GlobalScale MOCHABIN-V1 Bedienungsanleitung

MOCHABIN-V1 Quick Start Guide page: 1 / 39

1/ 39

MOCHABIN-V1 PCBA - Quick Start Guide

Rev 02- Aug 31, 2021

Revision History

Date Revision Board Rev Description

Jan 29, 2020 Rev 01 V0-0-0

Apr 23, 2021 Rev 02 V1-1-0

Aug 31,2021 Rev 02 V1-1-0 Mark SW2 reset switch on page

MOCHABIN-V1 Quick Start Guide page: 2 / 39

2/ 39

Index

A. Appearance........................................................................................................................................ 4

B. Package contents.............................................................................................................................. 6

C. Key Features...................................................................................................................................... 7

D. I/O ports on PCBA............................................................................................................................. 8

D-1. Top side................................................................................................................................................. 8

D-2. Bottom side......................................................................................................................................... 11

E. User interfaces................................................................................................................................. 12

E-1. J2- JTAG debugger Pin definition ............................................................................................ 12

E-1-2. J2- JTAG debugger schematic........................................................................................... 12

E-2. J6- Mikrobus- Pin definition ...................................................................................................... 13

E-2-2. J6- Mikrobus- Schematic ....................................................................................................... 13

E-3. J29 FAN Power connector ........................................................................................................ 14

E-3-2. J29- Schematic ....................................................................................................................... 14

E-4. J1, J2, J3, J4, J5, J6 on WiFi ax-BT module .......................................................................... 15

E-5. J5 mini-PCIe LED ...................................................................................................................... 16

E-6. J4 M.2-2280-B-key LED............................................................................................................ 17

E-7. Micro SIM connector-J38 .......................................................................................................... 18

F. Bootstrap wire jumpers....................................................................................................................... 19

F-1. CPU Clock – J14, J15, J16 ....................................................................................................... 19

F-2. Boot Mode – J17, J18, J19, J20, J21, J22.............................................................................. 20

G. Block Diagram ................................................................................................................................. 24

H. Cable connection for testing .......................................................................................................... 25

I. Preparation for power on.................................................................................................................... 26

H-1. Hardware: ................................................................................................................................... 26

H-2. Software:..................................................................................................................................... 26

J. Find com port and connect with putty............................................................................................... 27

K. Start running MOCHABIN ......................................................................................................... 29

J-1. Check U-boot version and some system information ............................................................ 29

J-2. login name:“root” password: “admin” ....................................................................................... 30

J-3. Check the kernel version ........................................................................................................... 30

J-4. Check the CPU information....................................................................................................... 31

J-4.1 check with command “cat /proc/cpuinfo” ............................................................................ 31

J-4.2 check with lscpu command .................................................................................................. 32

J-5. Check the memory information................................................................................................. 32

MOCHABIN-V1 Quick Start Guide page: 3 / 39

3/ 39

J-6. Check the network information ................................................................................................. 33

J-6.1 check with ifconfig command ............................................................................................... 33

J-6.2 Using ping command to verify internet connection ........................................................... 35

J-7. Check the USB3.0 ports ............................................................................................................ 35

J-7.1 check USB device without USB disk plugged.................................................................... 35

J-7.2 check USB device with 2 USB disks plugged.................................................................... 36

J-7.3 check disk partitions .............................................................................................................. 36

J-7.4 check disk partitions with “df” command............................................................................. 37

J-7.5 check disk partitions with “fdisk -l” command..................................................................... 37

J-8. top command............................................................................................................................... 39

J-9. Other useful commands like “lspci” and “lsmod” .................................................................... 39

MOCHABIN-V1 Quick Start Guide page: 4 / 39

4/ 39

A. Appearance

Optional

MOCHABIN-V1 Quick Start Guide page: 5 / 39

5/ 39

MOCHABIN-V1 Quick Start Guide page: 6 / 39

6/ 39

B. Package contents

Note *1: There are two SKUs, MOCHABIN-V1 PCBA and MOCHABIN-V1 BOX, this Quick Start Guide is for the MOCHABIN-V1 PCBA

Content List Qti Std/ Opt Remark

1 MOCHABIN PCBA 1 unit standard *1

2 AC to DC 12V Power Adapter 1 pc standard Input 90-240VAC / output 12V,3A

DC (optional)

3 Micro USB to USB type-A cable

1 pc optional For debug console use

4 Warranty card 1 pc standard

MOCHABIN-V1 Quick Start Guide page: 7 / 39

7/ 39

C. Key Features

SoC

• Marvell ARMADA 88F7040

• Quad-Core ARMv8 Cortex-A72

• CPU frequency @1400MHz

Memory • 4 GB / 8GB DDR4 -8bit (8bitx8)

Storage

• 4MB SPI NOR flash

• 16GB eMMC flash

• M.2 SSD socket for expansion

Ethernet

• 1x 10 Gb SFP+, fiber optic

• 1x 1Gb SFP, fiber optic

• 1x 1Gb RJ45 WAN

• 3x 1GB RJ45 LAN

• 1x 1GB RJ45 LAN with PoE

Wireless • 802.11 2x2 WiFi ax + BT5 mini-PCIe module - optional

USB • 2x USB 3.0 type-A female

Expansion

• 16-pin (2x8) MikroBus connector

• 1x Mini-PCIe 3.0 (for WiFi ax module)

• 1x M.2-2250 B-key socket

• 1x M.2-2280 B-key socket (for SSD expansion)

• 1x SATA 7+15 socket

• 1x microbus-8x2 socket

• 1x SIM card slot-connect to all 3 connectors as mini-PCIe, M.2 2250 and M.2 2280

Debugging • 1x Cortex 2x5 JTAG

• 1x micro USB UART connector

Miscellaneous

• DC 12V Power Jack-5.5x2.1mm

• Power on/off button

• Reset button

LEDs

• 1x power on LED (3.3V)

• 3x tri-color status LEDs

• 1x M.2-2280 socket LED (reserved for SATA)

• 1x mini PCIe socket LED (reserved for WiFi)

MOCHABIN-V1 Quick Start Guide page: 8 / 39

8/ 39

D. I/O ports on PCBA

D-1. Topside

MOCHABIN-V1 Quick Start Guide page: 9 / 39

9/ 39

No Part location Name Description

1 BAT1 CR2032 /3.3V RTC power

2 J29 3-pin 2.0mm pitch FAN

header

*see section E-3

3 J6 Mikrobus socket For Mikrobus expansion board

*see section E-2

4 U12 SPI NOR Flash 4MB

5 U11 eMMC 16GB

6 J17,J18,J19,J29,J21,J22 Boot option selection *See section F-2

7 J14,J15,J16 CPU speed selection *See section F-1

8 SW1 switch Power on/off switch

9 U3, U4, U5, U6 SDRAM 1st bank DDR4 8bit x4

10 LED7 Green LED 3.3V power ready

11 LED6 Tri-color RGB LED Soft controlled I2C interface

12 LED5 Tri-color RGB LED Soft controlled I2C interface

13 LED4 Tri-color RGB LED Soft controlled I2C interface

MOCHABIN-V1 Quick Start Guide page: 10 / 39

10 / 39

Note 1:

1) J12 and J13 are the same eth2 port with different form factor, either RJ45 or SFP

2) J10 is a 10Gb SFP+ eth0 port

3) Eth0 and eth2 are network bonded in mode-1(active backup) as the same WAN port with eth2 set to bond-primary. This

means eth0 will be active only when eth2 doesn’t exist or fails.

No Part location Name Description

14 U1 SoC-Marvell 88F7040 @1400NHz

15 J4 M.2-2080-B key socket Reserved for SSD expansion

16 J2 JTAG Debugger 5x2 pins, *see section E-1

17 J5 Mini-PCIe socket Reserved for WiFi ax 2x2 + BT5 module

18 WiFi-J1/J2/J3 W.FL antenna connector *see section E-4

19 WiFi-J4/J5/J6 WiFi configuration *see section E-4

20 J38 SIM sleeve Connects to J4, J5 and J39 *see section E-7

21 LED2 WiFi LED for J5 Not populated *see section E-5

22 J40 Header for external WiFi LED Pin1-anode, pin2-cathode

23 LED1 SSD LED for J4 Not populated *see section E-6

24 J34 Header for external SSD LED Pin1-anode, pin2-cathode

25 J39 M.2-2250 B-key Reserved for 4G/LTE/5G module

26 J24 7+12 SATA connector For SATA expansion

27 J10 SFP+ eth0 10Gb WAN Fiber connector (see note 1)

28 J13 SFP eth2 1Gb WAN Fiber connector (see note 1)

29 M1 PoE module 802.3at/af 30W PoE module, power from J12

30 J12 Gb RJ45 with PoE- eth2 WAN with PoE input (see note 1)

31 J9 J9A, J9B, J9C, J9D 1Gb RJ45 for WANx1 and LANx3

32 J31 Dual ports USB3.0 type-A

female

33 J3 Micro-USB for debug console For debug console only

34 J23 +12V DC in DC Jack 5.5x2.1mm
