Gigabyte A520M S2H Bedienungsanleitung

GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.

Also, to reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

A520M S2H

User's Manual

Rev. 1301

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

For detailed product information, carefully read the User's Manual.

For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's

website.

https://download.gigabyte.com/FileList/Manual/mb_manual_installation-guide_103.pdf?m=sw

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

Chapter 1 Product Introduction .......................................................................................4

1-1 Motherboard Layout ......................................................................................... 4

Chapter 2 Hardware Installation .....................................................................................5

2-1 Installation Precautions .................................................................................... 5

2-2 Product Specications ...................................................................................... 6

2-3 Installing the CPU ............................................................................................ 9

2-4 Installing the Memory ....................................................................................... 9

2-5 Installing an Expansion Card ......................................................................... 10

2-6 Back Panel Connectors .................................................................................. 10

2-7 Internal Connectors ........................................................................................ 12

Chapter 3 BIOS Setup ..................................................................................................20

Chapter 4 Installing the Operating System and Drivers ................................................22

4-1 Operating System Installation ........................................................................ 22

4-2 Drivers Installation .......................................................................................... 23

Chapter 5 Appendix ......................................................................................................24

5-1 Conguring a RAID Set .................................................................................. 24

Regulatory Notices .................................................................................................... 25

Contact Us ................................................................................................................ 26

- 4 -

KB_MS_USB

HDMI

AUDIO

CPU_FAN

SYS_FAN1

ATX

A520M S2H

DDR4_A1

DDR4_B1

BAT

U32

CODEC

M_BIOS

VGA

DVI

PCIEX16

PCIEX1_1

PCIEX1_2

iTE® Super

I/O

Realtek®

GbE LAN

F_U32

SPEAKER

F_USB1 F_PANEL

F_USB2TPM

D_LED1

SATA3

012

U32_LAN

Socket AM4

CLR_CMOSF_AUDIO

M2A_CPU 806042

SATA3

SYS_FAN2

COMLED_C

QFLASH_PLUS

QFLED

ATX_12V

AMD

A520

1-1 Motherboard Layout

Chapter 1 Product Introduction

Chapter 2 Hardware Installation

2-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can become

damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's

manual and follow these procedures:

•Prior to installation, make sure the chassis is suitable for the motherboard.

•Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

•Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

•When connecting hardware components to the internal connectors on the motherboard, make

sure they are connected tightly and securely.

•When handling the motherboard, avoid touching any metal leads or connectors.

•It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic

components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keep your hands dry and rst touch a metal object to eliminate static electricity.

•Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

•Before connecting or unplugging the power supply cable from the motherboard, make sure

the power supply has been turned off.

•Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

•Before using the product, please verify that all cables and power connectors of your hardware

components are connected.

•To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

•Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

•Do not place the computer system on an uneven surface.

•Do not place the computer system in a high-temperature or wet environment.

•Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

•If you are uncertain about any installation steps or have a problem related to the use of the

product, please consult a certied computer technician.

•If you use an adapter, extension power cable, or power strip, ensure to consult with its installation

and/or grounding instructions.

- 5 -

2-2 ProductSpecications

CPU AMD Socket AM4, support for:

AMD Ryzen™ 5000 G-Series Processors/

AMD Ryzen™ 5000 Series Processors/

AMD Ryzen™ 4000 G-Series Processors/

AMD Ryzen™ 3000 G-Series Processors/

AMD Ryzen™ 3000 Series Processors

(Go to GIGABYTE's website for the latest CPU support list.)

Chipset AMD A520

Memory 2 xDDR4 DIMM sockets supportingup to 64 GB (32 GB single DIMM capacity)

of systemmemory

Support for DDR4 3200/2933/2667/2400/2133 MT/s memory modules

Dual channel memory architecture

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Prole (XMP) memory modules

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

Integrated Graphics Processor with AMD Radeon™ Graphics support:

- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz

* The DVI-Dport does not support D-Subconnection by adapter.

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1 version, HDCP2.3, and HDR.

Support for up to 3 displays at the same time

Maximumshared memory of 16 GB

Audio Realtek®audio CODEC

High Denition Audio

2/4/5.1/7.1-channel

* You can change the functionality of an audio jackusingthe audio software.To congure

7.1-channel audio, access the audio software for audio settings..

LAN Realtek®GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Expansion Slots CPU:

- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16

Chipset:

- 2 x PCI Express x1 slots, supporting PCIe 3.0

Storage Interface CPU:

- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe

3.0 x4/x2 SSD support)

Chipset:

- 4 x SATA 6Gb/s connectors

- Support for RAID 0, RAID 1, and RAID 10

- 6 -

USB CPU:

- 4 x USB 3.2 Gen 1 ports on the back panel

Chipset:

- 2 x USB 3.2 Gen 1 ports available through the internal USB header

- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through

the internal USB headers)

Internal

Connectors

1x24-pin ATXmain power connector

1x8-pin ATX12Vpower connector

1xCPU fan header

2 xsystemfan headers

1xaddressable LEDstrip header

1xRGB LEDstrip header

1xM.2 Socket 3 connector

4 xSATA 6Gb/s connectors

1xfront panel header

1xfront panel audio header

1xUSB 3.2 Gen 1header

2 xUSB 2.0/1.1 headers

1xTrusted PlatformModule (TPM) header (2x6 pin, for the GC-TPM2.0_S

module only)

1xserial port header

1xspeaker header

1xchassis intrusion header

1xClear CMOSjumper

BackPanel

Connectors

1xPS/2 keyboard/mouse port

1xD-Subport

1xDVI-Dport

1xHDMI port

4 xUSB 3.2 Gen 1ports

2 xUSB 2.0/1.1 ports

1xRJ-45 port

1xQ-FlashPlus button

3 xaudio jacks

I/O Controller iTE®I/O Controller Chip

Hardware

Monitor

Voltage detection

Temperature detection

Fan speed detection

Overheatingwarning

Fan fail warning

Fan speed control

* Whether the fan speed control function is supported will depend on the fan you install.

- 7 -

BIOS1x128 Mbit ash

Use of licensed AMI UEFI BIOS

PnP1.0a, DMI 2.7, WfM2.0, SM BIOS2.7, ACPI 5.0

Unique Features Support for APP Center

* Available applications in APP Center may vary by motherboard model. Supported

functions of each application may also vary depending on motherboard specications.

- @BIOS

- EasyTune

- RGB Fusion

- Smart Backup

- System Information Viewer

Support for Q-Flash Plus

Support for Q-Flash

Bundled

Software

Norton®Internet Security (OEMversion)

LAN bandwidth management software

Operating

System

Support for Windows 11 64-bit

Support for Windows 10 64-bit

FormFactor Micro ATXFormFactor; 24.4cmx20.5cm

* GIGABYTE reserves the right to make any changes to the product specications and product-related information without

prior notice.

&Please visit the SERVICE/SUPPORT\Utility page on GIGABYTE's website to download the latest version

of apps.

https://www.gigabyte.com/Support/Utility/Motherboard?m=ut

- 8 -

2-3 Installing the CPU

2-4 Installing the Memory

Read the following guidelines before you begin to install the memory:

•Make sure that the motherboard supports the memory. It is recommended that memory of the same

capacity, brand, speed, and chips be used.

(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)

•Always turn off the computer and unplug the power cord from the power outlet before installing the

memory to prevent hardware damage.

•Memory modules have a foolproof design. A memory module can be installed in only one direction.

If you are unable to insert the memory, switch the direction.

DualChannelMemoryConguration

This motherboard provides two memory sockets and supports Dual Channel Technology. After the memory

is installed, the BIOS will automatically detect the specications and capacity of the memory. Enabling Dual

Channel memory mode will double the original memory bandwidth.

The two memory sockets are divided into two channels and each channel has one memory socket as following:

Channel A: DDR4_A1

Channel B: DDR4_B1

Read the following guidelines before you begin to install the CPU:

•Make sure that the motherboard supports the CPU.

(Go to GIGABYTE's website for the latest CPU support list.)

•Always turn off the computer and unplug the power cord from the power outlet before installing the

CPU to prevent hardware damage.

•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly.

•Apply an even and thin layer of thermal grease on the surface of the CPU.

•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage

of the CPU may occur.

•Set the CPU host frequency in accordance with the CPU specications. It is not recommended

that the system bus frequency be set beyond hardware specications since it does not meet the

standard requirements for the peripherals. If you wish to set the frequency beyond the standard

specications, please do so according to your hardware specications including the CPU, graphics

card, memory, hard drive, etc.

Installing the CPU

Completely lift up the CPU socket locking lever. Locate the pin one (denoted by a small triangle) of the CPU

socket and the CPU. Once the CPU is positioned into its socket, place one nger down on the middle of the

CPU, lowering the locking lever and latching it into the fully locked position.

AM4 Socket

A Small Triangle

Marking Denotes Pin

One of the Socket AM4 CPU

A Small Triangle

Marking Denotes CPU

Pin One

Completely lift up the CPU

socket locking lever

Do not force the CPU into the CPU socket before the CPU socket locking lever is lifted up, or

damage to the CPU and CPU socket may occur.

&Please visit GIGABYTE's website for details on hardware installation.

https://www.gigabyte.com/WebPage/210/quick-guide.html?m=sw

- 9 -

Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one memory module is installed.

2. When enabling Dual Channel mode with two memory modules, it is recommended that memory of

the same capacity, brand, speed, and chips be used.

2-5 Installing an Expansion Card

Read the following guidelines before you begin to install an expansion card:

•Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

•Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

2-6 Back Panel Connectors

USB 2.0/1.1 Port

The USB port supports the USB 2.0/1.1 specication. Use this port for USB devices.

PS/2 Keyboard/Mouse Port

Use this port to connect a PS/2 mouse or keyboard.

D-Sub Port (Note 1)

The D-Sub port supports a 15-pin D-Sub connector and supports a maximum resolution of 1920x1200@60 Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports D-Sub

connection to this port.

DVI-D Port (Note 1)(Note 2)

The DVI-D port conforms to the DVI-D specication and supports a maximum resolution of 1920x1200@60 Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports DVI-D

connection to this port.

HDMI Port (Note 1)

The HDMI port is HDCP 2.3 compliant and supports Dolby TrueHD and DTS HD Master

Audio formats. It also supports up to 192KHz/24bit 7.1-channel LPCM audio output.

You can use this port to connect your HDMI-supported monitor. The maximum supported resolution is

4096x2160@60 Hz, but the actual resolutions supported are dependent on the monitor being used.

•To set up a triple-display conguration, you must install motherboard drivers in the operating

system rst.

•After installing the HDMI device, make sure to set the default sound playback device to HDMI.

(The item name may differ depending on your operating system.)

•When removing the cable connected to a back panel connector, rst remove the cable from

your device and then remove it from the motherboard.

•When removing the cable, pull it straight out from the connector. Do not rock it side to side to

prevent an electrical short inside the cable connector.

Triple-DisplayCongurationsfortheOnboardGraphics:

Triple-display congurations are supported after you install motherboard drivers in OS. Only single display

is available during the BIOS Setup or POST process.

- 10 -

Inhaltsverzeichnis

Andere Gigabyte Hauptplatine Handbücher

Gigabyte

Gigabyte GA - 686LX3 Bedienungsanleitung

Gigabyte

Gigabyte GA-M52L-S3 Bedienungsanleitung

Gigabyte

Gigabyte GA-PICO3455 Bedienungsanleitung

Gigabyte

Gigabyte H510M DS2V Bedienungsanleitung

Gigabyte

Gigabyte GA-X99-UD4 Bedienungsanleitung

Gigabyte

Gigabyte B550 AORUS ELITE V2 Bedienungsanleitung

Gigabyte

Gigabyte GA-8TRS350MT Bedienungsanleitung

Gigabyte

Gigabyte GA-586TX Bedienungsanleitung

Gigabyte

Gigabyte GA-H77TN Bedienungsanleitung

Gigabyte

Gigabyte GA-H81M-D2W Bedienungsanleitung

Gigabyte

Gigabyte GA-Z68XP-UD3 Bedienungsanleitung

Gigabyte

Gigabyte GA-EG41MF-S2H Bedienungsanleitung

Gigabyte

Gigabyte GA-X99-UD3 Bedienungsanleitung

Gigabyte

Gigabyte GA-6VXC7-4X Bedienungsanleitung

Gigabyte

Gigabyte GA-780T-D3L Bedienungsanleitung

Gigabyte

Gigabyte GA-Q77M-D2H Bedienungsanleitung

Gigabyte

Gigabyte GA-G41MT-ES2L Bedienungsanleitung

Gigabyte

Gigabyte GA-6WFZ7 Bedienungsanleitung

Gigabyte

Gigabyte GA-H110M-S2PV Bedienungsanleitung

Gigabyte

Gigabyte GA-6JIEV2-RH Bedienungsanleitung

Gigabyte

Gigabyte Z790 AORUS ELITE AX ICE Bedienungsanleitung

Gigabyte

Gigabyte GA-8I875 Bedienungsanleitung

Gigabyte

Gigabyte GA-H81M-HD3 Bedienungsanleitung

Gigabyte

Gigabyte GA-X38-DS4 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
