cab e Assemb ies

Connector Type and test method1

V-System®F07 ST SMA

Single-Ended Method Substitution Method Single-Ended Method Single-Ended Method Single-Ended Method

Operating Wavelength 660 nm 660 nm 660 nm 660 nm 850 nm 660 nm 850 nm

5 ft (1.5 m) 2.0 dB 4.0 dB 2.0 dB 1.5 dB 1.5 dB 1.5 dB 1.5 dB

50 ft (15.2 m) 2.2 dB 4.2 dB 2.2 dB 1.7 dB 1.6 dB 1.7 dB 1.6 dB

100 ft (30.5 m) 2.4 dB 4.4 dB 2.4 dB 1.9 dB 1.7 dB 1.9 dB 1.7 dB

200 ft (60.9 m) 2.7 dB 4.7 dB 2.7 dB 2.2 dB 2.0 dB 2.2 dB 2.0 dB

300 ft (91.4 m) 3.1 dB 5.1 dB 3.1 dB 2.6 dB 2.2 dB 2.6 dB 2.2 dB

400 ft (121.9 m) 3.5 dB 5.5 dB 3.5 dB 3.0 dB 2.5 dB 3.0 dB 2.5 dB

500 ft (152.4 m) 3.8 dB 5.8 dB 3.8 dB 3.3 dB 2.7 dB 3.3 dB 2.7 dB

600 ft (182.9 m) 4.2 dB 6.2 dB 4.2 dB 3.7 dB 3.0 dB 3.7 dB 3.0 dB

700 ft (213.4 m) 4.6 dB 6.6 dB 4.6 dB 4.1 dB 3.2 dB 4.1 dB 3.2 dB

800 ft (243.8 m) 4.9 dB 6.9 dB 4.9 dB 4.4 dB 3.5 dB 4.4 dB 3.5 dB

900 ft (274.3 m) 5.3 dB 7.3 dB 5.3 dB 4.8 dB 3.7 dB 4.8 dB 3.7 dB

1000 ft (304.8 m) 5.7 dB 7.7 dB 5.7 dB 5.2 dB 3.9 dB 5.2 dB 3.9 dB
