Contents

Box contents ............................................................... 1

Charging the baery ................................................... 2

Understanding the TW-Weighing Unit...................... 3

Installaon .................................................................. 4

Connecng equipment to the TW-........................... 6

Speciﬁcaons .............................................................. 6

First me start-up ....................................................... 7

Start a session............................................................. 8

View animal informaon........................................... 10

Care and maintenance.............................................. 11

Connecng the TW-to a computer ......................... 11

Approvals and standards........................................... 12

BOX CONTENTS

The Gallagher TW-box contains:

• Carry Bag

• TW-weighing unit

• 110V - 230V Mains AC adapter

• USB cable

• USB ﬂash drive

• 12V baery cable with alligator clips

• Mini Serial Adapter (2M1709)

• Mounng bracket and mounng hardware

TW-1

QUICK START GUIDE

Thank you for purchasing the Gallagher TW-Weigh Scale unit. The Gallagher

range of weighing systems is simple, tough, innovave and reliable.

BONUS OFFER

warranty to two years for free.

Follow these instrucons for the setup and ﬁrst use of the TW-.

Further informaon can be obtained by tapping when displayed on screen.

Gallagher TW-Weigh Scale Quick Start Guide

English

SPECIFICATIONS

Operang Temperature -20oto 50oC

-5oto 120oF

Environmental Protecon Rang IP67

Input Voltage 12 V DC

Esmated baery run me 16 hours at 60% brightness

12 hours at 100% brightness

CHARGING THE BATTERY

To ensure opmum performance of the TW-, the internal baery may need to be

charged for up to 16 hours before ﬁrst me use.

Important: If the TW-is to be stored for an extended period, this should be in

a cool dry place with a fully charged baery.

Always charge the baery indoors.

1. Connect the power adapter at the base of the unit and plug the TW-into a

power outlet and switch ON. The charging icon will display on the screen.

Warning: The power adaptor is intended for indoor use only. Do not expose to

rain or dampness.

2. When the charge shows 100% the TW-is ready to use with or without the

power adapter.

Note:

• When the TW-is in use, the baery icon

will display and show remaining charge.

• When using the scale and the charge level falls below 10%, the baery icon

will ﬂash with a red outline. You will have about 30 minutes to complete the

weighing session before the TW-must be charged. When the charge level

becomes crical the unit will shut down.

• To check remaining run me at current sengs, from the Home screen, go to

Sengs > About > Baery.

• The baery error icon will display if the baery is too hot (above +45oC)

or too cold (below 0oC). The Scale will keep operang while plugged in

but will not charge properly unl at room temperature.

Gallagher TW-Weigh Scale Quick Start Guide

English

UNDERSTANDING THE TW-1 WEIGHING UNIT

Footer bar detail

Loadbar connecons

USB port

(for memory sck)

Serial port

(mini adapter supplied to

change connector sex)

USB port

(connect to PC)

Baery charger

WiFi status

Bluetooth status Baery charge indicator

Weighing mode

AUTO - Automac weight lock

MAN - Manual weight lock

Touch Screen

Tap the screen icons,

ﬁeld names or buons

to view or enter data.

Weigh buon

Records animal weight

Zero buon

Sets the displayed

weight to zero.

Home Buon

Return to the

Home screen

Power buon

Turn TW-1 On/Oﬀ

Find animal

Look up and add animal to

a session

Backspace/DeleteChange mode from numeric

to alpha text entry Space bar

Navigaon keys

These buons can be

used to navigate the

funcons of the scale

as an alternave to the

touch screen.

Footer bar

On-screen Help

Touch to display

informaon about

the current screen

Remove animal

Weigh screen

Connecons

Gallagher TW-Weigh Scale Quick Start Guide

English

INSTALLATION

Installing the TW-

The TW-can be placed on a table top or mounted

on the bracket supplied.

Installing the Scale bracket

The bracket can be mounted on a ﬂat vercal surface, a round post, or a rail.

To mount the bracket on a ﬂat vercal surface, or a round wooden post, use

the 4 x tek screws included with the unit.

To mount the bracket on either a vercal or horizontal bar, use the ‘U’ bolts

included with the unit.

Important:

It is not recommended to mount the TW-bracket on the weighing crate or chute

as interacon with the scale can impair weighing performance.

Gallagher TW-Weigh Scale Quick Start Guide

English

Installing the loadbars

If using loadbars, follow these steps:

1. Select a weighing site that provides a solid, level and well drained surface.

2. Ensure the loadbars and plaorm are well secured and clear of any

obstrucons.

3. Either bolt the loadbars to the concrete pad or locate them on studs set into

the concrete. It is important that the loadbars and plaorm sit ﬂat without

any rocking or twisng to avoid weighing inaccuracies.

Note: It may be necessary to shim the loadbars or plaorm to ensure there

are no twisng pressures within the plaorm. Weights should be evenly

distributed over the top of the weigh bars.

4. Connect the loadbar cables to the TW-.

A beep will sound indicang a successful connecon/ disconnecon of the

loadbars.

WARNING – Do not weld the loadbars or any structure that they are

aached to. Loadbars contain sensive electronic devices which will be

damaged by welding. Damage caused by welding will void warranty.

Position the TW-:

• clear of the plaorm to ensure it does not interfere with the ﬂow of

animals during the weighing cycle

• within easy reach of the loadbar leads

• within easy reach of the operator (for manual weighing)

Gallagher TW-Weigh Scale Quick Start Guide

English

FIRST TIME START-UP

The ﬁrst me the TW-is powered on, the First Time Start-Up screen will display.

Tap the screen to update the language, me, date and weight ﬁelds as required

and then tap Save.

To change any of these sengs later, they can be accessed via Sengs on the

right of the Home screen.

For more informaon about this screen or any TW-screen, tap displayed in

the top right corner of the screen. This will display the On-screen Help with more

informaon about what you see on the screen.

Note: The navigaon keys on the keypad can be used at any me to select the

TW-1 funcons, as an alternave to the touch screen.

Auto Shutdown

When the TW-is leidle for more than 30 minutes it will automacally shutdown

to preserve the baery.

Press the Power buon to turn the unit back on.

Note: When the baery charger is connected, the TW-1 will not shutdown aer

the inacvity period. The screen will remain acve.

Gallagher TW-Weigh Scale Quick Start Guide

English

CONNECTING EQUIPMENT TO THE TW-1

Connecting to an EID Reader

The EID Reader can be connected to the TW-by either a serial cable or via

Bluetooth®.

1. Turn On the EID Reader.

2. Turn On the TW-.

3. On the TW-, tap Sengs > Equipment Connecons > EID Reader.

4. Select how the Reader is being connected, either via Bluetooth or using a

serial cable.

Note: A mini serial adapter is included with the TW-if a female serial

connecon is required.

Important: The TW-can also be connected to via Bluetooth as a “Slave”,

by iniang the connecon from the reader. A passcode of “0000” may be

required to complete this connecon.

Refer to Bluetooth – Connect EID Reader in the TW-1 On-screen Help or your EID

Reader User Manual for further informaon on pairing the reader.

Connecting to a Drafter/Sorter

To connect the TW-to a draer, use the data cables suppled with your draer.

Refer to your Draer User Manual for more informaon.

1. Turn On the TW-.

2. On the TW-, tap Sengs > Equipment Connecons > Draer.

3. Specify the type of draer that is being connected, to complete the setup.

If your draer is not listed, tap Create Custom and follow the conﬁguraon

wizard set up your draer.

Gallagher TW-Weigh Scale Quick Start Guide

English

START A SESSION

When you gather informaon about an animal, it is recorded in a Session. Each

event such as weighing, adds a record to the current session.

A template using pre-determined defaults can be set up and used each me you

start a new session.

Note: It is recommended a new session is opened for a new day’s acvity or for a

new group of animals. An animal cannot appear within the same session more than

once.

To start a new session:

1. From the Home screen, tap New . The New Session screen is displayed.

2. Tap Quick Start to open the Weigh screen with the scale default sengs.

Note: To set up and use templates, refer to the TW-1 On-Screen Help.

Important: Before weighing, 0.0 should be displayed. If not, press .

1. Load the animal onto the plaorm.

2. If required, you can record the animal’s Visual Tag Number or scan an

Electronic ID.

3. If weighing in AUTO - Automac weight lock, the scale will lock on to the

weight and hold it on the screen unl the animal leaves the plaorm.

If weighing in MAN - Manual weight lock, you must ﬁrst press Weigh .

When the weight becomes stable, it will lock.

4. Move the animal oﬀthe plaorm.

Important: If the weight displayed does not always return to 0.0 aer weighing,

check for dirt or manure that may have been leon the plaorm.

The TW-can be re-zeroed by pressing .

Reminder: For more informaon about this screen or any TW-screen, tap

displayed in the top right corner of the screen.

To customize the session:

click on the Opons buon

at the lower leof the

screen. Here you can set up

the weighing mode, draing

opons and name for the

session. Refer to Session

Opons (p. 9) for more

informaon.

Gallagher TW-Weigh Scale Quick Start Guide

English

Notes:

• When the weight locks, there will be a beep (if turned on in Sengs) and a

red light above the Weigh buon displays brieﬂy.

• Other informaon, for example: Notes, can be entered once the weight has

locked or an ID has been entered.

• In either mode, you can re-weigh an animal by pressing Weigh aer a

successful weight lock.

• If draing is turned on, the gate number and group will display, in top

right corner of the screen, indicang the draing category. Tap this box to

override the draing decision.

• By default the scale will automacally zero any debris leon the plaorm

between 2-5kg depending on the capacity of your loadbars. This can be

altered in the connected loadbar sengs.

Session Options

The Sessions Opons menu is used to conﬁgure sengs for the current session.

1. From this screen you can change the session name, turn draing On or Oﬀ,

change the weight lock mode and conﬁgure Advanced sengs.

2. Tap Save to keep any changes.

View the On-Screen Help for more informaon about each draing opon and

the Advanced sengs.

Gallagher TW-Weigh Scale Quick Start Guide

English

VIEW ANIMAL INFORMATION

The informaon collected during a session can be viewed from the session’s

Weigh screen.

To view informaon about

all the animals in the

session;

tap All Animals,

tap .

Tap to view weight range

of animals.

To view informaon about an

individual animal weighed;

tap .

Tap an animal VID to view this

animal on the Weigh screen.

Tap to view the history

of weights for the selected

animal, from the Weigh

screen.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Gallagher Skala Handbücher

Gallagher

Gallagher 026015 Bedienungsanleitung

Gallagher

Gallagher W310 v2 Bedienungsanleitung

Gallagher

Gallagher TWR-5 Bedienungsanleitung

Gallagher

Gallagher DS5000 Bedienungsanleitung

Gallagher

Gallagher DAIRY SCALE XDS5000 Benutzerhandbuch

Gallagher

Gallagher W210 Bedienungsanleitung

Gallagher

Gallagher TWR-1 Bedienungsanleitung

Gallagher

Gallagher SmartScale 700 Bedienungsanleitung

Gallagher

Gallagher TWR-5 Bedienungsanleitung

Gallagher

Gallagher W-1 Bedienungsanleitung

Gallagher

Gallagher W-1 Bedienungsanleitung

Gallagher

Gallagher SmartScale 600 Bedienungsanleitung

Gallagher

Gallagher W-0 Bedienungsanleitung

Gallagher

Gallagher W110 Bedienungsanleitung

Gallagher

Gallagher SmartScale 300 Bedienungsanleitung

Gallagher

Gallagher W810 Bedienungsanleitung

Gallagher

Gallagher SmartScale 800 Bedienungsanleitung

Gallagher

Gallagher W-0 Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
