Geeetech Acrylic Prusa I3 Pro C Betriebsanleitung
Assemble Instruction of Geeetech Acrylic Prusa I3 Pro C
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Notice:
1. This kit contains tiny parts; please keep them away from kids under 3.
2. This building instruction applies to Geeetech Acrylic Prusa I3 pro C.
3. Some pictures of the printed part may be a bit different from those in your
package, no worries, they work the same, and the way to assemble is similar.
4. Building and operating 3D printer involves electricity, so all necessary precautions
should be taken and adhered to.
5. Building a 3d printer requires a certain amount of handling ability and basic
knowledge of working principle of 3D printer.
6. Be patient, please. If you have any problems assembling, please contact us, we
will try our best to help you.
1Unfold the box and check the package list
Unfold the package and take all the parts out to check the condition of the items.
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
All the acrylic plate has been etched with part ID and the plate is covered with
a sheet of kraft paper, you need to tear them off.
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Tips:
1. Before assembly, you are advised to put all the parts, especially the screws and nuts
in order, which will save you a lot of time looking for the required parts.
2. The part ID is corresponding to the number labeled on the bag of every part. Some
parts may not have label, you can refer to the pictures on the package list.
2 Assemble Y axis
2.1 Assemble the rods of a Y axis
Step1.Assemble the 2 threaded rods.
Part ID
Required number
Required parts
NO.5
2
M10 threaded rod
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
NO.A14
2
Y plate connecting
plate
NO.18
6
M8 spring washer
NO.9
8
M10 washer
NO.12
8
M10 nut
Thread the nuts and washers into the two M10 threaded rods separately. The order
should be:
1) Thread the acrylic fender (Y plate connecting plate) in the middle.
2) Thread the M10 washer > M8 spring washer >M10 nut > M10 nut > M10 washer
on the left
3) Thread theM10 washer < M8 spring washer < M10 nut < M10 nut< M8 spring
washer < M10 washer on the right
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Step2.Assemble the 2 smooth rods
Part ID
Required number
Required parts
NO.3
2
M8 smooth rod
NO.39
4
LM8UU Linear bearings
Slide 2 bearings on each smooth rod. Before you slide the bearings please make sure
they are clean.
1.2.Attach the front and rearAcrylic support plates of the rods.
Part ID
Required number
Required parts
NO. A9, A 10
2
Acrylic plate( front)
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Step1. Slide the rods into the acrylic plate; adjust the length so that the smooth rods fit
snugly between the front and rear piece.
Step2. Screw up the rods and plate with M10 nut and M10 washer.
* Tips: the Y-axis must be a rectangle, that is the rods on both side should be parallel,
so is the front and back plate. Otherwise it will cause obstruction for the belt later.
You can use a Digital Caliper to measure.
2.2 Assemble the Y idler
NO. A 11, A 12
2
Acrylic plate( rear)
NO.9
4
M10 washer
NO.12
4
M10 nut
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Part ID
Required number
Required parts
NO.38
2
624ZZ Ball bearing
NO.66
1
bearing holder
NO.27
1
M3 x 20 screw
NO.15
1
M3 wing nut
NO.35
1
M4 x25 screw
NO.14
1
M4 lock nut
Step1. Thread the M3 x 20 screw through the bearing holder.
Step2. Put the M4 x25 screw through the holes with the two 624ZZ bearings in
between. Lock the other end with a M4 lock nut.
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
Step3. Mount the assembled bearing holder onto the front support plates. And screw it
with a wing nut.
*Please leave enough room for the belt between the ball bearing and the screw.
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 - 858
Shenzhen GETECH CO.,LTD
GEEETECH
2.3 Mount the Y motor
Part ID
Required number
Required parts
NO. A13
1
Y motor fix plate
NO.75
1
Stepper motor
NO.43
1
pulley
NO.25
3
M3 x 12 screw
NO.26
2
M3 x 16 screw
NO.16
2
M3 square nut
Step1. Mount the pulley on the motor shaft, one of the screws should be screwed on
the cross section of the shaft. Do not screw too tight to turn smoothly.
