Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)

mITX-Q47EA (MQ47EAI-SI)

mITX-Q47EA Mini-ITX Motherboard

User’s Manual 1st Ed

www.gigaipc.com

This document is copyrighted, 2021. All rights are reserved. The

original manufacturer reserves the right to make improvements to the

products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translat¬ed, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no respon¬sibility for its use, or for any

in¬fringements upon the rights of third parties that may result from its

use.

The material in this document is for product information only and

is subject to change without notice. While reasonable efforts have

been made in the preparation of this document to assure its accuracy,

GIGAIPC assumes no liabilities resulting from errors or omissions in this

document, or from the use of the information contained herein.

GIGAIPC reserves the right to make changes in the product design

without notice to its users.

3www.gigaipc.com

Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)

Acknowledgement

All other products’ name or trademarks are properties of their

respective owners.

• AMD® is trademark of Advanced Micro Devices.

• Microsoft Windows is a registered trademark of Microsoft Corp.

• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel

Corporation

• Core, Atom are trademarks of Intel Corporation

• ITE is a trademark of Integrated Technology Express, Inc.

• IBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

All other product names or trademarks are properties of their

respective owners.

www.gigaipc.com

Packing List

Before setting up your product, please make sure the following items

have been shipped:

Item Quantity

mITX-Q47EA MB 1

SATA power cable 2

I/O Bracket 1

If any of these items are missing or damaged, please contact your

distributor or sales representative immediately.

5www.gigaipc.com

Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)

About this Document

This User’s Manual contains all the essential information, such as

detailed descriptions and explanations on the product’s hardware

and software features (if any), its specifications, dimensions, jumper/

connector settings/definitions, and driver installation instructions (if

any), to facilitate users in setting up their product.

Users may refer to the GIGAIPC.com for the latest version of this

document.

www.gigaipc.com

Safety Precautions

Please read the following safety instructions carefully. It is advised that

you keep this manual for future references

1. All cautions and warnings on the device should be noted.

2. Make sure the power source matches the power rating of the

device.

3. Position the power cord so that people cannot step on it. Do

not place anything over the power cord.

4. Always completely disconnect the power before working on the

system’s hardware.

5. No connections should be made when the system is powered

as a sudden rush of power may damage sensitive electronic

components.

6. If the device is not to be used for a long time, disconnect it from

the power supply to avoid damage by transient over-voltage.

7. Always disconnect this device from any AC supply before

cleaning.

8. While cleaning, use a damp cloth instead of liquid or spray

detergents.

9. Make sure the device is installed near a power outlet and is

easily accessible.

10. Keep this device away from humidity.

11. Place the device on a solid surface during installation to prevent

falls

12. Do not cover the openings on the device to ensure optimal heat

dissipation.

7www.gigaipc.com

Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)

13. Watch out for high temperatures when the system is running.

14. Do not touch the heat sink or heat spreader when the system is

running

15. Never pour any liquid into the openings. This could cause fire or

electric shock.

16. As most electronic components are sensitive to static electrical

charge, be sure to ground yourself to prevent static charge

when installing the internal components. Use a grounding

wrist strap and contain all electronic components in any static-

shielded containers.

17. If any of the following situations arises, please the contact our

service personnel:

i. Damaged power cord or plug

ii. Liquid intrusion to the device

iii. Exposure to moisture

iv. Device is not working as expected or in a manner as described

in this manual

v. The device is dropped or damaged

vi. Any obvious signs of damage displayed on the device

18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED

ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S

PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO

PREVENT DAMAGE.

www.gigaipc.com

FCC Statement

This device complies with Part 15 FCC Rules. Operation

is subject to the following two conditions: (1) this device

may not cause harmful interference, and (2) this device

must accept any interference received including

interference that may cause undesired operation.

Caution:

There is a danger of explosion if the battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dispose of used

batteries according to the manufacturer’s instructions and your local government’s

recycling or disposal directives.

Attention:

Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.

Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le

constructeur. Recycler les batteries usées en accord avec les instructions du fabricant

et les directives gouvernementales de recyclage.

9www.gigaipc.com

Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)

China RoHS Requirements (CN)

产品中有毒有害物质或元素名称及含量

GIGAIPC Main Board/ Daughter Board/ Backplane

部件名称

有毒有害物质或元素

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

印刷电路板

及其电

子组件

○ ○ ○ ○ ○ ○

外部信号

连接器

及线材

○ ○ ○ ○ ○ ○

O：表示该有毒有害物质在该部件所有均质材料中的含量均在

SJ/T 11363-2006 标准规定的限量要求以下。

X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出

SJ/T 11363-2006 标准规定的限量要求。

备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。

www.gigaipc.com

China RoHS Requirement (EN)

Poisonous or Hazardous Substances or Elements in Products

GIGAIPC Main Board/ Daughter Board/ Backplane

Component

Poisonous or Hazardous Substances or Elements

Lead

(Pb)

Mercury

(Hg)

Cadmium

(Cd)

Hexavalent

Chromium

(Cr(VI))

Polybrominated

Biphenyls

(PBB)

Polybrominated

Diphenyl Ethers

(PBDE)

PCB & Other

Components O O O O O ○

Wires &

Connectors

for External

Connections

O O O O O O

O：The quantity of poisonous or hazardous substances or elements found in each

of the component's parts is below the SJ/T 11363-2006-stipulated requirement.

X: The quantity of poisonous or hazardous substances or elements found in at least

one of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.

Note: The Environment Friendly Use Period as labeled on this

product is applicable under normal usage only
