GE 165D4700P126 Bedienungsanleitung
GE Appliances
GE Answer Center
®
800.626.2000
Dishwashers
Part No. 165D4700P126 Pub. No. 49-5780
GSD500
GSD530
GSD650
GSD680
GSD715
GSD720
GSD725
Owner’s Manual
Congratulations!
You Are Now Part of the GE Family.
Welcome to the GE family.
We’re proud of our quality
products and we are
committed to providing
dependable service. You’ll
see it in this easy-to-use
Owner’s Manual and you’ll
hear it in the friendly voices
of our customer service
department.
Best of all, you’ll experience
these values each time you
use your dishwasher. That’s
important, because your
new dishwasher will be part
of your family for many
years. And we hope you will
be part of ours for a long
time to come.
We thank you for buying
GE. We appreciate your
purchase, and hope you
will continue to rely on us
whenever you need quality
appliances for your home.
Important!
Staple sales slip or cancelled
check here.
Proof of the original purchase date
is needed to obtain service under
the warranty.
Write the model and serial
numbers here.
#
#
You can find them on the tub wall just
inside the door.
2
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
GE & You,
A Service Partnership.
Inside you will find many
helpful hints on how to use and
maintain your dishwasher
properly. Just a little preventive
care on your part can save you a
great deal of time and money
over the life of your dishwasher.
Read this Manual
Ask any GE appliance owner and they will
tell you we stand behind our products with
unmatched quality service. However, did
you know that most questions result from
simple problems that you can easily fix
yourself in just a few minutes? This
Owner’s Manual can tell you how.
You’ll find many answers to
common problems here.
If you review our chart of
Troubleshooting Tips first,
you may not need to call for
service at all.
Review the Section on
Troubleshooting Tips
If you do need service, you can
relax knowing help is only a
phone call away. A list of toll-free
customer service numbers is
included in the back section.
Or you can always call the
GE Answer Center®at
800.626.2000, 24 hours a day,
7 days a week.
If You Need Service
Safety Information . . . . . . .4–7
Operating Instructions
Control Panel . . . . . . . . . . . . . . .8
Control Settings . . . . . . . . . . . . .8
Dial Cycles . . . . . . . . . . . . .10–11
Using the Dishwasher . . . .12, 13
Loading the
Dishwasher Racks . . . . . . .14, 15
Changing Color Panels . . . . . . .16
Care and Cleaning . . . . . . . . . .18
Troubleshooting Tips
Before You
Call For Service . . . . . . . . . 19–23
Customer Service
Warranty . . . . . . . . . . . . . . . . .27
Service Telephone
Numbers . . . . . . . . . .Back Cover
3
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
WARNING!
For your safety, the information in this manual must be
followed to minimize the risk of fire, explosion, electric
shock, or to prevent property damage, personal injury,
or loss of life.
Under certain conditions hydrogen gas may be produced in
a water heater that has not been used for two weeks or
more. Hydrogen gas can be explosive under these
circumstances.
If the hot water has not been used for two weeks or more, prevent
the possibility of damage or injury by turning on all hot water
faucets and allow them to run for several minutes. Do this before
using any electrical appliance which is connected to the hot water
system. This simple procedure will allow any built-up hydrogen gas
to escape. Since the gas is flammable, do not smoke or use an open
flame or appliance during this process.
WATER HEATER SAFETY
5
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
Use your dishwasher only for its intended purpose as
described in this Owner’s Manual.
This dishwasher must be properly installed and located in
accordance with the Installation Instructions before it is used.
If you did not receive an Installation Instructions sheet with
your dishwasher, you can receive one by calling us toll-free
at the GE Answer Center®
, 800.626.2000.
■Connect to a grounded
metal, permanent wiring
system; or run an equipment-
grounding conductor with
the circuit conductors and
connect to the equipment-
grounding terminal or lead
of the appliance.
■Improper connection of the
equipment-grounding
conductor can result in a risk
of electric shock. Check with
a qualified electrician or
service representative if you
are in doubt whether the
appliance is properly
grounded.
■Dispose of discarded
appliances and shipping or
packing material properly.
■Do not attempt to repair or
replace any part of your
dishwasher unless it is
specifically recommended in
this manual. All other
servicing should be referred
to a qualified technician.
■To minimize the possibility of
electric shock, disconnect
this appliance from the
power supply before
attempting any maintenance.
NOTE:
Turning the
dishwasher off does not
disconnect the appliance
from the power supply. We
recommend having a
qualified technician service
your appliance.
PROPER INSTALLATION
AND MAINTENANCE
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
DO NOT…
■Do not tamper with controls.
■Do not abuse, sit on, or stand
on the door or dish rack of
the dishwasher.
■Do not discard a dishwasher
without first removing the
door of the washing
compartment.
■Do not store or use
combustible materials,
gasoline or other flammable
vapors and liquids in the
vicinity of this or any other
appliance.
■Do not allow children to play
inside, on or with this
appliance or any discarded
appliance.
WARNING!
7
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
WHEN USING YOUR DISHWASHER
■Use only powder or liquid
detergents or wetting agents
recommended for use in a
dishwasher.
■Locate sharp items so that
they are not likely to damage
the door seal.
■Load sharp knives with the
handles up to reduce the risk
of cut-type injuries.
■Do not wash plastic items
unless marked
dishwasher
safe
or the equivalent. For
plastic items not so marked,
check the manufacturer’s
recommendations.
■Do not touch the heating
element during or
immediately after use.
■Do not operate your
dishwasher unless all
enclosure panels are properly
in place.
■Close supervision is necessary
if this appliance is used by or
near children.
■Load light plastic items so
they will not become
dislodged and drop to the
bottom of the dishwasher—
they might come into contact
with the heating element and
be damaged.
REMEMBER…
Your continued health and safety are important to us.
Please read and follow this Safety Information carefully.
We want you to remain a happy and healthy part of our
GE family.
SAVE THESE INSTRUCTIONS
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
About the dishwasher control panel.
You can locate your model number on the tub wall just inside the door.
Throughout this manual, features and appearance may vary from your model.
8
Models GSD650 and GSD680
Models GSD500 and GSD530
NORMAL WASH
SHORT WASH
RINSE & HOLD
DRYING
OFF HEAVY WASH
HEATED
DRY OFF
HEATED
DRY ON
12
SHORT
WASH
RINSE & HOLD
POT-
SCRUBBER
CYCLES
NORMAL
WASH
HEATED DRY
ON OFF
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
ENERGY OPTIONS
1 2 3
Models GSD715 and GSD720
SHORT
WASH
RINSE & HOLD
POT-
SCRUBBER
CYCLES
NORMAL
WASH
HEATED DRY
ON OFF
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
ENERGY OPTIONS
1 2 3
Model GSD725
SHORT
WASH
RINSE & HOLD
POT-
SCRUBBER
CYCLES
NORMAL
WASH
HEATED DRY
ON OFF
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
ENERGY OPTIONS
1 2 3
Energy Options
HEATED DRY Turns the drying heater on for fast drying. This
ON cycle will extend the time to your wash cycle.
HEATED DRY Shuts off the drying heat options. Dishes air dry
OFF naturally and energy is saved.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
Control Settings
Cycles
POTSCRUBBER/ For heavily soiled dishes or cookware with dried-on
HEAVY WASH or baked-on soils. Everyday dishes may be included.
This cycle will not remove burned-on foods.
NORMAL WASH For loads of everyday dishes, glasses and cookware
with medium soils.
NOTE:
Many dishes have lighter
soil than normal. Choosing a cycle other than
NORMAL WASH
will save energy and water.
SHORT WASH For quickly washing loads of everyday dishes with
medium soils that have not dried on, such as loads
consisting mostly of glasses.
RINSE & HOLD For rinsing partial loads that will be washed later.
Do not use detergent.
PLATE WARMER For warming clean dishes and serving plates. This
cycle will take approximately 32 minutes.
■Make sure the Dial is at the
OFF
position.
■Latch the door.
1
2
Start
Slowly turn the Dial to the
START
position. Don’t turn it
past the
START
position, or you could accidentally miss a
rinse. There is a time delay between start-up and water
fill so you will not hear any wash action right away.
3
9
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
About the dial cycles.
Short Wash
For quickly washing loads of everyday dishes with
medium soils that have not dried on.
Select the
NORMAL WASH
cycle and any options.
Be sure the door is unlatched.
Slowly turn the Dial to
SHORT WASH
.
Latch the door to start the cycle.
4
3
2
1
SHORT
WASH
RINSE & HOLD
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
Rinse & Hold
For rinsing partial loads that will be washed later.
Do not
use detergent.
Make sure
HEATED DRY OFF
is selected.
Be sure the door is unlatched.
Slowly turn the Dial to
RINSE & HOLD.
Latch the door to start the cycle.
4
3
2
1
SHORT
WASH
RINSE & HOLD
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
Plate Warmer
For warming clean dishes and serving plates. This cycle
will take approximately 32 minutes.
Load clean dishware to be warmed.
Select
HEATED DRY ON.
Be sure the door is unlatched.
Slowly turn the Dial to
PLATE WARMER.
Latch the door to start the cycle.
5
4
3
2
1
SHORT
WASH
RINSE & HOLD
PLATE
WARMER
(PRESS
HEATED DRY)
OFF START
10
Dieses Handbuch passt für folgende Modelle
16
Inhaltsverzeichnis
Andere GE Spülmaschine Handbücher
GE
GE Monogram ZBD6800KBB Benutzerhandbuch
GE
GE GLD4908T Handbuch
GE
GE Monogram ZBD6880NSS Benutzerhandbuch
GE
GE Profile PDW8000 Series Bedienungsanleitung
GE
GE HDA2030 Montageanleitung
GE
GE Spacemaker Bedienungsanleitung
GE
GE GSD1807 Bedienungsanleitung
GE
GE 31-9155 Anleitung zur Verwendung
GE
GE 49-55082-4 Bedienungsanleitung
GE
GE GLC4000 Series Bedienungsanleitung
GE
GE GSD2100V Handbuch
GE
GE GSD1200L Bedienungsanleitung
GE
GE Monogram ZBD1800K Series Anleitung zur Verwendung
GE
GE Monogram ZBD6800K Anleitung zur Verwendung
GE
GE GSD3300R Handbuch
GE
GE GSM2100 Bedienungsanleitung
GE
GE Monogram ZBD5600 Bedienungsanleitung
GE
GE GLD2850T10CS Bedienungsanleitung
GE
GE Appliances GSD4410 Bedienungsanleitung
GE
GE Dishwasher Bedienungsanleitung
