G-Systems 16A Bedienungsanleitung

User manual 16Aventilation controller 16A

Version: 1:00:00

Date: 27/06/16

Approved for: All

Created by: G-Systems ngineering Ltd

Table of Contents

User manual 16Aventilation controller 16A ...........................................................................1

Introduction Foreword:.......................................................................................................2

Technical specifications:....................................................................................................2

Assembly:..........................................................................................................................2

Operation of the keypad: ..................................................................................................2

Description of the elements:..............................................................................................4

Menu structure:..................................................................................................................5

Function diagram:..............................................................................................................6

Menu functions:..................................................................................................................7

Main screen part 1.........................................................................................................7

Main screen part 2.........................................................................................................7

Main screen part 3.........................................................................................................7

Main menu:........................................................................................................................7

Submenu ventilator settings:.........................................................................................8

Settings of switched outputs XIT1: ...............................................................................10

Disabled:......................................................................................................................10

Output Sensor 1 heat:.................................................................................................10

Output sensor 1 cool:...................................................................................................11

Output sensor 1 humidify/moisturise:..........................................................................11

Output sensor 1 dehumidify/drying; Output sensor 2 heat; Output sensor 2 cool:.....11

Output 1 timer:.............................................................................................................11

Settings of switched outputs XIT2:................................................................................12

Submenu general settings:..............................................................................................12

Time and date settings:...............................................................................................12

Language settings:......................................................................................................13

Light sensor settings:...................................................................................................13

LCD Display settings:..................................................................................................13

Alarm settings:.............................................................................................................13

Recording of historical data (Only for model with USB recording):.............................14

Reset to factory settings:.............................................................................................14

page 1 of 15

Introduction Foreword:

Thank you that you have chosen the G-Systems ngineering Ltd 16A fan controller

product.

The 16A fan controller is a climate controller which can measure the air temperature

humidity and water temperature. The controller integrates several measurements

simultaneously and continuously controls devices such as intake- and exhaust fans and 2

switched channels can be individually and user definied programmed on / off. The 16A fan

controller controls based on the measurement data all functions, depending on the model

saves all setpoints and actual values to an external USB memory stick in a .csv format

(comma-separated values). These values can be evaluated on a computer at a later time,

or with the free of charge GS Growthanalizer software.

Technical specifications:

Operating voltage: 230V / 50Hz

Depending on the country the maximum power rating of the power-cord is variable:

VD L typ max: 16A, Schuko

VD F type max: 16A, France

VD type max:13A, Switzerland

VD U type max 13A, ngland

Loading of the individual outputs:

Intake fan max: 10A 2300W cos 1

xhaust fan max : 10A 2300W cos 1

xit 1 max: 10A 2300W cos 1

xit 2 max: 10A 2300W cos 1

The sum of all the currents can not exceed prescribed maximum current of the country

socket!

Assembly:

Mount the 16A fan controller with the included mounting bracket to a non-flammable

surface such as brick concrete and never on wood, plastic carboard, etc. Make sure that

on your choice of the place have sufficient ventilation in the location and the heat can be

dissipated. Avoid small unventilated rooms or cabinets. Improper installation will result a

overheating of the controller!

Operation of the keypad:

The controller is operated by four menu keys.

With the arrow keys UP and DOWN the various menu lines can be selected. Press

page 2 of 15

NT R to go one level deeper into the submenu and SAV / XIT one level back.

If settings get changed with the two arrow keys you don't have to confirm with NT R, the

values get stored with SAV / XIT

! All values get stored in an internal memory and are also after a power failure or

prolonged disconnection available. Time and date have a back-up capacitor which runns

about 72 hours. After this time they have to be setted again.

page 3 of 15

Description of the elements:

1. Connection for exhaust fan

2. Connection for intake air fan

3. Programmable exit 1

4. Programmable exit 2

5. Temperature L D

6. xit 1 L D

7. Humidity L D

8. Day / night L D

9. Alarm L D

10. xit 2 L D

11. UP arrow

12. DOWN arrow

13. SAV / XIT

14. NT R

15. Powersupply

16. Sensor cable for temperature and humidity (only gases)

17. Sensor cable for temperature (liquids and gases)

18 LCD display with 2x16 characters

19 USB L D

20. USB port

page 4 of 15

Menu structure:

page 5 of 15

Function diagram:

page 6 of 15

Menu functions:

Navigate the main menu with the UP / DOWN buttons.

Main screen part 1

Temperature T1 ° C Shows the measured in ambient air temperature.

Humidity in RH Shows the measured in the room relative humidity.

Temepratur T2 in C ° Displays measured in the water temperature.

Time Displays the current time in hours and minutes.

Main screen part 2

Fanspeed 1 shows in% the fan speed of the exhaust air fan.

Fanspeed 2 shows in% the fan speed from the supply air fan.

Main screen part 3

Alarms of the exceeded maximum values.

T1 = Temperature sensor 1 max.

RH = Humidity sensor 1 max.

T2 = Temperature sensor 2 max.

Alarms of underrun minimum values.

T1 = Temperature sensor 1 min.

RH = Humidity sensor 1 min.

T1 = Temperature sensor 2 min.

Confirm with the SAV / XIT button an alarm. The 9. alarm L D will switch off should the

actual value be below the set value. Depending on the model there is located a dry contact

in the inside the 16A controller. This contact is closed on alarm.

Main menu:

Go with the NT R button one level deeper into the menu. Here is a selection of the four

main menu items.

1. Set fan settings = Ventilator settings

2. Set exit 1 = Output setting of exit 1

3. Set exit 2 = Output setting of exit 2

4. General settings = General Settings

page 7 of 15

Mainscreen 1

T1=23.4C° RH=60%

T2=19.1C° 09:13

Fanspeed 1 90%

T1--- T2--- H---

Fanspeed 2 70%

T1--- T2--- H---

Scroll with the UP / DOWN keys to receive the downward hiden records.

The function to select is displayed flashing. Press the NT R key to select and to get into

the submenu.

Submenu ventilator settings:

Here you find all settings for both fans-outputs " xhaust fan" and "Intake fan" exhaust fan

on the left and right supply air fan. On AC fans can be loaded max 2200W per output,

depending on the country and plug type, but you can connect a maximum of 3600W total

load. Depending on model you have, there are in the inside of the 16A controller 2 outputs

for C-fan 0-10V and PWM signal paralel connected to the AC socket.

1. Set temperature = Temperature setting

2. Set humidity = Humidity setting

3. Fan settings = Ventilator Setting

Scroll with the UP / DOWN keys to display the below information.

1. Fan day = Ventilation day

2. Fan night = Ventilation night

3. Hysteresis = hysteresis

What is hysteresis? Hysteresis refers to the value between the lowest and the highest

value of the controlling range.

xample: We set the temperature to 25°C with a hysteresis of 2°C. The fan starts from

25°C to controll and reaches the maximum speed + 2°C hysteresis at 27°C. In this 2°C

hysteresis of 25°C to 27°C, the fan speed changes linearly according the temperature

difference.

The function to select is displayed flashing. Press the NT R key to select them.

page 8 of 15

Set fan settings

Set e it 1

Set e it 2

Generl settings

Set temperature

Set humidity

Fan settings

Select the desired setting, which you like to change, e.g. "Vent. Day. " Now, the value

starts flashing which can be changed with the UP DOWN buttons. Press once to change

by 0.1 or hold the button to change the value fast. If you have set the desired value, save

the new setting with the SAV / XIT button.

Repeat this procedure to change all other values in the menu.

With the SAV / XIT button to return back to the sub menu fan settings. Repeat this

procedure for the humidity setting. The third setting you can find the fan settings. Under

this sub menu, you get the following settings:

1. Minimum speed = Minimum speed setting (exhaust fan)

2. Maximum speed = Maximum speed setting (exhaust fan)

3. Negativepressure = Negative pressure setting (intake air fan)

Here you can set the minimum and maximum speed of the exhaust fan. These values will

never be exceeded in day and night mode and are always the same. The supply air fan

don't have a minimum speed value and will turn off when the temperature and humidity

undercuts the set value. By setting of the minimum speed value at the exhaust fan you

avoid odours escape through small openings in the room. By setting the maximum speed

value you avoid the fans making to much noise on full load. The third setting you have the

negative pressure, this setting reduces the intake fan speed according the value of the

exhaust fan speed and work synchrony together. For example: If we set a -20% negative

pressure, the exhaust air fan operates at full load 100%, the intake fan will have 80%. The

xhaust fan removes more air from the room as the intake fan blows inside and you obtain

a guaranteed negative pressure during the regulation. If the exhaust fan runs at 50% then

the intake air fan runs at 40%. -20% of its power. You can see this current ratio in the main

page 9 of 15

Fan day 22.8C°

Fan night 20.3C°

Hysteresis 2.5C°

Sub menu fan setting

Set temperature

Set humidity

Fan settings

Minimum speed

Ma imum speed

Negativepressure

Fan1 10%

Fan1 100%

Fan2 -50%

screen part 2.

Settings of switched outputs XIT1:

In the main menu you find “Set exit 1” = Settings output exit 1. Push the NT R button to

get one level deeper into the menu. Than push again to “choose function”. The following

functions are available:

x = disabled = Output disabled

x = T1 heat = Output sensor 1 heat

x = T1 cool = Output sensor 1 cool

x = Rh humidify = Output sensor 1 humidify/moisturise

x = Rh dehumidi = Output sensor 1 dehumidify/drying

x = T2 heat = Output sensor 2 heat

x = T2 cool = Output sensor 2 cool

x = timer = Output timer

Scroll with UP / DOWN buttons to the desired function and confirm with NT R. If a

function has already been selected, you can use "set value" to change the values. If you

like to switch to another function, select the new function in"Set exit 1". Change the values

or confirm the new function with the SAV / XIT button.

Disabled:

This function turns off the output.

utput Sensor 1 heat:

This function is measuring the air temperature and can be to connected a heater. In the

submenu you can make the following settings:

page 10 of 15

Choose function

E 1= S1 heat

E 1= S1 cool

E 1= S2 humidify

E 1= S2 dehumidi

E 1= S3 heat

E 1= S3 cool

E 1= timer

E 1= disabled

E it 1 Sensor 1

Heat day 24.0C°

Heatnight 24.0C°

Hyst. -02.0C°

Inhaltsverzeichnis

Andere G-Systems Controller Handbücher

G-Systems

G-Systems GSE AC-EC Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
