Gordon 93499 Bedienungsanleitung

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web site at: http://www.harborfreight.com

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions and replacement parts, please call 1-800-444-3353.

TO PREVENT SERIOUS INJURY,

READ AND UNDERSTAND ALL WARNINGS

AND INSTRUCTIONS BEFORE USE.

TABLETOP PAPER SHREDDER

Model 93499

Due to continuing improvements, actual product may differ slightly from the product described herein.

For technical questions, please call 1-800-444-3353. Page 2

SKU 93499

PRODUCT SPECIFICATIONS

SAVE THIS MANUAL

You will need this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures, parts list and as-

sembly diagram. Keep your invoice with this manual. Write the invoice number

on the inside of the front cover. Keep this manual and invoice in a safe and dry

place for future reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS

Failure to follow all instructions listed below may result in

electric shock, fire, and/or serious injury.

SAVE THESE INSTRUCTIONS

WORK AREA

1. Keep your work area clean and well lit. Cluttered benches and dark areas

invite accidents.

2. Do not operate Paper Shredders in explosive atmospheres, such as in the

presence of flammable liquids, gases, or dust. Paper Shredders create

sparks which may ignite the dust or fumes.

3. Keep bystanders, children, and visitors away while operating a Paper

Shredder. Distractions can cause you to lose control.

Note: This unit works on “AA” batteries or on an AC Adapter that is NOT in-

cluded. The following manual addresses safety issues for both applications.

Waste Basket Dimensions 1-3/8” L x 4-1/4” W x 4-5/16” H

Strip Size 0.14” Wide

Cutter Housing Dimensions 10-1/2” L x 4-3/4” W x 1-3/4” H

Sheet Capacity 1 (#20WT.)

Power Source 6 “AA” Batteries or 120 Volts AC,

DC9V 1.2A Adapter (not included)

Weight 1.65 Lbs.

For technical questions, please call 1-800-444-3353. Page 3

SKU 93499

ELECTRICAL SAFETY

4. Grounded tools must be plugged into an outlet properly installed and

grounded in accordance with all codes and ordinances. Never remove the

grounding prong or modify the plug in any way. Do not use any adapter

plugs. Check with a qualified electrician if you are in doubt as to whether

the outlet is properly grounded. If the tools should electrically malfunction or

break down, grounding provides a low resistance path to carry electricity away

from the user.

5. Double insulated tools are equipped with a polarized plug (one blade is

wider than the other). This plug will fit in a polarized outlet only one way. If

the plug does not fit fully in the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician to install a polarized outlet. Do not

change the plug in any way. Double insulation eliminates the need for the

three wire grounded power cord and grounded power supply system.

6. Avoid body contact with grounded surfaces such as pipes, radiators,

ranges, and refrigerators. There is an increased risk of electric shock if your

body is grounded.

7. Do not expose Paper Shredders to rain or wet conditions. Water entering a

Paper Shredder will increase the risk of electric shock.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools

or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,

sharp edges, or moving parts. Replace damaged Power Cords immedi-

ately. Damaged Power Cords increase the risk of electric shock.

9. When operating a Paper Shredder outside, use an outdoor extension cord

marked “W-A” or “W”. These extension cords are rated for outdoor use, and

reduce the risk of electric shock.

PERSONAL SAFETY

10. Stay alert. Watch what you are doing, and use common sense when oper-

ating a Paper Shredder. Do not use a Paper Shredder while tired or under

the influence of drugs, alcohol, or medication. A moment of inattention while

operating Paper Shredders may result in serious personal injury.

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.

Keep your hair, clothing, and gloves away from moving parts. Loose

clothes, jewelry, or long hair can be caught in moving parts.

For technical questions, please call 1-800-444-3353. Page 4

SKU 93499

12. Avoid accidental starting. Be sure the Power Switch is off before plugging

in. Plugging in Paper Shredders with the Power Switch on, invites accidents.

TOOL USE AND CARE

13. Do not force the Paper Shredders. Allow the Shredder to work at its own

speed.

14. Do not use the Paper Shredder if the Power Switch does not turn it on or

off. Any Paper Shredder that cannot be controlled with the Power Switch is

dangerous and must be replaced.

15. Disconnect the Power Cord Plug from the power source before making any

adjustments, changing accessories, or storing the Shredder. Such preven-

tive safety measures reduce the risk of starting the Shredder accidentally.

16. Store idle Paper Shredders out of reach of children and other untrained

persons. Paper Shredders are dangerous in the hands of untrained users.

17. Maintain Paper Shredders with care. Keep blades sharp and clean. Prop-

erly maintained Shredders with a sharp cutting edge are less likely to bind and

are easier to control. Do not use a damaged tool. Tag damaged tools “Do not

use” until repaired.

18. Check for misalignment or binding of moving parts, breakage of parts, and

any other condition that may affect the Shredder’s operation. If damaged,

have the Shredder serviced before using.

For technical questions, please call 1-800-444-3353. Page 5

SKU 93499

SERVICE

20. Service must be performed only by qualified repair personnel. Service

or maintenance performed by unqualified personnel could result in a risk of injury.

21. When servicing a Shredder, use only identical replacement parts. Follow

instructions in the

“Inspection, Maintenance, And Cleaning”

section of this

manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

SPECIFIC SAFETY RULES

1. Maintain labels and nameplates on the Paper Shredder. These carry impor-

tant information. If unreadable or missing, contact Harbor Freight Tools for a

replacement.

2. Keep Children Away. The paper shredder is not a toy.

3. Always keep the extension cord away from moving parts on the Shredder.

4. Avoid unintentional starting. Make sure you are prepared to begin work

before turning on the Paper Shredder.

5. Do not force the Paper Shredder. This Paper Shredder has a two minute on,

15 minute off cycle. If it is not observed, it may overheat or blow the fuse. Also,

observe the one sheet maximum. Overloading may damage the unit.

6. Never leave the Paper Shredder unattended when it is plugged into an

electrical outlet. Turn off the Shredder, and unplug it from its electrical outlet

before leaving.

7. Do not put paper with paperclips, staples, or folds through the Paper

Shredder. Doing so will damage the unit.

8. Keep the cooling vents on the bottom of the Paper Shredder clear and

uncovered. Covering the cooling vents will cause the unit to overheat.

9. WARNING! People with pacemakers should consult their physician(s) before

using this product. Electromagnetic fields in close proximity to a heart pace-

maker could cause interference to or failure of the pacemaker.

For technical questions, please call 1-800-444-3353. Page 6

SKU 93499

GROUNDING

WARNING!

Improperly connecting the grounding wire can result in the risk of electric

shock. Check with a qualified electrician if you are in doubt as to whether the

outlet is properly grounded. Do not modify the power cord plug provided with

the tool. Never remove the grounding prong from the plug. Do not use the

tool if the power cord or plug is damaged. If damaged, have it repaired by

a service facility before use. If the plug will not fit the outlet, have a proper

outlet installed by a qualified electrician.

GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS

1. Tools marked with “Grounding Required” have a three wire cord and three prong

grounding plug. The plug must be connected to a properly grounded outlet. If

the tool should electrically malfunction or break down, grounding provides a low

resistance path to carry electricity away from the user, reducing the risk of elec-

tric shock. (See Figure A.)

2. The grounding prong in the plug is connected through the green wire inside the

cord to the grounding system in the tool. The green wire in the cord must be the

only wire connected to the tool’s grounding system and must never be attached

to an electrically “live” terminal. (See Figure A.)

3. Your tool must be plugged into an appropriate outlet, properly installed and

grounded in accordance with all codes and ordinances. The plug and outlet

should look like those in the following illustration. (See Figure A.)

FIGURE A

For technical questions, please call 1-800-444-3353. Page 7

SKU 93499

FIGURE B

DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS

4. Tools marked “Double Insulated” do not require grounding. They have a special

double insulation system which satisfies OSHA requirements and complies with

the applicable standards of Underwriters Laboratories, Inc., the Canadian

Standard Association, and the National Electrical Code. (See Figure B.)

5. Double insulated tools may be used in either of the 120 volt outlets shown in the

following illustration. (See Figure B.)

EXTENSION CORDS

Grounded

tools require a three wire extension cord.

Double Insulated

tools

can use either a two or three wire extension cord.

2. As the distance from the supply outlet increases, you must use a heavier gauge

extension cord. Using extension cords with inadequately sized wire causes a

serious drop in voltage, resulting in loss of power and possible tool damage.

(See Figure C, next page.)

3. The smaller the gauge number of the wire, the greater the capacity of the cord.

For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.

(See Figure C.)

4. When using more than one extension cord to make up the total length, make

sure each cord contains at least the minimum wire size required.

(See Figure C.)

5. If you are using one extension cord for more than one tool, add the nameplate

amperes and use the sum to determine the required minimum cord size.

(See Figure C.)

For technical questions, please call 1-800-444-3353. Page 8

SKU 93499

6. If you are using an extension cord outdoors, make sure it is marked with the

suffix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.

7. Make sure your extension cord is properly wired and in good electrical condition.

Always replace a damaged extension cord or have it repaired by a qualified

electrician before using it.

8. Protect your extension cords from sharp objects, excessive heat, and damp or

wet areas.

SYMBOLOGY

Double Insulated

Canadian Standards

Association

Underwriters

Laboratories, Inc.

Volts Alternating Current

Amperes

No Load Revolutions

per Minute (RPM)

noxxxx/min.

V ~

RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*

(120 VOLT)

NAMEPLATE

AMPERES

(At Full Load) EXTENSION CORD LENGTH

25 FEET 50 FEET 75 FEET 100 FEET 150 FEET

0 - 2.0 18 18 16 16 16

2.1 - 3.4 18 18 16 14 14

3.5 - 5.0 18 18 16 14 12

5.1 - 7.0 18 16 14 12 12

7.1 - 12.0 16 14 12 10 -

12.1 - 16.0 14 12 10 - -

16.1 - 20.0 12 10 - - -

FIGURE C *Based on limiting the line voltage drop

to five volts at 150% of the rated amperes.

For technical questions, please call 1-800-444-3353. Page 9

SKU 93499

UNPACKING

When unpacking, check to make sure that the product is intact and undamaged. If any

parts are missing or broken, please call Harbor Freight Tools at the number shown on the

cover of this manual as soon as possible.

ASSEMBLY AND OPERATING INSTRUCTIONS

CAUTION: Always make sure the Power Cord of the Paper Shredder is un-

plugged from its electrical outlet

prior

to installation.

FIGURE 1

Switch

For technical questions, please call 1-800-444-3353. Page 10

SKU 93499

To remove or replace the “AA” batteries, open the plastic lid on the bottom of the unit.

Remove the old and replace with new batteries making sure that the polarity on the

batteries match the polarity on the battery housing.

Caution: Do not put paper with paper clips, staples, or folds through the Paper

Shredder. Doing so will damage the unit.

1. Set the Paper Shredder into place and make sure it sits securely on the Waste

Bin.

Caution!! Make sure clothing or long hair stay clear of the unit.

2. Turn the Switch (See FIGURE 1) to the ON position. Plug in the unit. Insert a

piece of paper into the Feed Slot until the Paper Shredder grabs the paper and

draws it in.

Note: If you want to back out a piece of paper that is in the unit, turn it off, then turn the

Switch to reverse.

3. When you are finished shredding, turn off the unit and unplug it from the power

outlet.

FIGURE 2

Caution! Do not use an AC adapter if you are using non-rechargeable batteries. An

AC adapter will try to charge the batteries and in doing so will damage the unit.You may

use an AC adapter with rechargeable batteries. An AC adapter is not included.

Note: Paper jamming and the machine stopping may be an indication that too much

paper has been inserted. Set the switch to reverse and remove excess paper. Turn the

unit off and allow it to cool before restarting.

Caution! This unit has a two minute on, fifteen minute off cycle. If it is not observed,

it may overheat. Also, observe the one sheet maximum. Overloading may damage

the unit.

Inhaltsverzeichnis

Andere Gordon Aktenvernichter Handbücher

Gordon

Gordon 93520 Bedienungsanleitung

Beliebte Aktenvernichter Handbücher anderer Marken

Swingline

Swingline STACK-AND-SHRED200X&200XL 60X Bedienungsanleitung

GBC

GBC ShredMaster CC055 Bedienungsanleitung

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Bedienungsanleitung

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Bedienungsanleitung

Rexel

Rexel Optimum AutoFeed+ 45X Bedienungsanleitung

Martin Yale

Martin Yale 227284S1 Bedienungsanleitung

Bonsaii

Bonsaii DocShred C223-A Bedienungsanleitung

HSM

HSM Pure 740 max Bedienungsanleitung

TRU RED

TRU RED TR-BMC20A Bedienungsanleitung

Fellowes

Fellowes 50S Bedienungsanleitung

GBC

GBC SHREDMASTER 1236SE Bedienungsanleitung

Gude

Gude GH 2600 P Bedienungsanleitung

Ativa

Ativa DQ80M Bedienungsanleitung

Q-Connect

Q-Connect Q8CC Bedienungsanleitung

Fellowes

Fellowes POWERSHRED C-325CI Bedienungsanleitung

Olivetti

Olivetti Privacy 5000C Kurzanleitung

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Bedienungsanleitung

Dahle

Dahle paperSAFE 22022 Bedienungsanleitung
