Gigabyte 6EMMP Bedienungsanleitung

6EMMP

TABLE OF CONTENTS

1. INTRODUCTION

1.1. PREFACE..........................................................................................................1-1

1.2. KEY FEATURES...............................................................................................1-1

1.3. PERFORMANCE LIST......................................................................................1-2

1.4. BLOCK DIAGRAM ............................................................................................1-3

1.5. INTRODUCE THE PentiumII Processor ......................................................1-4

1.6. What is AGP?....................................................................................................1-6

2. SPECIFICATION

2.1. HARDWARE.....................................................................................................2-1

2.2. SOFTWARE......................................................................................................2-2

2.3. ENVIRONMENT................................................................................................2-2

3. HARDWARE INSTALLATION

3.1. UNPACKING.....................................................................................................3-1

3.2. MAINBOARD LAYOUT.....................................................................................3-2

3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS .............................3-1

3.4. DRAM INSTALLATION.....................................................................................3-6

3.5. CPU SPEED SETUP ........................................................................................3-6

3.6. CMOS RTC & ISA CFG CMOS SRAM.............................................................3-7

3.7. SPEAKER CONNECTOR INSTALLATION .....................................................3-7

3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION....................3-7

3.9. POWER LED CONNECTOR INSTALLATION ................................................3-7

Table Of Contents

3.10. IDE & ATAPI DEVICE INSTALLATION..........................................................3-8

3.11. PERIPHERAL DEVICE INSTALLATION........................................................3-8

3.12. KEYBOARD & PS/2 MOUSE INSTALLATION...............................................3-8

4. BIOS CONFIGURATION

4.1. ENTERING SETUP ..........................................................................................4-1

4.2. CONTROL KEYS..............................................................................................4-1

4.3. GETTING HELP................................................................................................4-2

4.4. THE MAIN MENU..............................................................................................4-2

4.5. STANDARD CMOS SETUP MENU .................................................................4-5

4.6. BIOS FEATURES SETUP................................................................................4-9

4.7. CHIPSET FEATURES SETUP.........................................................................4-13

4.8. POWER MANAGEMENT SETUP....................................................................4-16

4.9. PNP/PCI CONFIGURATION............................................................................4-21

4.10. LOAD BIOS DEFAULTS.................................................................................4-23

4.11. LOAD PERFORMANCE DEFAULTS.............................................................4-22

4.12. INTEGRATED PERIPHERALS ......................................................................4-23

4.13. SUPERVISOR/USER PASSWORD...............................................................4-30

4.14. IDE HDD AUTO DETECTION........................................................................4-31

4.15. SAVE & EXIT SETUP.....................................................................................4-32

4.16. EXIT WITHOUT SAVING...............................................................................4-33

APPENDIX A: On-Board Display Driver Installation

A.1. ATi RAGE PRO DISPLAY DRIVER INSTALLATION......................................A-1

A.2. YAMAHA SOUND DRIVER INSTALLATION...................................................A-6

6EMMP

1-1

1. INTRODUCTION

1.1. PREFACE

Welcome to use the 6EMMP motherboard. It is a PentiumII Processor based

PC / AT compatible system with AGP/ PCI / ISA Bus, and has been designed

to be the fastest PC / AT system. There are some new features allow you to

operate the system with just the performance you want.

This manual also explains how to install the motherboard for operation, and

how to set up your CMOS CONFIGURATION with BIOS SETUP program.

1.2. KEY FEATURES

qIntel PentiumII Processor based PC / AT compatible mainboard.

qSlot 1 supports PentiumII processor running at 233-633 MHz.

qIntel 440EX chipset, Supports SDRAM / Ultra DMA/33 IDE.

qBuilt-in ATi RAGE PRO 3D graphics acceleration chip.

qBuilt-in PCI YAMAHA audio chip.

qSupports external Modem Ring-On on COM A&B and internal Modem

Ring-On.

qSupports Wake-up on LAN (JP7).

qSupports 2xDIMMs using 3.3V EDO or SDRAM DIMM module.

qSupports 8 MB - 256 MB EDO / 256MB SDRAM memory on board.

q2xPCI Bus slots, 2xISA Bus slots.

qSupports 2 channels Ultra DMA/33 IDE ports for 4 IDE Devices.

qSupports 2xCOM (16550), 1xLPT (EPP / ECP), 1x Floppy port.

qSupports 2xUSB ports, 1xPS/2 Mouse, 1xPS/2 Keyboard.

qLicensed AWARD BIOS, 2Mbits FLASH RAM.

q24.3 cm x 20 cm Micro-ATX form factor, 4 layers PCB.

Introduction

1-2

1.3. PERFORMANCE LIST

The following performance data list is the testing results of some popular

benchmark testing programs.

These data are just referred by users, and there is no responsibility for different

testing data values gotten by users. (The different Hardware & Software

configuration will result in different benchmark testing results.)

•CPU PentiumII processor

•DRAM (128 x 1) MB SDRAM (SEC KM48S8030BT-GH)

•CACHE SIZE 512 KB included in CPU

•DISPLAY Onboard ATi AGP 3D graphics acceleration chip

(4MB SGRAM)

•STORAGE Onboard IDE (IBM DHEA-38451)

•O.S. Windows NT 4.0

•DRIVER Display Driver at 1024 x 768 x 64K colors x 75Hz.

INTEL Bus Master IDE Driver 3.01

Intel PentiumII

Processor 266MHz(66x4) 333MHz(66x5)

Winbench98

CPU mark32 721 865

FPU Winmark 1380 1720

Business Disk 1800 1870

Hi-End Disk 4500 4710

Business Graphics 156 176

Hi-End Graphics 174 198

Winstone98Business 27.2 32.4

Hi-End 32.2 36.1

6EMMP

1-3

3.3V EDO/SDRAM

DIMM Sockets

Floppy Port

1.4. BLOCK DIAGRAM

PS/2 Keyboard

24MHz

33MHz

66MHz

Ultra DMA/33

IDE Ports

IDE Bus

PCI Bus

ISA Bus

AGP Bus

LPT Port

COM Ports

DRAM Bus

PS/2 Mouse

USB Bus

USB Ports

14.318MHz

48MHz

14.318MHz

I/O

CHIPSET

IT8671F

Host Bus

PAC

82443EX

CHIPSET

PIIX4

82371EB

CHIPSET

Clock

Generator

ATi

RAGE PRO

VIDEO

MEMORY

100MHz

MIC

L-IN

L-OUT

YAMAHA

24.576MHz

14.318MHz

66MHz

VGA

Game

Port

AC-2

Introduction

1-4

1.5. INTRODUCE THE Pentium



II Processor

Figure 1:Retention Mechanism & attach Mount (Optional)

6EMMP

1-5

Figure 1:Retention Mechanism & attach Mount (Optional)

Figure 2:OEM PentiumII Processor

Figure 3:Heatsink / FAN & Heat sink support for OEM PentiumII Processor

Introduction

1-6

Figure 4:Boxed PentiumII Processor & Heat sink support

1.6 What is AGP

The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge

device that supports an AGP port. The main purpose of the AGP port is to

provide fast access to system memory.

The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits

at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and

side band addressing. When the 2x-data rate is used, the port can transmit data

at 533MB/sec (66.6*2*4). The read-queue can be used to pipeline reads –

removing the effects of the reads-latency. Side band addressing can be used to

transmit the data address on a separate line in order to speed up the

transaction.
