Gainward GTS 450 512MB Bedienungsanleitung

Gainward GTS 450 512MB DVI HDMI

GPUCoreMemoryCapacityTypeOutputs

GTS450783MHz1804MHz512MBGDDR5/128bitsDVI,VGA,HDMI

PRODUCT SPECIFICATIONS

zSuperior Hardware Design

zGainward’s award winning High-

Performance/ Wide-BandwidthTM hardware

design powered by NVIDIA’s GeForceTM GTS

450 GPU (40nm) integrating 512MB/128bits

high-speed GDDR5 memory which offers

enhanced, leading-edge performance for the

3D enthusiasts.

z783MHz core clock, 1804MHz (DDR 3608)

memory clock.

zHigh performance 2-slot cooler.

zDVI (resolution support up to 2560x1600),

VGA and HDMI support.

zFull integrated support for HDMI 1.4a

including xvYCC, Deep color and 7.1

digital surround sound.

zDual-link HDCP Capable: Designed to

meet the output protection management

(HDCP) and security specifications of the

Blu-ray Disc formats, allowing the

playback of encrypted movie content on

PCs when connected to HDCP-compliant

displays.

zSupports two monitors simultaneously,

enabled by the NVIDIA nView™Multi-

Display Technology for office applications,

3D gaming and professional applications

such as CAD, DTP, animation or video

editing. NVIDIA nView™allows end-users

to select any combination of multiple

displays.

CHIPSET SPECIFICATIONS

zNVIDIA GeForceTM GTS 450

zMicrosoft DirectX 11 Support: DirectX 11

GPU with Shader Model 5.0 support

designed for ultra high performance in the

new API’s key graphics feature, GPU-

accelerated tessellation.

zNVIDIA PhysXTM:Full support for NVIDIA

PhysX technology, enabling a totally new

class of physical gaming interaction for a

more dynamic and realistic experience with

GeForce.

zNVIDIA 3D VisionTM Ready: GeForce GPU

support for NVIDIA 3D Vision, bringing a

fully immersive stereoscopic 3D experience

to the PC. A combination of high-tech

wireless glasses and advanced software, 3D

Vision transforms hundreds of PC games

into full stereoscopic 3D. In addition, you

can watch 3D movies and 3D digital

photographs in eye popping, crystal-clear

quality.

zNVIDIA CUDATM Technology: CUDA

technology unlocks the power of the GPU’s

processor cores to accelerate the most

demanding system tasks such as video

transcoding, physics simulation, ray tracing

and more, delivering incredible performance

over traditional CPUs.

zMicrosoft Windows 7 Support: Windows 7

is the next generation operating system that

will mark a dramatic improvement in the way

the OS takes advantage of the GPU to

provide a more compelling user experience.

BUNDLED ACCESSORIES

•Gainward QuickStart Manual

•Driver CD and Application S/W

Driver for Windows 7/Vista/XP

•Cables and Accessories

Complementary Power Cable (option)

Gainward GTS 450 512MB DVI HDMI

zEasy Plug-and-Play AUTORUN

installation from CD-ROM.

zIncludes Gainward’s award winning

EXPERTool™ tuning utility for

customized performance enhancements

and efficient desktop management.

zNVIDIA GeForce Unified Driver

Architecture (UDA): Delivers a proven

record of compatibility, reliability, and

stability with the widest range of games

and applications. NVIDIA GeForce drivers

provide the best out-of-box experience for

every users and deliver continuous

performance and feature updates over the

life of NVIDIA GeForce GPUs.

zPCI Express 2.0 Support: Designed for

the new PCI Express 2.0 bus architecture,

offering the highest data transfer speeds

for the most bandwidth-hungry games and

3D applications, while maintaining

backwards compatibility with existing PCI

Express motherboards for the broadest

support.

By taking advantage of the GPU for both

graphics and computing, Windows 7 will not

only make today’s PCs more visual and

more interactive but also ensure that they

have the speed and responsiveness

customers want.

zDirectCompute Support: Full support for

DirectCompute, Microsoft’s GPU computing

API.

zOpenCL Support: Full support for OpenCL

GPU computing API.

z32x Anti-aliasing Technology: Lightning

fast, high-quality anti-aliasing at up to 32x

sample rates obliterates jagged edges.

zOpenGL 4.0 Optimizations and Support:

Ensures top-notch compatibility and

performance for OpenGL applications.

zPureVideoTM HD technology: The

combination of high-definition video decode

acceleration and post-processing that

delivers unprecedented picture clarity,

smooth video, accurate color, and precise

image scaling for movies and video.

zHardware Decode Acceleration: Provides

ultra-smooth playback of H.264, VC-1,

WMV, DivX, MPEG-2 and MPEG-4 HD and

SD movies without the need for a dual or

quad-core CPU.

Note: Gainward's bundle items are subject to

change. Please refer to your local Gainward

dealer for more information, or the

description in the regional product package

SYSTEM REQUIREMENTS

•Intel Core2Duo series, AMD Athlon 64 X2

series or above CPU

•Minimum of 2GB system memory

•Minimum 400W system power supply with

one 6-pin PCI Express supplementary power

connector

•DVD-ROM drive

•Requires a PCI Express 2.0 compliant

motherboard

•Requires a dual-width x16 graphics slot

•Windows 7/Vista/XP

API SUPPORT

•DirectX 11 in hardware

•OpenGL 4.0 support

OS SUPPORT

•Windows 7/Vista/XP

BAR CODE

•Large Box: 426018336-1503
