German pool HTM-660 Bedienungsanleitung

P.1

Mini Ceramic Fan Heater HTM-660

USER MANUAL

Online Warranty Registration

Please read these instructions and warranty information carefully

before use and keep them handy for future reference.

P.2

Content

Warnings & Safety Precautions

Product Structure

Operating Instructions

Cleaning and Maintenance

Technical Specication

Warranty Terms & Conditions

P.3

Warnings & Safety Precautions

WARNING!

Read all instructions carefully before using this product.

• This product is for domestic indoor use only. If this product is used for any commercial, industrial,

rental or other purposes, product warranty will be VOIDED.

• This product is not intended for use by children or persons with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction

concerning use of this product by an adult responsible for their safety.

• Mind your children and DO NOT let children play with this product.

• Cleaning and user maintenance shall not be made by children without supervision.

• Check the voltage indicated on the rating label before using this product.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualied persons in order to avoid hazards.

• Unplug this product from the power source before cleaning and maintenance.

• Contact German Pool authorized service technician for repair or maintenance of this product.

When using electrical appliances, basic precautions should always be followed to reduce the risk of

re, electric shock, and injury to persons, including the following:

1. Read all instructions before using this heater.

2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided,

use handles when moving this heater. Keep combustible materials, such as furniture, pillows,

bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater and keep

them away from the sides and rear.

3. Extreme caution is necessary when any heater is used by or near children or invalids and whenever

the heater is left operating and unattended.

4. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been

dropped or damaged in any manner. Return heater to authorized service facility for examination,

electrical or mechanical adjustment, or repair.

5. Do not use outdoors.

6. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never

locate heater where it may fall into a bathtub or other water container.

7. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do

not route cord under furniture or appliances. Arrange cord away from trafc area and where it will not

be tripped over.

P.4

Warnings & Safety Precautions

8. This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be

made by children without supervision.

9. Children less than 3 years of age should be kept away unless continuously supervised.

10. Children aged from 3 to 8 years shall only switch on/off the appliance provided that it has been

placed or installed in its intended normal operating position and they have been given supervision

or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children aged from 3 to 8 years shall not plug in, regulate, and clean the appliance or perform

user maintenance.

11. CAUTION — some parts of this product can become very hot and cause burns. Particular attention

has to be given where children and vulnerable people are present.

12. Disconnect from main power source when not in use or cleaning.

13. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or

similarly qualied persons in order to avoid a hazard.

14. The voltage and frequency of the power supply must comply with the technical specication of

the heater. 220-240V~/50Hz

15. Warning: in order to avoid overheating, do not cover the heater.

16. Do not twist the device, to avoid damage on the device.

17. Do not beat or shake the device when the device is turned on.

18. When the device is working, do not touch the wind outlet, to avoid scalding skin.

19. Be sure the wind inlet & outlet are unblocked to avoid any malfunction appearance; such as

distortion, changing color, etc.

20. Put the power cord in the right way to avoid stumbling over the power cord.

21. Do not allow the power cord to touch the front net cover to avoid the high temperature from

damaging the power cord.

22. Put the device on a at surface when using. It is strictly prohibited to use the device near or in

bathroom, shower or a swimming pool.

23. The device is hot when in operation, Avoid ammable, explosive articles, as well as environments

full of inammable air or dust.

24. A re may occur if the heater is covered with or touches ammable material, including curtains,

drapes, bedding etc. when in operation. KEEP THE HEATER AWAY FROM SUCH MATERIALS.

P.5

25. Do not let the power cord hang over the edge of the table or work surface or touch hot surfaces.

26. Do not hang a wet cloth or anything wet above the device, to avoid leakage of electricity.

27. Do not put ammable or cloth on the device, to avoid re or electric shock.

28. When the device is in operation, please do not place the air outlet and inlet next to the wall or

curtain to avoid obstructing the air and inuence the heater effect.

29. Do not place the power cord at the wind outlet, it will damage the insulation layer of wires

30. Do not insert conductive objects into air inlet or outlet, to avoid electric shock.

31. Considering the security, when no one is around, turn off the device, to avoid unpredictable accidents.

32. The device is not intended to use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction.

33. Make sure power is off and the plug is disconnected when cleaning or repairing.

34. If not using the device for a long period, please disconnect the plug, put the device into the box and

store the device in a dry and ventilated place.

35. Do not attempt to repair, disassemble or modify the device privately when there is some damage

on the power cord or something is wrong with the device.

36. Warning: the heater cannot be directly located under the socket.

Warnings & Safety Precautions

P.6

Product Structure

Main Body

Control Panel

On/Off button Body sensor button

1. Front cover

2. Power indicator

3. Body sensor indicator

4. Control panel

5. Body sensor detector

6. On/Off button

7. Body sensor button

8. Dust-proof lter

9. Back cover

10. Power switch

11. Tip-over switch

P.7

Operating Instructions

Installation

• Take the product out of the packaging box.

• Place the heater on a at surface as shown in picture 1.

Function Button Instructions

1. On/Off Button

1.1 Connect and turn on electricity, the heater enters standby mode. All indicator lights are off.

1.2 Under standby mode, press the button once to turn on the device. The default setting after the

heater is turned on:

a) Body sensor mode indicator light is off, heater enters continuous mode.

b) PTC heating element starts working.

c) DC Fan turns on.

During operation, press button once to turn off the heater (all indicator lights are off, PTC heating

element stops working immediately, DC fan stops working after 10 seconds).

2. Body Sensor Button

2.1 When the device is on, press button to turn on/off body sensor mode.

2.2 Continuous mode: when turns off body sensor mode, the heater enters continuous mode. The heater

continuously works; PTC heating element and DC fan also work simultaneously.

2.3 Body sensor mode: When this mode is on, body sensor mode operates.

• Upon switching to the body sensor mode, the PTC heating element keeps operating for the rst

2 minutes and the system will continuously detect the presence of human body; if human body is

detected within 2 minutes, it keeps functioning while resetting the timer for another 2-minute

interval. If human body is not detected, the PTC heating element will stop working after 2 minutes.

10 seconds later the motor will be switched off and stop generating warm air.

• Body sensor mode indicator: the sensor will be on as long as the PTC heating element and fan are

working. When human body is absent, they will be switched off and the indicator will keep ashing

at 1 Hz.

Note:

The machine has no memory function. Every time the heater reboots, by default the PTC heating

element is on and the body sensor function is off.

Figure 1

P.8

Operating Instructions

Cleaning and Maintenance

Technical Specication

Body Sensor Mode Instructions:

When the temperature is between 20℃and 25℃, this mode is effective when a body is detected

within a distance of around 1.8 meters. The sensor is affected by the temperature of the environment.

The lower the temperature the more sensitive the sensor is and vice versa. The effective angles are

between 60 degrees vertically and 90 degrees horizontally.

1. Before cleaning or maintenance, please unplug the heater and wait for the heater to cool.

2. When cleaning the surface of the heater, do it with a wet cloth. Do not use petrol, thinner, diluents or

other similar chemical substances. Do not spray at the heater.

3. If there is dirt blocking the back cover, the heater performance may be affected. Clean the back

cover at least every other month. A wet cloth may be used to wipe the back cover.

4. If the heater will not be used for a long period of time, pack the heater properly and store it in a dry

and ventilated place.

Specications are subject to change without prior notice.

If there is any inconsistency or ambiguity between the English version and the Chinese version, the

Chinese version shall prevail.

Refer to www.germanpool.com for the most up-to-date version of the Operating Instructions.

Model

Voltage

Frequency

Power

Sound Level

Dimensions

Net Weight

HTM-660

220-240 V~

50 Hz

600 W

≤50 dB

(H)185mm (W)118mm (D)98.8mm

0.71 kg

P.9

警告及注意事項

產品結構

操作說明

清潔與保養

技術規格

保用條款

P.10

警告及注意事項

使用本產品時，必須採取一切基本預防措施以降低火警、觸電或受傷的機會。基本預防措施包括以下：

1. 使用本產品前，先閱讀所有說明。

2. 本機使用時會變熱。避免燙傷，請勿讓皮膚直接接觸產品表面。易燃物料（如家具、枕頭、床

上用品、紙張、衣服和窗簾）與本機正面需至少保持3英尺（0.9米）的距離，並遠離機體側面

和後部。

3. 當兒童或殘疾人接近或使用暖器時，以及暖風機運行而無成人看管時，必須格外小心。

4. 當本產品的電源線或插頭損壞、發生故障、跌落或有任何損毀時，請勿操作本產品。如電源線

損壞或發生其他故障，必須由本公司或合資格的專業技術人員更換和維修。

5. 請勿在戶外使用本產品。

6. 本機不適用於浴室，洗衣區和類似的室內場所。切勿將暖風機放在可能落入浴缸或其他水容器

的地方。

7. 不要將電線置於地毯下。不要用地毯或其他類似的物件覆蓋電線。不要將電線放在家具或電器

下面。將電線遠離多雜物或容易被絆倒的地方。

8. 8歲或以上的兒童，以及身體，感官或精神能力下降或缺乏經驗和知識的人員，只可在得到監

督、指導並清楚了解觸電危機的情況下使用本機。未經監督的兒童不得進行清潔或保養。

9. 除非有持續不斷的監督，否則3歲以下兒童應遠離本產品。

10. 3至8歲兒童只可在得到監管並清楚了解觸電危險的情況下開啟或關閉本機，切勿進行接插電

源、調控、清潔或保養等工作。

11. 注意-本產品於使用時或使用後機體不同部分將變熱，有燙傷危險。請特別注意保護兒童及其

他弱勢人群。

警告！

使用本產品前，請仔細閱讀所有說明。

．本產品只限家居室內日常使用，如產品作任何商業、工業、出租或其他用途，保用證即告失效。

．請勿讓兒童或身體有殘障、精神不健全及對本產品缺乏經驗或知識的人士單獨使用本產品；

 如需使用，必須要在負責任的成年人監管下方可使用。

．應照顧好兒童，確保他們不會玩耍本產品。

．無成年人監管下，勿讓兒童清潔及維護本產品。

．使用前，請先檢查所有電壓是否與本產品標籤上的電壓相符。

．如果電源線損壞，為免發生意外，電源線必須由廠方、廠方指定的維修中心或同等合格的

 技術人員進行更換。

．清潔或檢查本產品前，必須先關機及拔掉插頭。

．請聯繫德國寶授權的技術人員進行維修或保養本產品。

Inhaltsverzeichnis

Andere German pool Heizung Handbücher

German pool

German pool HTM-260 Bedienungsanleitung

German pool

German pool EFB-P35HM Bedienungsanleitung

German pool

German pool YW-18B Bedienungsanleitung

German pool

German pool HTW-521 Bedienungsanleitung

German pool

German pool EFB-326H-SC Bedienungsanleitung

German pool

German pool HTM-360 Bedienungsanleitung

German pool

German pool HTE-90H Bedienungsanleitung

German pool

German pool HTW-320 Bedienungsanleitung

German pool

German pool HTW-115U Bedienungsanleitung

German pool

German pool HTM-560 Bedienungsanleitung

German pool

German pool HTS-200 Bedienungsanleitung

German pool

German pool HTS-200 Bedienungsanleitung

German pool

German pool EFB-326H Bedienungsanleitung

German pool

German pool HTF-210 Bedienungsanleitung

German pool

German pool HTD-89H Bedienungsanleitung

German pool

German pool HTW-330 Bedienungsanleitung

German pool

German pool HTD-89H Bedienungsanleitung

German pool

German pool HTB-148 Bedienungsanleitung

German pool

German pool HTB-816 Bedienungsanleitung

German pool

German pool EFB-426HM-SC Bedienungsanleitung

German pool

German pool HTW-330 Bedienungsanleitung

German pool

German pool HTF-420 Bedienungsanleitung

German pool

German pool HTB-716 Bedienungsanleitung

German pool

German pool HTW-521 Bedienungsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
