Glab MAC-4.4 Bedienungsanleitung

Instrukcja obsługi

User Manual

Bedienungsanleitung

MIDI AMP CONTROLLER

MAC-4.4

Dear Customer!

Thank you for choosing our product.

MIDI AMP CONTROLLER MAC-4.4 is an adaptor that enables to control (switch

the channels, switch on/off other functions) the amps equipped with EXTERNAL

SWITCHING or FOOTSWITCH inputs. MAC-4.4 should be controlled by programmable

MIDI controller (which enables to program and send chosen MIDI PROG CHANGE or

CTRL CHANGE commands for any controller’s preset). Control output signals are lead

to terminal strip that enables to connect up to eight JACK MONO plugs or cable

connected to amp’s FOOTSWITCH INPUT.

Basic characteristics:

- MIDI IN input and MIDI THRU output

- four separated relay outputs to switch an amp’s channels, controlled on the „one

of four” principle

- four separated relay outputs to switch an amp’s functions, with independent

controlling of each function

- rotatable switch to set MIDI channel (1 to 16)

- control commands select switches (Program Change and/or Control Change)

- power supply mode switch (from 9V connector or by PHANTOM MIDI IN).

Edition 1.4

Structure

1 - MIDI IN connector 6 - 9V power supply connector

2 - MIDI THRU connector 7 - power supply mode switch

3 - MIDI channel switch 8 - cable clamp

4 - Pr.Ch. microswitch 9 - outputs’ state indicators

5 - Ctrl Ch microswitch 10 - fixing cover for connected cables

MIDI channel setting

To set the MIDI channel the amp receive the commands on serves the MIDI

CHANNEL rotatable switch. To change the channel use a small screw and turn it a little

right or left. The arrow-head indicates set channel (A, B, C, D, E, F letters correspond

with 10, 11, 12, 13, 14, 15 channels’ numbers and “0” digit indicates channel No. 16).

Connecting to amp with EXTERNAL SWITCHING inputs

In case of connecting to the amps

equipped with EXTERNAL SWITCHING

connectors JACK MONO type it is needed to

use for every connector the double wire cable

with JACK MONO pin. It is recommended to

use the G LAB EXT SWT JACK MONO cables

(product code 00852). In case of making the

cables by yourself it is recommended to use

JACK plugs with the insulated (e.g. plastic)

cage.

To connect the cables remove the fixing cover. After connecting them put it back,

press down and tight up (see the picture below).

Connecting to the Bogner Ecstasy 101B amp

MAC 4.4 version for the Ecstasy 101B amp is equipped with 5 meters long cable with

the pin for the amp FOOTSWITCH input. Controller enables choosing of the channels

(No. 1, 2 or 3) and controlling the functions: BOOST1 (SWITCH OUT 5), BOOST2

(SWITCH OUT 6), FX LOOP (SWITCH OUT 7) and STANDBY (SWITCH OUT 8).

Controlling via MIDI commands

MAC-4.4 can be controlled by Program

Change and/or Control Change commands.

To choose the commands’ type received by the

controller use the Pr.Ch. and Ctrl Ch micro-

switches. ON position indicates that the

commands will be received.

In case of using Program Change command

the program number should be counted by

following formula:

Program number= amp channel number + SUM

SUM = 0 + 4 (if the output No. 5 is active) + 8

(if the output No. 6 is active) + 16 (if the output

No. 7 is active) + 32 (if the output No. 8 is active)

SWITCH OUT

5678

+4 +8 +16 +32 SUM

OFF OFF OFF OFF 0

ON OFF OFF OFF 4

OFF ON OFF OFF 8

ON ON OFF OFF 12

OFF OFF ON OFF 16

ON OFF ON OFF 20

OFF ON ON OFF 24

ON ON ON OFF 28

OFF OFF OFF ON 32

ON OFF OFF ON 36

OFF ON OFF ON 40

ON ON OFF ON 44

OFF OFF ON ON 48

ON OFF ON ON 52

OFF ON ON ON 56

ON ON ON ON 60

In the table below are shown the controllers’

numbers and functions. Controllers from 14 to 18

serve for individual control on every function and the

controller number 19 function similarly to the

Program Change command (sets the amp channel

and other amp functions).

Power supply

MAC should be supplied with 9V (DC) external adaptor with current 0,15 A or

more. It can be also supplied from MIDI IN (MIDI PHANTOM) connector via MIDI cable.

In such case it is needed to use the five wire MIDI cable and to set the power supply

switch on MIDI IN PHANTOM mode. Together with the device comes the adaptor

serving to divide the supply and the MIDI signal.
