Gigabyte GA-7VM Bedienungsanleitung

FCC Compliance Statement:

This equipment has been tested and found to

comply with limits for a Class B digital device ,

pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable

protection against harmful interference in

residential installations. This equipment

generates, uses, and can radiate radio

frequency energy, and if not installed and used

in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference

will not occur in a particular installation. If this

equipment does cause interference to radio or

television equipment reception, which can be

determined byturning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna

-Move the equipment away from the receiver

-Plug the equipment into an outlet on a circuit different from that to which

the receiver is connected

-Consult the dealer or an experienced radio/television technician for

additional suggestions

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void Your

authority to operate such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to

the following two conditions 1) this device may not cause harmful interference

and 2) this device must accept any interference received, including interference

that may cause undesired operation.

DECLARATION OF CONFORMITY

Per FCC Part 2 Section 2. 1077(a)

Responsible Party Name: G.B.T. INC.

Address: 18305 Valle

Blvd., Suite#A

LA Puent, CA 91744

Phone/Fax No: (818) 854-9338/ (818) 854-9339

hereby declares that the product

Product Name:

Model Number:

Mother Board

Conforms to the following specifications:

FCC Part 15,SubpartB, Section 15.107(a) and Section 15.109(a),

Class B Digital Device

Supplementary Information:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful

and (2) this device must accept any inference received, including

that may cause undesired operation.

Representative Person's Name: ERIC LU

Signature:

Date: Mar. 3, 2000

EricLu

GA-7VM

Declaration of Conformity

We, Manufacturer/Importer

(full address)

G.B.T. Technology Träding GMbH

Ausschlager Weg 41, 1F, 20537 Hamburg, Germany

declare that the product

( description of the apparatus, system, installation to which it refers)

Mother Board

GA-7VM

is in conformity with

(reference to the specification under which conformity is declared)

in accordance with 89/336 EEC-EMC Directive

EN 55011 Limits and methods of measurement EN 61000-3-2* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-2 by household appliances and similar

industrial, scientific and medical (ISM electrical equipment “Harmonics”

high frequency equipment

EN55013 Limits and methods of measurement EN61000-3-3* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-3 by household appliances and similar

broadcast receivers and associated electrical equipment “Voltage fluctuations”

equipment

EN 55014 Limits and methods of measurement EN 50081-1 Generic emission standard Part 1:

of radio disturbance characteristics of Residual, commercial and light industry

household electrical appliances,

portable tools and similar electrical EN 50082-1 Generic immunity standard Part 1:

apparatus Residual, commercial and light industry

EN 55015 Limits and methods of measurement EN 55081-2 Generic emission standard Part 2:

of radio disturbance characteristics of Industrial environment

fluorescent lamps and luminaries

EN 55020 Immunity from radio interference of EN 55082-2 Generic immunity standard Part 2:

broadcast receivers and associated Industrial environment

equipment

EN 55022 Limits and methods of measurement ENV 55104 Immunity requirements for household

of radio disturbance characteristics of appliances tools and similar apparatus

information technology equipment

DIN VDE 0855 Cabled distribution systems; Equipment EN 50091- 2 EMC requirements for uninterruptible

part 10 for receiving and/or distribution from power systems (UPS)

part 12 sound and television signals

CE marking (EC conformity marking)

The manufacturer also declares the conformity of above mentioned product

with the actual required safety standards in accordance with LVD 73/23 EEC

EN 60065 Safety requirements for mains operated EN 60950 Safety for information technology equipment

electronic and related apparatus for including electrical business equipment

household and similar general use

EN 60335 Safety of household and similar EN 50091-1 General and Safety requirements for

electrical appliances uninterruptible power systems (UPS)

Manufacturer/Importer

Signature : Rex Lin

(Stamp) Date : Mar. 3, 2000 Name : Rex Lin

R-11-04-000425

7VM

AMDTM Athlon AGP Motherboard

USER'S MANUAL

AMDTM Athlon Processor Motherboard

REV. 1.1 Fourth Edition

How this manual is organized

This manual is divided into the following sections:

1) Revision List Manual revision information

2) Item Checklist Product item list

3) Features Product information & specification

4) Hardware Setup Instructions on setting up the motherboard

5) Performance & Block Diagram Product Performance & Block Diagram

6) Suspend to RAM Instructions STR installation

7) BIOS Setup Instructions on setting up the BIOS

software

8) Appendix General reference

Table Of Content

Revision History P.1

Item Checklist P.2

Summary of Features P.3

7VM Motherboard Layout P.5

PageindexforCPUSpeedSetup/Connectors/PanelandJumperDefinition P.6

Performance List P.22

Block diagram P.23

Suspend to RAM Installation P.24

Memory Installation P.30

Page index for BIOSSetup P.31

Appendix P.61

7VM Motherboard

Revision History

Revision Revision Note Date

1.1 Initial release of the 7VM motherboard user’s manual. Mar. 2000

1.1 Second release of the 7VM motherboard user’s manual. Mar. 2000

1.1 Third release of the 7VM motherboard user’s manual. Mar. 2000

1.1 Fourth release of the 7VM motherboard user’s manual. Apr. 2000

The author assumes no responsibility for any errors or omissions that may appear in this

document nor does the author make a commitment to update the information contained herein.

Third-party brands and names are the property of their respective owners.

Apr. 25, 2000 Taipei, Taiwan, R.O.C

Item Checklist

;The 7VM Motherboard

;Cable for IDE / Floppy device

;Diskettes or CD (TUCD) for motherboard utilities

;7VM User’s Manual

7VM Motherboard

Summary Of Features

Form factor y 24.7 cmx 21.1 cm Micro ATX SIZE form factor, 4 layers PCB.

CPU y AMD Athlon(K7) Slot A Processor

y 512 KB 2nd cache in CPU Module

y Supports 500MHz ~ 1GHz and faster

Chipset Apollo KX133 ,consisting of:

y VIA8371 Memory/AGP/PCI Controller(PAC)

y VT82C686A PCI Super-I/O Integrated Peripheral

Controller (PSIPC)

Clock Generator y Supports 100~143MHz

Memory y 3 168-pin DIMM Sockets

y Supports SDRAM up to 1.5GB

y Supports only 3.3V SDRAM DIMM, PC-133 supported

I/O Control y VT82C686A

Slots y 1 AGP (Accelerated Graphics Port) slot

- AGP 66 / 133 MHz, 3.3V/1.5V device support

y 3 32-bit Master PCI Bus slots

y 1 AMR Slot

On-Board IDE y An IDE controller on the VT82C686A PCI chipset

provides IDE HDD/ CD-ROM with PIO, Bus Master ,

Ultra DMA/33, and ATA 66 Operation modes

y Can connect up to four IDE devices

On-Board

Peripherals y 1 Floppy port supports 2 FDD with 360K, 720K,1.2M,

1.44M and 2.88M bytes

y 1 Parallel port supports SPP/EPP/ECP mode

y 2 Serial Ports (COM 1 & COM 2)

y 4 USB ports

y 1 IrDA connector for Fast IrDA

Hardware Monitor

(Optional) y CPU/Power Supply/Panel Fan Revolution detect

y System Voltage Detect

y CPU Overheat Warning

y Display Actual Current Voltage

To be continued…

Summary Of Features

PS/2 Connector y PS/2Keyboard interface and PS/2Mouse interface

BIOS y Licensed AMI BIOS, 2M bit FLASHRAM

Additional Features y Internal/External Modem Wake up

y STR (Suspend-To-RAM)

y LAN Wake up

y System after AC back
