Solar Powered LED Sign
072318
21
globalindustrial.ca
Assembly Instructions Instrucciones de Ensamblaje Directives d’assemblage
Customer Service
US: 1-800-645-2986
Servicio de atención al Cliente
US: 1-800-645-2986
Service à la clientèle
Canada: 888-645-2986
CONTENTS
Ref. Qty. Description Ref. Qty. Description
1 1 Flashing Sign H6 412mm Diameter Plain Washer
2 1 Solar Panel Assembly
3 2 Pole Mounting Bracket H7 412mm Diameter Lock Washer
H1 1M10 x 1.5 x 25mm Lg.
Torx Pan Head Bolt H8 4M12 x 1.50
Hex Nut
H2 110mm Diameter
Lock Washer H9 28mm Diameter
Plain Washer
H3 110mm Diameter
Plain Washer H10 28mm Diameter
Lock Washer
H4 4M12 x 1.50 x 45mm Lg. T-Bolt H11 2M8 x 1.25 Hex Nut
H5 2M8 x 1.25 x 45mm Lg. T-Bolt 1Torx Allen Key
1AC Charger
Models 708312 708313
Connect solar panel
assembly to the sign
by connecting male
end of black chord
to female end and
screwing together.
Tighten with
torx allen key.
See
Detail A
Detail A
H1
2
1
H2
H3
WARNING
• Before proceeding with any assembly, installation,
maintenance, and/or troubleshooting, read all Warnings.
Failure to pay attention to them could result in serious injury
or death.
• Use OSHA- approved Protective Clothing and Devices,
Cut-proof Gloves, and Safety Glasses for all procedures.
Failure to do so could result in serious injury or death.
• Solar panels produce an electrical current. To reduce the
risk of injury, use shock-proof gloves and never perform any
procedure in or near standing water.
• Batteries must be disposed of according to local code.
DO NOT INCINERATE! Failure to heed this warning could
result in serious injury or death.
