Future Systems SecuwayCard 2000 Bedienungsanleitung
DASTEK EMC Lab,
DASTEK EMC Lab,DASTEK EMC Lab,
DASTEK EMC Lab, 204 Chuge-Ri Yangji-Myeon Yongin-Shi Kyunggi-Do,Korea
Tel:82-31-335-9341 Fax: 82-31-335-9343
!"#$%!&'#() *"+##()#")#,*(,-.%(,)./.'&012!) ) #0!'!)"-.3*0*"",!4!)*0
,#5!/#&%3"%*()).&*3).-) #%0#" #"#0!'!)"*3#,#"!4(#,).&3.5!,#3#*".(*+0#
&3.)#/)!.(*4*!(") *3'-%0!()#3-#3#(/#!(*3#"!,#()!*0!(")*00*)!.( !"#$%!&'#()4#(#3*)#"
%"#"*(,/*(3*,!*)#3*,!.-3#$%#(/1#(#341*(,!-(.)!(")*00#,*(,%"#,!(*//.3,*(/#2!)
) #!(")3%/)!.("'*1/*%"# *3'-%0!()#3-#3#(/#).3*,!./.''%(!/*)!.(.2#5#3) #3#!"
(.4%*3*()##) *)!()#3-#3#(/#2!00(.).//%3!(*&*3)!/%0*3!(")*00*)!.(-) !"#$%!&'#(),.#"
/*%"# *3'-%0!()#3-#3#(/#).3*,!..3)#0#5!"!.(3#/#&)!.(2 !/ /*(+#,#)#3'!(#,+1
)%3(!(4) ##$%!&'#().--*(,.() #%"#3!"#(/.%3*4#,).)31)./.33#/)) #!()#3-#3#(/#+1
.(#.3'.3#.-) #-.00.2!(4'#*"%3#"
6#.3!#().33#0./*)#) #3#/#!5!(4*()#((*
6(/3#*"#) #"#&*3*)!.(+#)2##() ##$%!&'#()*(,3#/#!5#3
6.((#/)) ##$%!&'#()!().*(.%)0#).(*.!3/%!),!--#3#(/#-3.'
) *)).2 !/ ) #3#/#!5#3!"/.((#/)#,
6.("%0)) #,#*0#3.-*(#7!#(/#,3*,!.8)#/ (!/!*(-.3 #0&
!"%(!)2*")#")#,2!) " !#0,#,/*+0#".() #!& #3*0,#5!/#" !#0,#,/*+0#"
'%")+#%"#,2!) ) #%(!)).!("%3#/.'&0!*(/#
#'*(%-*/)%3#3!"(.)3#"&.("!+0#-.3*(13*,!..3!()#3-#3#(/#/*%"#,+1
%(*%) .3!9#,'.,!-!/*)!.(").) !"#$%!&'#()%/ '.,!-!/*)!.("/.%0,5.!,) #%"#3:"
*%) .3!)1)..*)#) ##$%!&'#()
Part 1
SecuwayCard 2000
Installation
1-1
Chapter 1 SecuwayCard 2000?
The SecuwayCard 2000 is a part of the SecuwaySuite 2000
package as mentioned previously on this manual. Cooperating with the
SecuwayCenter 2000, SecuwayGate 2000,
SecuwayClient 2000 and SecuwayCard 2000 provides the
End-to-End total security solution from sender to receiver.
SecuwayCard 2000 provides Network communication security
service that encrypts/decrypts the network packet using key management
method based on IPSEC. SecuwayCard 2000 also gives you the
hardware security token function that encrypts/decrypts the hard disk,
floppy disk and booting restriction program which allows only authorized
user to use the system from booting. The booting restriction program is
optional part and you can install it regardless of SecuwayCard 2000.
SecuwayCard 2000 have the security policy and the key received
from SecuwayCenter 2000 administrator. SecuwayCard 2000
uses the key and security policy for network communication. You can use
the security function easily without any other operation because it is
provided automatically only by installing the PCMCIA card on the
computer with which you use the SecuwayCard 2000.
SecuwayCard 2000 can be easily installed and used transparently
not only on the Desktop PC but also Note PC because its hardware is
provided with the type of PCMCIA card.
1-2 Chapter 1
SecuwayCard 2000?
SecuwayCard 2000
Features
SecuwayCard 2000 has the following features.
Obey the IPSEC
SecuwayCard 2000 obeys the IPSEC(Internet Protocol Security)
while doing the TCP/IP communication. And so, the user can send the
encrypted data safely to the destination when using the application.
Communication data encryption
SecuwayCard 2000 consists of AH(Authentication Header) and ESP
(Encapsulated Security Payload). AH authenticates the sending place of IP
packet and check if the packet is transformed illegally or not. ESP provides
the security service by encrypting the packet data.
PCMCIA type of security token
SecuwayCard 2000 provides with the transparency on the user
security circumstances and is easily installed and used on the Desktop PC
or Note PC that has PCMCIA card reader because its hardware is provided
as PCMCIA type of security token.
File/Folder Encryption/Decryption
If you log on the SecuwayCard 2000 Manager program, you can
encrypt or decrypt the file or folder on the Windows Explorer without
running any other program. You can select the way to encrypt or decrypt
the file or folder between the “Password Method Encryption” and “Auto
Encryption”. “Auto Encryption” is the way to use the key received from
SecuwayCenter 2000 for encrypting or decrypting the file or folder.
1-3
Various password algorithm/authentication algorithm
SecuwayCard 2000 adopts various password algorithm and
authentication algorithm while doing the network communication.
System locking function using screen saver
SecuwayCard 2000 provides the system locking function as running
the screen saver if you leave the computer or do not input any other keys
in restricted time. If the screen saver is running, you can use the system
only after successful authentication using the permitted password.
Various interfaces
You can set the SecuwayCard 2000 user interface in 3 ways by
cooperating with the SecuwayCenter 2000. If you want to hide the
setting status of the SecuwayCard 2000 from the user, you can
select the item that has no user interface on the SecuwayCenter
2000 and send it online.
TamperProof hardware security
If unauthorized user takes apart the SecuwayCard 2000 hardware or
tries to access to the memory, the password algorithm, key for
encryption/decryption and other security information saved in
SecuwayCard 2000 is deleted automatically to protect from leaking
information.
Log saving function
The user executing circumstances of the SecuwayCard 2000
Manager program is saved on the log and so the manager can easily
monitor or track the system.
2-1
Chapter 2 Before Setting Up the
SecuwayCard 2000
This chapter tells you the system requirements to set up the
SecuwayCard 2000 and some notices you should know before
setting up the SecuwayCard 2000.
System Requirements
The system requirement to setup the SecuwayCard 2000 is like the
following.
!" 486 Mhz CPU or higher PC
!" Windows 95, Windows 98, Windows Me (Installed in PC)
!" Networking environment using Microsoft TCP/IP protocol stack
!" Desktop PC or Note PC installed with PCMCIA card reader
If you use Note PC, you can install the SecuwayCard 2000 in
your Note PC without installing any other application program
because PCMCIA card reader is already installed in Note PC
basically. If you use Desktop PC, you should install the PCMCIA
card reader program before installing the SecuwayCard
2000 because PCMCIA card reader is not installed in Note PC
basically.
2-2 Chapter 2
Before Setting Up the SecuwayCard 2000
Checking the contents of the package
When you unpack the SecuwayCard 2000 package box, you can find
out the following things in the box. If any of them is not in the box or there
is anything to be changed because it is damaged, contact to the dealer.
!" SecuwayCard 2000 card (PCMCIA type)
!" SecuwayCard 2000 program CD that contains the
SecuwayCard 2000 manager program.
!" This guide
3-1
Chapter 3 Setting Up the SecuwayCard
2000
This chapter shows you the way to install the hardware and software of the
SecuwayCard 2000.
Installing the
SecuwayCard 2000
in the
computer
Let’s see the way to install the SecuwayCard 2000 in the Note PC or
Desktop PC.
Installing the SecuwayCard 2000 in the Note PC
If you are to install the SecuwayCard 2000 in the Note PC, follow
the steps below
This guide describes the way to install the SecuwayCard
2000 in the Note PC in which Windows Me operating system is
installed as an example.
#Insert the SecuwayCard 2000 in the PCMCIA card slot of Note
PC while the power of Note PC is off.
$Turn on the power of Note PC and then the Windows Me operating
system shows you the following message after finding out the
SecuwayCard 2000 as the new hardware.
3-2 Chapter 3
Setting Up the SecuwayCard 2000
%In a few seconds, the installation process for the SecuwayCard
2000 driver is started.
Select the “Automatic search for a better driver(Recommended)” and
click [Next>] button.
&After the operating system find out the driver for SecuwayCard
2000 on the CD-ROM and then the following message is displayed.
If you click [Next>] button, then the installation process of the
SecuwayCard 2000 driver is started.
