Gigabyte 6CXC Bedienungsanleitung

FCC Compliance Statement:

This equipment has been tested and found to

comply with limits for a Class B digital device ,

pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable

protection against harmful interference in

residential installations. This equipment

generates, uses, and can radiate radio

frequency energy, and if not installed and used

in accordance with the instructions, may cause

harmful interference to radio communications.

However,thereisnoguaranteethatinterference

will not occur in a particular installation. If this

equipment does cause interference to radio or

television equipment reception, which can be

determinedbyturningtheequipmentoffandon,theuserisencouragedtotryto

correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna

-Move the equipment away from the receiver

-Plug the equipment into an outlet on a circuit different from that to which

the receiver is connected

-Consult the dealer or an experienced radio/television technician for

additional suggestions

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void Your

authority to operate such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to

the following two conditions 1) this device may not cause harmful interference

and2)thisdevicemust acceptanyinterferencereceived,includinginterference

that may cause undesired operation.

DECLARATIONOFCONFORMITY

Per FCC Part 2 Section 2. 1077(a)

Responsible Party Name: G.B.T. INC.

Address: 18305 Valley Blvd., Suite#A

LA Puent, CA 91744

Phone/Fax No: (818) 854-9338/ (818) 854-9339

hereby declare s that the product

Product Name:

Model Number:

Mother Board

Conforms to the following specifications:

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),

Class B Digital Device

Supplementary Information:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful

and (2) this device must accept any inference received, including

that may cause undesired operation.

Representative Person's Name: ERIC LU

Signature:

Date: Dec.03,1999

Eric Lu

GA-6CXC

Declaration of Conformity

We, Manufacturer/Importer

(full address)

G.B.T. Technology Träding GMbH

Ausschlager Weg 41, 1F, 20537 Hamburg, Germany

declare that the product

( description of the apparatus, system, installation to which it refers)

Mother Board

GA-6CXC

is in conformity with

(reference to the specification under which conformity is declared)

in accordance with 89/336 EEC-EMC Directive

EN 55011 Limits and methods of measurement EN 61000-3-2* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-2by household appliances and similar

industrial, scientific and medical (ISM electrical equipment “Harmonics”

high frequency equipment

EN55013 Limits and methods of measurement EN61000-3-3* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-3by household appliances and similar

broadcast receivers and associated electrical equipment “Voltage fluctuations”

equipment

EN 55014 Limits and methods of measurement EN 50081-1Generic emission standard Part 1:

of radio disturbance characteristics of Residual, commercial and light industry

household electrical appliances,

portable tools and similar electrical EN 50082-1Generic immunity standard Part 1:

apparatus Residual, commercial and light industry

EN 55015 Limits and methods of measurement EN 55081-2Generic emission standard Part 2:

of radio disturbance characteristics of Industrial environment

fluorescent lamps and luminaries

EN 55020 Immunity from radio interference of EN 55082-2Generic immunity standard Part 2:

broadcast receivers and associated Industrial environment

equipment

EN 55022 Limits and methods of measurement ENV 55104 Immunity requirements for household

of radio disturbance characteristics of appliances tools and similar apparatus

information technology equipment

DIN VDE 0855 Cabled distribution systems; Equipment EN 50091-2 EMC requirements for uninterruptible

part 10 for receiving and/or distribution from power systems (UPS)

part 12 sound and television signals

CE marking (EC conformity marking)

The manufacturer also declares the conformity of above mentioned product

with the actual required safety standards in accordance with LVD 73/23 EEC

EN 60065 Safety requirements for mains operated EN 60950 Safety for information technology equipment

electronic and related apparatus for including electrical business equipment

household and similar general use

EN 60335 Safety of household and similar EN 50091-1General and Safety requirements for

electrical appliances uninterruptible power systems (UPS)

Manufacturer/Importer

Signature : RexLin

(Stamp) Date : Dec. 03, 1999 Name : Rex Lin

6CXC/6CXC-1

PentiumII / III Processor

Motherboard

USER'S MANUAL

PentiumII / III Processor MAINBOARD

REV. 2.3 First Edition

R-23-01-091223

How this manual is organized

This manual is divided into the following sections:

1) Revision List Manual revision information

2) Item Checklist Product item list

3) Features Product information & specification

4) Hardware Setup Instructions on setting up the motherboard

5) Performance & Block Diagram Productperformance & block diagram

6) Suspend to RAM & Dual BIOS Instructions STR installation & Dual BIOS

7) BIOS Setup Instructions on setting up the BIOS software

8) Appendix General reference

Table Of Content

Revision History P.1

Item Checklist P.2

Summary of Features P.3

6CXC/6CXC-1 Motherboard Layout P.5

Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition P.8

Performance List P.28

Block Diagram P.29

Suspend to RAM Installation P.30

Dual BIOS Introduction P.36

Memory Installation P.43

Page Index for BIOS Setup P.44

Appendix P.77

6CXC/6CXC-1 Motherboard

Revision History

Revision Revision Note Date

2.3 Initial release of the 6CXC/6CXC-1 motherboard user’s manual. Dec.1999

The author assumes no responsibility for any errors or omissions that may appear in this

document nor does the author make a commitment to update the information contained herein.

Third-party brands and names are the property of their respective owners.

Sound Blaster is a registered trademark of Creative Technology Ltd in the United States and

certain other countries. Sound Blaster-LINK and SB-LINK are trademarks of Creative

Technology Ltd.

Dec. 23 , 1999 Taipei, Taiwan, R.O.C

Item Checklist

þThe 6CXC/6CXC-1 Motherboard

þCable for IDE / Floppy device

þCD (IUCD) for motherboard utilities

oInternal COMB Cable (Optional)

oInternal USB Cable (Optional)

oCable for SCSI device

þ6CXC/6CXC-1 User’s Manual

6CXC/6CXC-1 Motherboard

Summary of Features

Form factor Ÿ30.5 cm x 22 cm ATX SIZE form factor, 4 layers PCB.

CPU ŸPentiumII/III Processor

Ÿ256/ 512 KB 2nd cache in CPU

Chipset Ÿ82820 HOST / AGP / RDRAM Controller

Ÿ82801AA(ICH) I/O Controller Hub

Ÿ82805AA(MTH) Memory Translator Hub

Clock Generator ŸSupports 100 / 133MHz

Ÿ105/110/115/117/120/125/127/135/137/140/

145/150 MHz clocks (reserved)

Memory Ÿ4 168-pin DIMM Sockets Support 4 banks.

I/O Control ŸWinbond W83627HF LPC

Slots Ÿ1 AMR (Audio Modem Riser) slot

Ÿ1 Universal AGP slot 1X/2X/4X 1.5V/3.3V device

support

Ÿ5 32-bit Master PCI Bus slots

Ÿ1 16-bit ISA Bus slot (Optional)

On-Board IDE ŸAn IDE controller on the Intel

82801AA PCI chipset

providesIDE HDD/CD-ROM with PIO, Bus Master and Ultra

DMA33/ATA66 operation modes

ŸCan connect up to four IDE devices

On-Board Peripherals Ÿ1Floppyportsupports2FDDwith360K,720K,1.2M, 1.44M

and 2.88M bytes

Ÿ1 Parallel ports supports SPP/EPP/ECP mode

Ÿ2 Serial Ports (COMA & COMB)

Ÿ4 USB ports (Front USB Port Optional)

Ÿ1 IrDA connector for IR/CIR

Hardware Monitor

(Optional) ŸCPU/Power Supply/System Fan Revolution detect

ŸCPU Fan Control

ŸSystem Voltage Detect

ŸCPU Overheat Warning

ŸChassis Intrusion Detect

ŸDisplay Actual Current Voltage

On-Board Sound

(Optional) ŸAureal AU8810(Optional)

ŸLine In / Line Out / Mic In/ AUX In / CD In / TEL / SPDIF

/ Game Port

PS/2 Connector ŸPS/2Keyboard interface and PS/2Mouse interface

To be continued…

Summary of Features

BIOS ŸLicensed AMI BIOS, 4M bit FWH

ŸSupport Dual BIOS (Optional)

Additional Features ŸInternal/External Modem Wake up

ŸSTR (Suspend-To-RAM)

ŸWake On LAN

ŸPS/2 Keyboard Password Wake up

ŸPS/2 Mouse Wake up

ŸSystem after AC back

ŸPolyfuseforkeyboard,USB,Gameportover-currentprotection
