IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Important Safety Advice
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience or knowledge if they
have been given supervision or instruction
concerning the use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Children of less than 3 years should be kept
away unless continuously supervised. Children
aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that
it has been placed or installed in its intended
normal operating position and they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children
aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance
or perform user maintenance.
CAUTION: Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
DO NOT use the heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
WARNING: In order to avoid overheating, do
not cover the heater.
DO NOT use this heater with a programmer,
timer, separate remote-control system or
any other device that switches the heater on
automatically, since a re risk exists if the
heater is covered or positioned incorrectly.
DO NOT cover the appliance or place material
or garments on it, or obstruct the air circulation
around this appliance, for example with
curtains or furniture, as this could cause over
heating and a re risk.
DO NOT place the heater directly below a xed
socket outlet.
This warning symbol indicates that the
heater should not be covered.
The heater has an IPX4 rating and is therefore
suitable for use in lofts, garages, utility rooms,
airing cupboards, sheds, display windows,
etc., however it is not waterproof and should
not be used in environments where continuous
or excessive water-spraying may occur.
IMPORTANT: If the mains lead of this
appliance is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualied person in order to avoid a
hazard.
Minimum clearance as indicated in Fig.3 must
be observed at all times when the heater is in
use.
The heater is designed for oor or wall xing
only and must be tted horizontally. It should
not be used as a free-standing unit.
IMPORTANT: The wall brackets supplied
with the appliance must be used.
Electrical
WARNING: THIS APPLIANCE MUST BE
EARTHED
If the socket outlets in your home are not of
the 13 amp BS1363 type (see Fig. 6) they
will not accept the plug connected to this
heater, therefore cut off the plug. When cut
off this plug can constitute a shock hazard if
inserted into a socket outlet. It must therefore
be disposed of safely.
Before wiring the appropriate plug please note
that the wires in this mains lead are coloured
in accordance with the following code:
GREEN/YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
Connect the Green/Yellow wire to the terminal
marked E or the earth symbol or coloured
Green or Green/Yellow. Connect the Brown
wire to the terminal marked L or coloured Red.
Connect the Blue wire to the terminal marked
N or coloured Black. DO NOT connect the
Brown (Live) or the Blue (Neutral) wires to
the Earth terminal of your 13 amp plug. If the
terminals of the plug are unmarked or you are
in any doubt, consult a qualied electrician.
General
Your tubular heater will provide a safe, low
level of heat output. These models are
designed for continuous operation and will
reach normal operating temperatures within
a few minutes after the appliance is switch
on. Based on the surrounding environment
and ambient temperature, the heater may
periodically cycle its heat output to ensure the
maximum permitted surface temperature is
not exceeded. All models are splash proof to
IPX4 standard.
