G-Technology G SPEED eS PRO Bedienungsanleitung

G SPEED

PRO

™

High-Performance RAID Solutions for HD/2K Production

PRODUCT MANUAL

g-technology.com

p.2

Table of Contents

G SPEED

PRO

™

Table of Contents

Safety & General Use

Safety Precautions.........................................4

Backup Your Data ..........................................5

About Your G-SPEED eS Pro

Introduction ....................................................7

What’s in the Box ..........................................8

System Requirements..................................8

Overview of the Drive .................................9

Overview of the Controller .......................9

Using Your Drive

Drive LED Operation.....................................11

Warning LED and Alarms............................11

Disconnect the Drive ...................................12

Windows Use...................................................12

Using ATTO R680 RAID Controller

Download ATTO RAID Software...............14

Install ATTO Driver & CongTool .............14

Install ATTO Controller.................................15

Attach eS Pro to ATTO Controller.............15

Add Second G-SPEED eS Pro Unit............16

Uninstall ATTO Driver & CongTool ........16

Table of Contents

Conguring G-SPEED eS Pro

RAID Conguration Scripts for Mac........18

Use the ATTO CongTool............................19

Change the RAID Mode...............................21

Congure Two RAID Units..........................26

Set Up Alert Notications...........................31

Maintenance for your Drive

Replace a Failed Disk Drive ........................33

Initialize Drive for Mac ................................36

Restore the Drive Icon .................................39

Reformat with Partitions.............................41

Appendix

RAID Levels Explained .................................46

Support & Warranty

Technical Support .........................................48

Limited Warranty ...........................................49

Table

G SPEED

PRO

™

Safety & General Use

• Safety Precautions ................................................................ p.4

• Backup Your Data ................................................................. p.5

p.4

Safety & General Use

G SPEED

PRO

™

Safety Precautions

G-SPEED eS Pro’s warranty may be void as a result of the failure to respect the precautions listed here. If

you detect a problem with your drive, please contact our Technical Support department.

If the product is returned with damage caused by improper handling, the warranty will

be void and liability will rest with the user. Please read our Limited Warranty.

• Servicing: Your drive contains no user-serviceable parts. If it appears to be malfunctioning,

have it inspected by a qualied Technical Support representative.

• Moisture: Place the device away from moisture or liquids. To reduce the risk of damage, do

not expose this drive to rain or moisture. Do not use it in damp or wet conditions. Never place

objects containing liquids on the drive as they may spill into its openings.

• Ventilation: Place the device in a vented area. The drive should never be placed near

or over a radiator or heat source.

• Temperature: Do not expose this drive to temperatures outside the range of 5°C to 35°C (41°F to 95°F);

or to operational humidity beyond 5-80%, non-condensing, or non-operating humidity beyond 10-90%,

non-condensing. Avoid placing your drive near a source of heat, or exposing it to sunlight (even through

a window), or in an environment that is too cold or humid.

• Physical Damage: Do not place heavy objects on the drive. Never use excessive force

on your drive.

health

p.5

Safety & General Use

G SPEED

PRO

™

Backup Your Data

The disk drive contained in your G-SPEED eS Pro device is a delicate electronic instrument

and is susceptible to damage due to excessive physical shock. Under no circumstances

will G-Technology be held liable for the recovery or restoration of lost data. Any loss, corruption

or destruction of data while using a G-Technology drive is the sole responsibility of the user.

Make Two Backups

To help prevent the loss of your data, we highly recommend that you keep TWO copies

of your data in separate storage locations. When in RAID 1, 5 or 6 (Protected mode),

G-SPEED eS Pro will safeguard your data from hard drive failure. However, if any le

system corruption occurs, the data contained on G-SPEED eS Pro may be aected.

For critical data, it is recommended to keep one copy on G-SPEED eS Pro and a second copy on

another storage device.

backup

G SPEED

PRO

™

About Your G-SPEED eS Pro

• Introduction ............................................................................ p.7

• What’s in the Box .................................................................. p.8

• System Requirements ........................................................... p.8

• Overview of the Drive ......................................................... p.9

• Overview of the Controller ................................................ p.9

p.7

About Your G-SPEED eS Pro

G SPEED

PRO

™

Introduction

Thank you for purchasing G-SPEED eS Pro from G-Technology.

Specically designed for professional content creation applications, G-SPEED eS Pro

features a high-speed mini-SAS interface. The storage system provides RAID 0, 1, 5, 6 and

JBOD functionality when used in conjunction with the ATTO ExpressSAS R680 PCIe mini-

SAS RAID controller.

Two G-SPEED eS Pro units can be attached to the ATTO R680 RAID controller for incredible

performance.

intro

p.8

About Your G-SPEED eS Pro

G SPEED

PRO

™

What’s in the Box

The following items are included in the box:

• G-SPEED eS Pro storage system

• 4 removable SATA drive modules (installed in unit)

• (2) disk module keys

• 2-meter mini-SAS cable

• AC Power cable

• Quickstart Guide

Optional purchase: ATTO R680 PCIe x8 RAID controller

If any items are missing, please contact G-Technology at

support@g-technology.com or call (888) 426-5214.

Download the latest G-SPEED eS Pro manual and ATTO software at:

www.g-technology.com/support/gspeed_es_pro/

System Requirements

G-SPEED eS Pro and the ATTO R680 RAID controller support the folllowing Operating

Systems. The drive is set up at the factory for use with Mac OS® X systems, and format-

ted as‘HFS+’.

• Mac OS 10.5 or higher

• Windows XP, Vista or Windows 7

NOTE: The ATTO CongTool makes it possible to create RAID groups up to 16TB that

are compatible with Windows XP. For more information, please refer to the chapter

Using ATTO R680 RAID Controller.

inbox

p.9

About Your G-SPEED eS Pro

G SPEED

PRO

™

Overview of the Drive

G-SPEED eS Pro ships from the factory congured in RAID 0 for use with the ATTO R680

RAID controller. The RAID controller also supports RAID 1, 5, 6 and JBOD congura-

tions. If you wish to change the RAID mode, please refer to Change the RAID Mode.

For an explanation of supported RAID levels, please refer to RAID Levels Explained.

(4) Removable disk

drive modules

Drive Lock key hole

Drive module

Power/Activity LED

Power LED

Temperature/Fan

Warning LED

Alarm Mute button

mini-SAS port

Kensington lock

AC inputON/OFF Switch

‘Smart’cooling fans

PCIe x8 interface

(2) High-speed

mini-SAS ports

Overview of the Controller

The ATTO R680 RAID controller connects your G-SPEED eS Pro to a Mac or

Windows workstation, and also provides RAID 0, 1, 5, 6 and JBOD functionality.

Download the latest ATTO software at:

www.g-technology.com/support/gspeed_es_pro/

overview

G SPEED

PRO

™

Using Your Drive

• Drive LED Operation ......................................................... p.11

• Warning LED and Alarms ................................................ p.11

• Disconnect the Drive ......................................................... p.12

• Windows Use ........................................................................ p.12
