ELECTRIC CERAMIC HOB
INSTRUCTION FOR INSTALLATION AND USE
Model: CH30BF
Model: CH60BF
Model: CH77BF
Model: CH90BF
Important! Read these instructions for installation and use carefully.
Keep these instructions for future reference.
Any questions regarding the operation, maintenance service or warranty
of the appliance should be directed to GASLAND, please contact us via
email at:
UK market: campluxuk@outlook.com
2
Safety Warnings
Your safety is important to us. Please read this information before
using your cooktop.
Installation
Electrical Shock Hazard
• Disconnect the appliance from the mains electricity supply before
carrying out any work or maintenance on it.
• Connection to a good earth wiring system is essential and
mandatory.
• Alterations to the domestic wiring system must only be made by a
qualified electrician.
• Failure to follow this advice may result in electrical shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Read these instructions carefully before installing or using this
appliance.
• No combustible material or products should be placed on this
appliance at any time.
• Please make this information available to the person responsible for
installing the appliance as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must be installed according
to these instructions for installation.
• This appliance is to be properly installed and earthed only by a
suitably qualified person.
• This appliance should be connected to a circuit which incorporates an
isolating switch providing full disconnection from the power supply.
• Failure to install the appliance correctly could invalidate any
warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked cooktop. If the cooktop surface
should break or crack, switch the appliance off immediately at the
3
mains power supply (wall switch) and contact a qualified technician.
• Switch the cooktop off at the wall before cleaning or maintenance.
• Failure to follow this advice may result in electrical shock or death.
Health Hazard
• This appliance complies with electromagnetic safety standards.
Hot Surface Hazard
• During use, accessible parts of this appliance will become hot
enough to cause burns.
• Do not let your body, clothing or any item other than suitable
cookware contact the Induction glass until the surface is cool.
• Metallic objects such as knives, forks, spoons and lids should not be
placed on the hob surface since they can get hot
• Keep children away.
• Handles of saucepans may be hot to touch. Check saucepan handles
do not overhang other cooking zones that are on. Keep handles out of
reach of children.
• Failure to follow this advice could result in burns and scalds.
Cut Hazard
• The razor-sharp blade of a cooktop scraper is exposed when the
safety cover is retracted. Use with extreme care and always store
safely and out of reach of children.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Never leave the appliance unattended when in use. Boil over causes
smoking and greasy spillovers that may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as
described in this manual (i.e. by using the touch controls).
• Do not allow children to play with the appliance or sit, stand, or climb
on it.
• Do not store items of interest to children in cabinets above the
appliance. Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the
appliance is in use.
• Children or persons with a disability which limits their ability to use
4
the appliance should have a responsible and competent person to
instruct them in its use. The instructor should be satisfied that they
can use the appliance without danger to themselves or their
surroundings.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans across the Induction
glass surface as this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to
clean your cooktop, as these can scratch the Induction glass.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
•This appliance is intended to be used in household and similar
applications such as: -staff kitchen areas in shops, offices and other
working environments; -farm houses; -by clients in hotels, motels and
other residential type environments ; -bed and breakfast type
environments.
•WARNING: The appliance and its accessible parts become hot during
use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
•Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
•WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire. NEVER try to extinguish a fire with
water, but switch off the appliance and then cover flame e.g. with a lid
or a fire blanket.
•WARNING: Danger of fire: do not store items on the cooking
surfaces.
• Warning: If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock, for hob surfaces of glass-ceramic or
similar material which protect live parts
5
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
Congratulations on the purchase of your new Ceramic Hob.
We recommend that you spend some time to read this Instruction /
Installation Manual in order to fully understand how to install correctly
and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this
Instruction / Installation Manual for future reference.
Product Overview
Top View (CH30BF)
Control Panel (CH30BF)
1. max. 2000 W zone
2. max. 1500 W zone
3. Glass plate
4. Control panel
1. ON/OFF control
2. Power / Timer regulating key
3. Key lock control
4. Heating zone selection controls
5. Timer control
6
Top View (CH60BF)
Control Panel (CH60BF)
Top View (CH77BF)
1. max. 1800 W zone
2. max. 1200 W zone
3. max. 1800 W zone
4. max. 1200 W zone
5. Glass plate
6. Control panel
1. Heating zone selection controls
2. Power / Timer regulating controls
3. Keylock control
4. ON/OFF control
5. Timer control
1. max. 2200W(1000W) zone
2. max. 1200 W zone
3. max. 2000W(1100W) zone
4. max. 1200 W zone
5. Glass plate
6. Control panel
7
Control Panel (CH77BF)
Top View (CH90BF)
Control Panel (CH90BF)
1. Heating zone selection controls
2. Timer control
3. Power / Timer regulating controls
4. Keylock control
5. ON/OFF control
6. Dual Zone
1. max. 1200 W zone
2. max. 2300/1600/800 W zone
3. max. 2000/1100 W zone
4. max. 1200 W zone
5. max. 1800 W zone
6. Glass plate
7. Control panel
1. Cooking Zone indicator
2. Timer Indicator
3. Power/Timer regulating controls
4. Triple zone control
5. Keylock control
6. ON/OFF control
7. Oval Zone control
8
Product Information
The ceramic cooker hob can meet different kinds of cuisine demands because of
resistance wire heating, micro-computerized control and multi-power selection.
It’s an ideal really the optimal choice for modern families.
Before using your New Ceramic Hob
•Read this guide, taking special note of the ‘Safety Warnings’ section.
•Remove any protective film that may still be on your ceramic hob.
Using the Touch Controls
•The controls respond to touch, so you don’t need to apply any pressure.
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin film of water may make the
controls difficult to operate.
Choosing the right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Always centre your pan on the cooking zone.
9
Always lift pans off the ceramic hob –do not slide, or they may scratch the glass.
Using your Ceramic Hob
To start cooking
•After power on, the buzzer beeps once, all the indicators light up for 1 second
then go out, indicating that the ceramic hob has entered the state of
standby mode.
1. Touch the ON/OFF control，all the indicators
show “-“
2. Place a suitable pan on the cooking zone that
you hope to use.
•Make sure the bottom of the pan and the surface
of the cooking zone are clean and dry.
3. For Model CH77BF-AU, CH77BF-US, CH60BF, CH30BF-US, touch Heating zone
selection controls first, and select a heat setting by touching the “-“or “+”control.
Then touch “-“or “+”to adjust the heating stage.
10
3. For Model CH90BF-AU, select a heat setting by touching
the “-“or “+”control. Then touch “-“ or “+”to adjust the
heating stage.
•If you don’t choose a heat setting within 1 minute,
the ceramic hob will automatically switch off.
You will need to start again at step 1.
•You can modify the heat setting at any time during cooking.
4. For model CH77BF-AU, CH77BF-US, CH90BF-AU that have dual zone or oval
zone, activating double zone by pressing ,
when double zone is working, turning double zone off
by pressing
5. For model CH90BF-AU that have triple zone, activating or deactivating
triple zone by pressing
When you have finished cooking
1. For Model CH77BF-AU, CH77BF-US, CH60BF, CH30BF-US, touch heating zone
selection controls first, and select a heat setting by touching the “-“control,
turn the cooking zone off by scrolling down to ”0”
Then touch “-“or “+”to adjust the heating stage.
1. For Model CH90BF-AU, turn the cooking zone off by scrolling down to ”0”.
Make sure the display shows”0”, then shows ”H”.
