ASSEMBLY
INSTRUCTIONS
FOR KIT RACKS:
● TASTING TABLE 32 32
INTRODUCTION COMPONENTS
SIDE
LADDERS
MIDDLE
LADDERS
HARDWARE
TOOLS REQUIRED
TASTING TABLE 32 32
BASE
SIDES
SPACER
BARS
TABLE
TOP
QUANTITY OF COMPONENTS
BASE
BLOCK
BASE
MOULD
FRONT & SIDE
CLEATS
NAIL GUN
(with appropriate air
compressor
or electric nailer)
18 gauge brand nails
(supplied)
WOOD
GLUE
PHILIPS HEAD SCREWDRIVER
COMPONENT QTY
SIDE LADDER 4
MIDDLE LADDER 14
COUNTER TOP 1
SPACER BARS 12
BASE SIDES 4
BASE BLOCKS 4
BASE MOULD FRONT 2
BASE MOULD SIDES 2
CLEATS 8
The following tools are required
(NOT INCLUDED):
The following hardware is included in all kits:
The following components
are included in Tasting Table 32 32
Thank you for purchasing a KIT RACK by Genuwine Cellars.
The following instructions will help you assemble kits:
Please study the instructions carefully prior
to starting the assembly.
IMPORTANT!
Always follow the manufacturer's
instructions on how to use the nail gun to
prevent injury. Genuwine Cellars is not
liable for any injury incurred by any power
or hand tool used to assemble the kit.
●Philips Panhead 5/8"
●GAUGE
BRAD NAILS
(6 SLEEVES)
A
A
1
3
2
45
ASSEMBLY- IB RACKS
APPLY GLUE TO SPACER BARS
APPLY GLUE TO 3
SPACER BARS
*Apply enough glue so that it will not
run when the pieces are nailed together
2 NAILS PER
CONNECTION
FOR ALL 3
SPACER BARS
STEP
STEP
STEP
STEP STEP
SIDE LADDER
NAIL SPACER BARS
TO OTHER SIDE
THE SAME WAY AS THE
PREVIOUS DIAGRAM
MIDDLE LADDER
APPLY GLUE TO
3 MORE SPACER BARS
AS IN STEP 1
APPLY GLUE TO CLEATS
APPLIE GLUE TO 4
CLEAT NOTCHES
CLEATS HAVE
PRE-DRILLED HOLES
*Apply enough glue so that it will not
run when the pieces are connected
BOTTOM
TURN RACK
OVER ON ITS
TOP SPACER
BARS
PLACE CLEATS
AT THESE
LOCATIONS
TOP
SCREW CLEATS
TO SPACER BARS
AS SHOWN
MAKE 2 IDENTICAL
RACKS
FLIP RACK
OVER
ASSEMBLE THE SECOND RACK INTO THE
CLEATS IN FRONT OF THE OTHER RACK
SLIDE RACK TOWARD
THE OTHER RACK
IN ORDER TO PLACE IT
WHERE THE CLEATS
Philips Panhead 5/8"
4
1
STEP
BASE ASSEMBLY
BASE MOULD
FRONT
BASE MOULD
SIDE
BASE MOULD
SIDE BASE MOULD
FRONT
ATTACH BASE MOULDS FINISHED BASE ASSEMBLY
1
TASTING TABLE ASSEMBLY
STEP D
D
FIT EACH RACK INTO
BASE NOTCHES
NAIL SPACER BARS (FRONT
& REAR) TO TOP OF BASE
BLOCK
BASE NOTCHES
TO FIT RACKS
2-3 NAILS
PER CONNECTION
PLACING THE COUNTERTOP
2
STEP PLACE COUNTERTOP
ON RACKS
ASSEMBLY- BASE
BASE BLOCK
BASE SIDE
BASE SIDE
MAKE 3-4 NAILS PER CONNECTION
2 IDENTICAL BASES
2
STEP
3
STEP
PLACE NAIL THROUGH
TOP SPACER BAR AT
THESE LOCATIONS
TASTING TABLE 32 32 ASSEMBLY IS COMPLETED
VIEW OF TASTE TABLE FROM UNDERNEATH TO
SHOW LOCATIONS OF NAILS
1-2 NAILS PER LOCATION
