For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Parallel
115V
Wall Case Dimensions and Installation Information (in inches)
Specification Created 1/08 390448
ASV05LL
GE®115 Volt Mechanical Room Air Conditioner
17-1/8
11-1/8
13
Listed by
Underwriters
Laboratories
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
R
Note: When installing slide-out chassis units in through-the-wall
applications, keep louvers free. Do not restrict air flow areas. Fixed
chassis units are not suitable for through-the-wall applications.
Wall Outlets: All wiring including installation of receptacle must be
made in accordance with local electrical codes and regulations.
Electrical outlet should be in reach of line cord.
Note: Aluminum wiring may pose special problems – consult a
qualified electrician.
Features and Benefits
• 5,050 BTU, 9.7 EER, 115 Volts
• 2 Cooling / 2 Fan Only Speeds
• Adjustable Thermostat
• Fixed Chassis
• EZ Mount Window Kit
• Light Cool Grey
390448
Specification Created 1/08
AST05LL
Fan Only
High
Cool
Low
Cool
Medium
Cool
HI LO
Fan
ASV05LL
GE®115 Volt Mechanical Room Air Conditioner
