Genelec 8010 Bedienungsanleitung

Useful low frequency

spectrum extension

Loudspeakers Listening Distance Recommendations

20 30 40 50 60 70 80 90 100 200 300 400 500

Large Pipe Organ 16 Hz

5 strings Electric bass 31 Hz

Guitar 80 Hz

Male fundamental

Tuba (horn) 45 Hz

Double bass 40 Hz

Concert grand piano 29 Hz

frequency 120 Hz

Female fundamental

frequency 230 Hz

Step by Step Setup Guide

1238CF

1382

1234

1236

0.5 11.5 2510 15 (s)meter

1.6 3.2 56.5 16.5 32 50 (feet)

8320

8030

8040 / 8240

8050 / 8250

1032

8260

1237

8351

8020

8010

8330

103

104

100

102

104

100

109

101

105

109

115

107

102

111

115

121

100

103

107

113

102

106

112

Not recommended

When too close to the monitor, the

drivers - tweeter or midrange/tweeter

- are not summing together properly at

the crossover point, which affects the

perceived frequency response balance.

Recommended

The long-term sound pressure levels

(SPL) displayed take into consideration

an average room reverberation time

(RT60) of 0.3 sec.

Note: at extremely long distances the

SPL may become too low for the ap-

plication.

Product performance

Monitors -6 dB LF

Extension

Maximum

SPL at 1 m *

Room

volume

up to

Subwoofers

for 2

channels

Subwoofers

for 5

channels

8010 67 Hz 96 dB 55 m37040 7040

8020 / 8320 59 / 55 Hz 95 / 100 dB 65 m37050 / 7350 7050 / 7350

8030 / 8330 50 / 45 Hz 100 / 104 dB 75 m37050 / 7350 7060 / 7350

8040 / 8240 41 Hz 105 dB 85 m37060 / 7260 7070 / 7270

8050 / 8250 /

8351 32 Hz 110 dB 95 m37070 / 7270 7071 / 7271

1032 36 Hz 113 dB 100 m37071 7071

8260 23 Hz 113 dB 115 m37271 7271

1037 / 1237 32 Hz 116 / 118 dB 125 m37071 / 7271 7071 / 7271

1038CF /

1238CF 50 Hz 118 dB 125 m37071 / 7271 7071 / 7271

1038 / 1238 30 Hz 120 / 121 dB 170 m37071 / 7271 7071 / 7271

1034 / 1234 29 Hz 123 dB 200 m37073 2 x 7073

1036 / 1236 17 Hz 131 dB 400 m32 x 7073 3 x 7073

*) Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 1 m distance.

Sub-

woofers

Frequency range

+/-3 dB

Main / LFE channel

SPL short

term RMS at

1 m distance

7040 33 – 85 Hz / N/A 100 dB

7050 25 – 85 / 25 - 120 Hz 100 dB

7060 19 – 85 / 19 - 120 Hz 108 dB

7070 19 – 85 / 19 - 120 Hz 112 dB

7071 19 – 85 / 19 - 120 Hz 118 dB

7073 19 - 85 / 19 - 120 Hz 124 dB

7350 25 – 85 / 25 - 150 Hz 104 dB

7260 19 – 100* / 19 - 120 Hz 108 dB

7270 19 – 100* / 19 - 120 Hz 112 dB

7271 19 - 100* / 19 - 120 Hz 118 dB

*Variable subwoofer/main monitor crossover frequency, default 85 Hz.

Step by Step Setup Guide

( )

Concrete

structure

Vibration

Isolators

f~2-8 Hz

Multi-layered wall

wood, concrete, bricks

Amplifier

removed from

enclosure

Facingpanel

fixedtothe wall

(50-100mm/2-4")

Rubber gasket

(5-10mm/1/4-1/2")

1.1 m>

Max

60 cm

Avoid

Min 5 cm

Placing free standing speakers with subwoofers

Sub

300

1100

1000

1200

5.1 surround setup

ITU-R BS.775-2

Stereo setup

Main speaker placement

Genelec Document BBAG016e Copyright Genelec Oy 07.2015. All data subjected to change without prior notice.

BASS ROLL-OFF

20Hz 100Hz

-4

-2

-8

-6

ALL OFF

OFF ON

-2

-4 dB

-6

-8

TREBLE TILT

OFF ON

-2 dB

-4

MUTE

4kHz 20kHz

-2

-4

BASS TILT

OFF ON

-2

-4 dB

-6

MUTE

20Hz 100Hz

-2

-4

-6

8000 series needs ventila-

tion and free air flow around

the speaker cabinet and

sufficient openings on top

and bottom for proper LF

response.

Placing speakers in

relation to front wall

0.10 m 858 Hz

0.20 m 429 Hz

0.40 m 214 Hz

0.60 m 143 Hz

0.80 m 107 Hz

1.00 m 86 Hz

1.20 m 71 Hz

1.40 m 61 Hz

1.60 m 54 Hz

1.80 m 48 Hz

2.00 m 43 Hz

2.20 m 39 Hz

2.40 m 36 Hz

2.60 m 33 Hz

2.80 m 31 Hz

3.00 m 29 Hz

First cancellation

frequency

Distance

from wall

Genelec Oy, Olvitie 5, FIN-74100 Iisalmi, Finland. Phone: +358 17 83 881, Fax: +358 17 81 2267, E-mail: [email protected]

www.genelec.com

Flush mounting into a wall

• Flush mounting removes edge diffraction

• Eliminates reflection from the wall behind the

speaker

• Increases LF speaker efficiency

• Provides higher system SPL and lower

distortion

Free-standing:

Flat

Flush-mounting:

+6dB

2 walls position:

+12dB

Corner position:

+18dB

Avoid

> 60 cm

Min

5 cm

OVL

GENELEC

Max

60 cm

100 40020 40

(Hz)

80 200

Maximum

0.6 m

Distance > 0.6 m can reduce

the level of these frequencies

150
