Fysic FM-8800+ Bedienungsanleitung
User Manual
FM-8800+
2
1 OVERVIEW
1: Shortly press to activate camera functions.
Hold key press to activate flashlight.
2: Display
3: Hold to open the menu screen.
also functions as delete or cancel-key when
changing settings or programming
4: Phone ON key, for dialling numbers or taking
incoming calls
also functions as OK-key when changing settings or
Num
mm e r
123
7
56
4
89
0
ABC DEF
GHI JKL MNO
PQRS TUV
WXYZ
3
programming
5: Keypad
6: Hold to lock keyboard
7: Power line input (underneath phone)
8: Connector for headset (underneath phone)
9: Gap for clip attachment (underneath phone)
10: Hold to change between ‘Standard’ and ‘Conference’
profile settings.
(please view chapter 10.7)
11: Phone OFF-key, to stop a converstation. Also used
to cancel any action when changing settings or
programming
12: Wheel for selection of memories or settings.
13: Press shortly to activate the radio function
Hold to activate the sound amplifier
14: Internal speaker
15: Flashlight
16: Emergency key, Hold for 2 seconds to dial the
programmed emergency number
(please view chapter 5.2 for information on
programming emergency numbers.)
17: Built in speaker for ringer tones
18: Battery cover
19: Camera-lens
20: Slide in top position: Use camera for photography
Slide in bottom position: Use camera for
magnification of near objects or text.
4
2. PREPARATION & INSTALLATION
2.1 Placing the SIM-card and battery:
a. Slide the battery cover down and remove
it from the phone.
b. Place the SIM card; attention: the SIM
card only fits inside the socket when
angled correctly. Do not force the card
into place
c. place the battery;
attention: the battery
only fits inside the
socket when angled
correctly. Do not
force the battery
into place
d. Slide the battery
cover back into place.
2.2 Charging:
a. Plug the charger connector
into the bottom of the phone
b. Plug the charger into the electrical outlet. Charge
the phone for at least 15 hours before use.
5
3. Basic Operation
3.1 Turn Your Device On / Off
Press and hold the phone off key for about
3 seconds to turn your device On/ Off.
3.2 PIN-code, PUK-code and telephonecode:
When the phone turns on, it is possible you
are asked for a PIN-code. Enter the PIN-
code of the SIM-card and confirm with
the
key.
You are allowed up to 3 attempts to enter
the correct PIN-code. If 3 incorrect
PIN-codes are entered, the SIM-card will be
locked and can only be unlocked when a PUK-code is
entered. This PUK-code should be noted in the documen-
tation received together with the SIM-card.
If you have locked the phone itself with a
code as well, the phone code will be asked
after the PIN-code. Please view chapter
10.10.
Press the
key to confirm the entered
code.
PIN
CODE
TELEPHONE
CODE
PUK
CODE
6
3.3 Menu:
Programming the phone and changing settings is
done using the menu.
Open the menu by pressing & holding
the MENU key for 2 seconds.
3.4 Wheel:
The wheel on the right side of the phone can be
pushed upward, downwards and can be pressed.
Push up -and downwards on this wheel to navigate
memories and settings.
Pressing the button is equeal to pressing the key
in several situations.
2 sec
7
3.5 OK, BACK or CANCEL:
When changing the settings of various functions,
the following symbols may appear on the bottom of
your display:
, and . These symbols indicate
the function of the keys directly below these symbols
Press the key to
confirm your input or
choice ( )
Press the key to
delete you last input
() or to go one step
backward in the menu
Press the key
to cancel you current
action ( )
Num
mm e r
123
7
56
4
89
0
ABC DEF
GHI JKL MNO
PQRS TUV
WXYZ
8
4 DIALLING
4.1 Dialling a number:
1. Press number keys to enter the telephone number,
and then press the phone ON key.
4.2 Answering incoming calls:
1. Press the phone ON key to accept the call
(press the phone OFF key to refuse the call)
4.3 Handsfree:
1. Press the
key twice during a call to activate
the handsfree-function
2. Press the key twice once more to deactivate
the handsfree function.
4.4 Ending a call:
1. Press the phone OFF key to end your current
conversation.
4.5 Dial from memory:
1. Use the wheel to choose the desired number
2. Press the key to confirm your selection.
4.6 Quickdial:
1. Press the desired key 1x (2~9) and press the
phone ON key, the number will be dialled
9
5 Emergency Number
5.1 Introduction:
It is possible to program a phone number that will be
dialled after the emergency button has been pressed
for over 2 seconds.
This number can be any emergency number, but
also personal numbers of family or friends.
5.2 Programming:
Select the option ‘Emergency Call’ and enter the
telephone-number to be dialled in an emergency
sitation under the option ‘Emergency Number’.
The option ‘Delay’ can be used to set the delay-time
(3, 5 or 8 seconds) before the number will actually be
dialled. During this delay time, the call can be
aborted by pressing the phone OFF key.
5.3 Using alarm function:
Press and hold the alarm button for
2 seconds. The display will now start a
countdown according to the delay time
set. For the call itself, you do need to
hold the phone to your ear or use a
headset.
alarm key
Num
mm e r
1
2
3
7
56
4
89
0
ABC DEF
GHI JKL MNO
PQRS TUV
WXYZ
10
6 FLASHLIGHT
6.1 Introduction:
The FM-8800 has a helpful
flashlight to help light dark rooms
when needed.
6.2 Turn on or off:
Press and hold the
camera key for over 1
second to switch the light
on or off.
7 RADIO
1.plug in an earphone
2.press the radio/amplifier-key
shortly, the radio function will
be activated and can be
listened to through the
earphones.
3.Use the wheel to change the
radio channel
Please view chapter 10.9.
4.Press the key twice to
deactivate the radio function.
flashlight
hold over
1 second.
Num
mm e r
1
2
3
7
56
4
89
0
ABC DEF
GHI JKL MNO
PQRS TUV
WXYZ
shortly press
change channel
Num
mm e r
1
2
3
7
56
4
89
0
ABC DEF
GHI JKL MNO
PQRS TUV
WXYZ
