Low Loader Trailer Manual
If you have any questions please email service@futuratrailers.com
ph (855) 744 3877
futuratrailers.com!
Futura Trailers Limited Warranty (Overview)
Below is a brief overview of your trailers TWO YEAR LIMITED WARRANTY and the process for obtaining warranty service.!The full description of
the warranty can be found on our website www.futuratrailers.com/warranty.
Futura Trailers Inc warrants that its product will be free from defects in materials and workmanship, under normal use and service for a
period of two (2) years. The warranty period starts the day of purchase by the original owner.
In the event that the trailer is returned to an authorized Futura Trailers dealer or Futura Trailers facility or authorised agent and under their
inspection is determined to have been defective in material and/or workmanship, under normal use, the trailer will be repaired without
charge to the original purchaser.
You must contact Futura Trailers Inc or the dealer from which your trailer was purchased to make a warranty claim. All warranty work
performed must be pre-approved by Futura Trailers Inc, or Futura Trailers Inc reserves the right to deny coverage. All repairs must be
performed by Futura Trailers Inc, Futura Trailers Inc dealer or a service agent that has been pre-approved by Futura Trailers Inc.!Futura Trailers
Inc is not responsible for costs relating to transportation and delivery charges of the affected product.!
Futura Trailers Inc obligations under this limited warranty shall be limited to repairing or replacing any part or parts which, in the opinion of
Futura Trailers Inc, shall prove defective in materials or workmanship under normal use and service during the applicable two year period,
commencing with the date of the first retail purchase and no other remedy is available. Any freight transportation charge to or from Futura
Trailers Inc facilities or approved repairer is the responsibility of the purchaser and shall not be a part of the manufacturer’s limited warranty.
The limited warranty shall be void where the unit has been subject to misuse, neglect, alteration, modification, accident or where repair parts
or actual repairs have been supplied and/or performed without Futura Trailers authorization. Loading in excess of gross vehicle load ratings
stated on the VIN and Tire plates or incorrect loading will invalidate any and all warranties. Damage caused by failure to check and torque or
adjust wheel lug nuts or wheel bearings as specified is not covered by warranty. Normal maintenance and service items will not be replaced
due to wear (items include, but are not limited to, bearings, bushes, sheaves, brakes, brake linings, rigging cable, battery).
Limited Warranty does not cover wear, deterioration and/or damage from road elements, salt, sand, weather conditions, and/or improper
wash solvents. Any damage caused by or attributed to any act of God whatsoever is not covered by manufacturer’s limited warranty.
Limited Warranty claims can be entered at futuratrailers.com or email service@futuratrailers.com.
For full Limited Warranty terms and conditions;
DOWNLOAD FUTURA TRAILERS LIMITED WARRANTY DOCUMENT FROM FUTURATRAILERS.COM/WARRANTY!
futuratrailers.com
U.S. DEPARTMENT OF TRANSPORT (DOT) REQUIRES FUTURA TRAILERS INC TO HAVE A RECORD OF THE
FIRST PURCHASER OF A NEW VEHICLE. PLEASE ASSIST YOUR DEALER BY PROVIDING THE NECESSARY
INFORMATION TO REGISTER YOUR TRAILER OR REGISTER ON OUR WEB SITE
FUTURATRAILERS.COM/WARRANTY
OR E-MAIL SERVICE@FUTURATRAILERS.COM OR PHONE 855 744 3877
Welcome to Futura Trailers
Thank you for your recent purchase of a Futura Low Loader trailer.!At Futura Trailers we take great pride in the
quality of our trailers and hope your experience with our company is both satisfying and rewarding. We are
confident that our trailers will meet your high standards. If at any time you find you have issues with your
trailer, please do not hesitate to contact your local Futura Trailers dealer or our service department,
service@futuratrailers.com.
View Quick Start Video at futuratrailers.com/manuals
Before operating the trailer, please refer to both
“Low Loader Trailer Manual” and “Utility Trailer Owners Manual”
This User’s Manual contains safety information and instructions for your trailer. You must
read this manual along with Utility Owners Manual before loading or towing your trailer.
You must follow all safety precautions and instructions.
futuratrailers.com
Welcome to Futura Trailers
Check wheel lug nut torque to 95 ft/lb, 10, 25 and 50 miles and before each tow.
Trailer wheel lug nuts are prone to loosen after first being assembled. When towing a new trailer, or after wheels have been
remounted, check to make sure the lug nuts are tight after the first 10, 25 and 50 miles of driving and before each tow thereafter.
• Torque wheel lug nuts to 95 ft/lb in the sequence shown above.
• Repeat sequence before each trip or whenever a wheel is removed or replaced.
Check wheel bearings for heat and excessive play at 10, 25 and 50 miles.
The wheel bearing play is set at the factory, however, the wheel bearings may need resetting after towing and should be checked
regularly.
• Tow the trailer for 10 miles at highway speeds.
• Stop the vehicle and park in a safe location.
• Place your hand on each of the wheel hubs of the trailer. If a hub is too warm to comfortably hold your hand on,
the bearing is generating excessive heat and may be defective, have insufficient play or require lubrication.
• Setting wheel bearings please refer to the Service and Maintenance section of this manual.
• Check the wheel bearing for excessive heat or play again after 25 and 50 miles.!
futuratrailers.com
Wheel separation can occur, for proper safety and performance the
following checks should be performed at the specified intervals.
Failure to follow these instructions may result in serious injury or death! Additionally,
failure to follow these instructions may subject you to personal liability penalties as
determined by the U.S. Judicial System. Failure to follow these instructions may invalidate
the product warranty.
Read before towing your trailer.
Operating your Futura Low Loader
Learn how to safely and correctly operate the Futura Low Loader trailer. This document is to be read in
conjunction with the “Futura Utility Trailer Owners Manual” and instructional videos are available at
futturatrailers.com/videos.
futuratrailers.com
1. Connect the trailer to the tow vehicle.
Tow-ball size - 2 5/16”
Hitch height
should be 14” to 16”
Dangerous trailer sway may occur if hitch height is too low.
Lifting arm will not raise fully if hitch height is too low.
Operating your Futura Low Loader
futuratrailers.com
Ensure the tow ball size is correctly matched to the hitch.
Safety cables are connected and crossed and breakaway is
connected to the tow vehicle.
Connect to the tow vehicle. Ensure the safety
cables and the break-away cable are securely
connected to the tow vehicle. Safety cables
must be crossed under the hitch.
Raise the jack fully.
Remove the jack wheel and stow.
Operating your Futura Low Loader
!!
!!!!!!!!!!
futuratrailers.com
Turn on the master switch to operate the
trailer winch.
Before attempting to lower the trailer,
release all of the safety latches.
Latch shown in un-locked position.
3. Lower the trailer.
2. Park the trailer on level ground.
The trailer lifting arms may not raise fully if the trailer is
not parked on level ground.
Operating your Futura Low Loader
futuratrailers.com
Stand clear of the trailer or remain in loaded vehicle while lowering or
raising. There are several crush zones.
Never touch cables or moving parts when in operation.
Turn on your wireless remote by holding
down the two buttons simultaneously for 5
seconds until the red light illuminates.
or - use the manual switch on the winch
enclosure to lower the trailer.
Lower the trailer with the wireless Trailer
remote;
Operating your Futura Low Loader
futuratrailers.com
If you forget to unlock the safety latches before lowering the trailer,
do not attempt to unlock the safety latches as they will be under
load. Raise the trailer again, then release the safety latches.
Lower the trailer until the rear of the trailer is on the ground. Do not overrun the winch down. Stop as soon
as the load is light on the cable. The trailer’s tires should take some load when the vehicle is being loaded.
Raise the license plate.
Pre set the safety latches to auto latch once the
trailer is fully raised.
4. Pre set the safety latches
Operating your Futura Low Loader
Load the vehicle as far forward as possible. Ensure that at least 10% of the total weight is on the trailer tongue.
Rear and mid engine cars may require loading backwards for correct load distribution. If you drive on take the
remote with you. You may use the remote to raise the trailer from inside the vehicle. You may not be able to
open your vehicle doors with the trailer lowered.
futuratrailers.com
5. Roll, winch or drive the vehicle onto the trailer.
Ensure safety latches are preset to latch and stand clear or
remain in the vehicle while raising the trailer!
6. Raise the trailer using the Trailer remote or winch enclosure switch.
