Gatekeeper AI Betriebsanleitung

AI Dash Cam

User Operating Manual

Document Ref. No. : DN3515

Version No. : 1.1.0

Document Date : May 2023






of 51

TABLE OF CONTENTS
INTRODUCTION .............................................................................................................................4
1 AI DASH CAM DEVICE FRONT AND REAR VIEW .......................................................................................4
2 MICRO SD CARD ...........................................................................................................................7
3 WHAT’S INCLUDED .........................................................................................................................7
‘QUICK START’ GUIDE ....................................................................................................................8
1 STEP 1: POWERING THE AI DASH CAM ON AND OFF................................................................................8
2 STEP 2: IDENTIFYING THE AI DASH CAM NETWORK BROADCAST ID (SSID) ....................................................8
3 STEP 3: CONNECTING TO THE AI DASH CAM ..........................................................................................9
3.1 Step 3a: G4 Connect™...........................................................................................................9
3.2 Step 3b: Google Chrome –View IPC Interface...........................................................................9
VIEWING VIDEO WITH G4 CONNECT™.........................................................................................10
1 THE ‘GENERAL’TAB –YOUR DEVICE’S STATUS.......................................................................................11
2 THE ‘PREVIEW’TAB –VIEWING THE VIDEO ...........................................................................................11
3 THE ‘PLAYBACK’TAB –MANAGING RECORDED VIDEO .............................................................................12
3.1 Using ‘Video Export’ to export a video clip..............................................................................13
4 THE ‘PREFERENCES’TAB –CONFIGURING YOUR DEVICE ...........................................................................14
VIEWING VIDEO WITH GOOGLE CHROME (VIEW IPC) ..................................................................15
1 THE ‘PLAYBACK’TAB –MANAGING RECORDED VIDEOCLIPS.......................................................................15
2 THE ‘CONFIG’TAB –CONFIGURING YOUR DEVICE..................................................................................17
3 THE ‘LIVE VIEW’TAB –VIEWING VIDEO IN REAL TIME ..............................................................................17
4 THE ‘LOG’TAB –VIEWING AND MANAGING DEVICE LOGS ........................................................................18
AI DASH CAM ALARM SETTING ...................................................................................................19
1 REQUIREMENTS OF ADAS SETTING IN AI CALIBRATION ...........................................................................20
2 REQUIREMENT OF DSM SETTING IN AICALIBRATION ..............................................................................23
3 ADAS EVENT MONITOR ALARM TRIGGER STATUS .................................................................................24
4 DRIVER ALERT BUTTON:SETUP .........................................................................................................26
AI DASH CAM CONFIGURATION AND SETTINGS .........................................................................26
1 CONFIGURATION OVERVIEW ............................................................................................................27
2 DOWNLOADING DATA ...................................................................................................................38
AI DASH CAM INSTALLATION INSTRUCTIONS.............................................................................39
1 AI DASH CAM OPERATING CONDITIONS .............................................................................................39
2 MOUNTING THE AIDASH CAM ........................................................................................................39
3 POWER SUPPLY............................................................................................................................39
4 SENSOR CONNECTIONS..................................................................................................................40
5 CONFIGURATION ..........................................................................................................................40
WIRING INSTRUCTIONS...............................................................................................................40
1 CONNECTING THE POWER SUPPLY.....................................................................................................40
2 CONNECTING AN ADDITIONAL CAMERA...............................................................................................40

3 of 51

8.3 SENSOR CABLING .........................................................................................................................41

8.4CABLING DIAGRAM.....................................................................................................................42

9 CUSTOMER LIMITED WARRANTY.................................................................................................43

10 CONTACT INFORMATION...........................................................................................................45

APPENDIX .......................................................................................................................................46

11.1 REQUIREMENTS OF ADAS SETTING IN AICALIBRATION BY VEYES .............................................................46

11.2 REQUIREMENT OF DSM SETTING IN AI CALIBRATION BY VEYES ................................................................50

AI Dash Cam User Operating Manual

4 of 51

1 Introduction

The Gatekeeper Systems AI Dash Cam DVR is an AI based dashcam that helps drivers to

identify dangerous driving events and unsafe driving behaviors. It supports sending real-time

reminders to the drivers to avoid risks and uploads the events to fleet management platform

for driver training.

The default configuration of this dashcam comes with 2 built-in cameras, one camera is road

facing and provides ADAS (Advanced Driver Assistance System) functionality, the other

camera is interior facing and provides DSM (Driver Status Monitor) functionality to detect

driver's unsafe behaviors. This dashcam supports two additional cameras that can be

attached to the device. The resolution of the driver facing camera is 1080P, (1920*1080) and

the road facing camera resolution is 5MP, (2560*1920).

Video, audio, and metadata is recorded to two onboard, removable Micro Secure Digital (SD)

cards. These cards can be configured to loop record (Both cards participate in mainstream

recording to double the capacity), or the main SD card can be configured for main stream

recording and the secondary SD card can be configured for sub-stream recording, mirror

recording or alarm recording.

Data can be viewed and device settings can be configured, wirelessly using either Google

Chrome or Microsoft Edge web browsers, or through the ‘G4 Connect™’ software application

running on an Android compatible mobile device.

1.1 AI Dash Cam Device Front and Rear View

The Gatekeeper Systems AI Dash Cam DVR

video recording and management device.

1. Mounting plate

2. Speaker

3. Road and Driver facing cameras

4. Power

5. Alarm indicator

6. GPS antenna/receiver

7. Network

8. Wi-Fi transmitter / receiver

9. Recording

10. Driver Alert

11. Alignment set screw

AI Dash Cam User Operating Manual

5 of 51

Alarm Indicator

Name

Status description

Power indicator

OFF: Indicates power off

Green light always: Indicates power supply is normal

Alarm indicator

OFF: Indicates there is no alarm

Red light blinks three times: Indicates an alarm is generated

GPS antenna/receiver indicator

OFF: Indicates GPS is normal

Red light constant: Indicates the device location is abnormal (the

module is not located or connected, or the module is damaged)

Red light blinking (once per second): Indicates the GPS signal is poor

Network indicator

OFF: Indicates the device is connected to the server successfully

Red light always: Indicates the device fail to connect to the server

Wi-Fi transmitter/receiver indicator

OFF: Indicates the device is in disable or Client mode

Green light always: Indicates the device is in AP mode

Red light always: Indicates the WIFI is abnormal

Record indicator

OFF: Indicates the recording status of the built-in camera or

extended camera is normal

Red light always: Indicates the built-in camera or the extended

camera stop recording (including the private mode) or error

AI Dash Cam Technical Specifications

Video and Audio

Video Recording

4-Channel video

(Default: 2 channels; Extension: 2 channels) + 1-channel audio

Camera resolution

Configuration for 2 built-in cameras only:

Forward facing camera: 5MP @ 25 FPS

Driver facing camera: 1080P @ 25 FPS

Minimum frame rate for forward facing camera with ADAS: 20 FPS

Minimum frame rate for driver facing camera with DSM: 15 FPS

Configuration for 2 built-in cameras plus 2 additional optional cameras:

Forward facing camera: 5MP @ 20 FPS

Driver facing camera: 1080P @ 15 FPS

Optional AHD camera: 1080P @ 20 FPS

Optional IP camera: 1080P @ 10 FPS

Image Setting

Adjustable Brightness, Chroma, Contrast, Color Saturation, Sharpness

Video Coding

H.265 / H.264

Video Compression Bit Rate

500 Kbps –8 Mbps

Audio Compression Std

ADPCM, G.711, G.726. Default: ADPCM

Built in Speaker

Included, adjustable volume

Storage

Micro SD Card

2 x 64GB / 128GB / 256GB / 512GB

Camera Parameters of road facing camera (supports ADAS)

Sensor

1/2.7" 5M pixel CMOS Sensor

Electronic Shutter

1/30 Second - 1/100000 Second

Lens

Focal length: 2.8mm

AI Dash Cam User Operating Manual

6 of 51

S/N

≥48db

Lens mount

Built-in lens

Wide Dynamic Range (WDR)

Digital WDR

Backlight Compensation

Supported

Camera Parameters of driver facing camera (supports DSM)

Sensor

1/2.7" 5M pixel CMOS Sensor

Electronic Shutter

1/30 Second - 1/100000 Second

Lens

Focal length: 2.2mm

S/N

≥45db

Lens mount

Built-in lens

Wide Dynamic Range (WDR)

Digital WDR

Backlight Compensation

Supported

Infrared Lamp

Supported

Network

Wi-Fi

802.11 a/b/g/n 2.4GHz

Cellular

4G LTE

GPS

Built-in

Accelerometer

6-axis Sensor Included

Environmental Light Sensor supported

Ports

RS232

1- channel input

I/O Port

4- channel input

AV OUT

1 channel

USB

1 mini-USB port

Power

Power Supply

12 V~24 V nominal

Normal Power Consumption

7.56W

Peak Power Consumption

12.66W

Physical

Dimensions (L x W x H)

4.45” x 2.67” x 3.47” (113.0 mm x 67.8 mm x 88.2 mm)

Weight

295g

Environmental

Operating Temperature

-40°C ~ +70°C (-40°F ~ +158°F)

Humidity

15~95% non-condensing

Compatible Software

Category

G4 Viewer Plus, G4 Enterprise, G4 Connect

ADAS Event Monitor Specifications

Display

Diagonal Size (Inch)

1.4″

Resolution

128*128

Brightness

400cd/m²

Light Sensors

Support

Lenses

Glass

AI Dash Cam User Operating Manual

7 of 51

Communication Method

RS485

Buzzer

Built-in, no less than 80dB

Power Specifications

Power

5V-12V DC

Power Consumption

1.5W

Panel Interface

Connection Cable Length

3m/8m

Connector Type

Reserved interfaces for docking hardware

1.2 Micro SD Card

It is recommended that the AI Dash Cam uses Gatekeeper Systems Micro SD cards, in a

64GB, 128GB, 256GB or 512GB size format. Gatekeeper Systems Micro SD cards have been

manufactured and tested to perform at the widest range of temperature tolerances,

exceeding the performance of consumer grade Micro SD cards.

SD Card File Formatting: The AI Dash Cam uses a propriety file format and should not

be reformatted using a Windows operating system. If you encounter a prompt to reformat

the Micro SD Card (in a Windows environment), click CANCEL. Reformatting the SD Card will

delete all recorded data, and will require that the Micro SD card be re-formatted in the AI

Dash Cam format before video recording can occur.

1.3 What’s Included

The following items are included as part of your basic product package.

AI Dash Cam

This is the AI Dash Cam with ADAS and

DSM functionality

Power Supply Box

(CAB000545)

This is the vehicle power ignition cable for

powering the AI Dash Cam and connecting

ADAS Event Monitor or Driver Alert.

Flying Lead Cable

(CAB000547)

This is the flying leads cable for connecting

power and its connected accessories.

AI Dash Cam User Operating Manual

8 of 51

Windshield Mount

This is the Windshield Mount with 3M

adhesive to attach window.

Allen key and Crowbar

This is the Allen key for inserting SD card

and connecting USB cable.

Alcohol Pad

The is the 75% Ethyl Alcohol for disinfection

use.

2 ‘Quick Start’ Guide

The Quick Start guide is intended to get you up and running with your new AI Dash Cam

system and assumes that the device has been installed in your vehicle by a Gatekeeper

Installation Technician. If you prefer to mount the device yourself, please refer to the ‘AI Dash

Cam Installation Instructions’ section for detailed hardware and cabling instructions.

2.1 Step 1: Powering the AI Dash Cam On and Off

Turning on your vehicle ignition will power up the AI Dash Cam. Turning off your vehicle will

power down the device after a five-minute shutdown delay. (Note: The duration of the five-

minute shutdown can be modified using the device configuration settings.)

2.2 Step 2: Identifying the AI Dash Cam Network Broadcast ID (SSID)

Before a Wi-Fi connection can be established with the AI Dash Cam, you must first identify

the device’s network broadcast ID (or SSID). The default SSID is identified on the sticker

attached to the casing of your AI Dash Cam device. Make sure you have correctly identified

the SSID before proceeding.

AI Dash Cam User Operating Manual

9 of 51

NOTE: If your AI Dash Cam device fails to recognize your SSID (or the SSID

does not appear), please restart the device. The AI Dash Cam will stop

broadcasting its SSID after a two-minute interval if a device has not been

connected to it.

2.3 Step 3: Connecting to the AI Dash Cam

You can connect wirelessly to the AI Dash Cam in one of two ways. By using either;

▪The G4 Connect™application (‘app’) installed on any Android or iOS operating system

compatible mobile device (Recommended approach).

▪Google Chrome and Microsoft Edge web browsers on a Windows operating system device.

2.3.1 Step 3a: G4 Connect™

The G4 Connect app can be installed to an

Android device by downloading the app

through the ‘Google Play’ digital distribution

service (play.google.com)

Once the G4 Connect app is installed, start your vehicle to power on the AI Dash Cam. After

the Wi-Fi light turns green, using your Android device, search for the broadcast network ID

(e.g. 000035000AE6) from its Wi-Fi settings list, enter the password and connect to this

network. Refer to Step 2 if you are having problems identifying the correct broadcast network

ID.

Once you have connected your Android or iOS device to the AI Dash Cam, launch the G4

Connect app. When presented with a login screen supply the following credentials:

Username: admin

Password: admin

You are now successfully connected through the G4 Connect app and can begin using your

AI Dash Cam device. You can also choose the Remember option to easy log in in the future.

2.3.2 Step 3b: Google Chrome –View IPC Interface

AI Dash Cam User Operating Manual

10 of 51

Start your vehicle to power on the AI Dash Cam device. Using a PC or laptop with an active

Wi-Fi connection, search for and connect to your AI Dash Cam’s broadcast network ID (e.g.

000035000AE6). Refer to Step 2 if you are having problems identifying the correct broadcast

network ID.

Once connected, launch Google Chrome web browser. Note: Other browsers such as

Microsoft Edge are also support and may have compatibility issues when used with Gatekeeper

Systems devices.

From your Google Chrome web browser, type in one of the following IP addresses:

192.168.88.2 or 192.168.240.1

These default IP addresses will open the View IPC web interface to access your AI Dash Cam

device.

Once the IP address has been entered, supply the following login credentials:

User name: admin

Password: admin

You are now successfully connected through the Google Chrome View IPC interface and can

begin using your AI Dash Cam device.

3 Viewing Video with G4 Connect™

Connecting to the AI Dash Cam through the G4 Connect app is the recommended method

for viewing and managing data, and configuring the device. The G4 Connect app makes

navigating the AI Dash Cam’s functionality easy through its four tabs: ‘General’, ‘Preview’,

‘Playback’, and ‘Preferences’.

Inhaltsverzeichnis

Andere Gatekeeper Dashcam Handbücher

Gatekeeper

Gatekeeper Y35v2 Bedienungsanleitung

Gatekeeper

Gatekeeper Y62DC Bedienungsanleitung

Beliebte Dashcam Handbücher anderer Marken

Cansonic

Cansonic UltraDuo Z2 Bedienungsanleitung

Gazer

Gazer F720 Bedienungsanleitung

HP f500g Bedienungsanleitung

Xblitz

Xblitz TANGO 4K Bedienungsanleitung

Rexing

Rexing M1 Bedienungsanleitung

Maka Technologies

Maka Technologies Marbella MXPro Bedienungsanleitung

NESA

NESA NRC-80DLM Montage- und Bedienungsanleitung

Kaiser Baas

Kaiser Baas R20 Bedienungsanleitung

Boyo

Boyo VTM43TC Bedienungsanleitung

Minolta

Minolta MNCD37 Bedienungsanleitung

Thinkware

Thinkware FA10 Bedienungsanleitung

Momento

Momento MD-5200 Bedienungsanleitung

BlackVue

BlackVue DR590X-1CH Bedienungsanleitung

HP F300 Bedienungsanleitung

CammSys

CammSys BlackSys BH-300 Bedienungsanleitung

Snooper

Snooper DVR-2HD Bedienungsanleitung

Lukas

Lukas Q900 Bedienungsanleitung

RVS

RVS 450C Bedienungsanleitung
