Gorenje RF4142ANW Bedienungsanleitung
GB Instructions for use
Refrigerator-freezer
Kühlschrank mit Gefrierfach
Réfrigérateur congélateur
Hladilnik z zamrzovalnikom
Hladnjak s ledenicom
Frižider sa zamrzivačem
DE Gebrauchsanweisung
FR Notice d’utilisation
SI Navodilo za uporabo
BIH Upute za uporabu
HR
BIH Uputstva za upotrebu
SRB MNE
Important warnings ..................................................... 3
A few tips on how to save power with your
refrigerator-freezer combo ........................................ 4
Appliance description ................................................. 5
Installation and connection ........................................ 6
Changing the direction of door opening ................... 7
Operating the appliance ............................................. 9
Recommended food arrangement
in the appliance ......................................................... 11
Storing food in the refrigerator ................................ 12
Freezing fresh food and storing frozen food .......... 13
Defrosting the appliance ........................................... 15
Cleaning the appliance ............................................. 16
Troubleshooting ........................................................ 17
Information on appliance noise ............................... 18
We thank you for the confi dence you have shown by purchasing our appliance.
We wish you a lot of pleasure using the appliance.
The appliance is intended solely for household use.
The refrigerator-freezer is intended for use in households.
The lower part is the refrigerator compartment intended for storing fresh food at temperatures
above 0°C.
The upper part is the freezer compartment intended for freezing fresh food and long-term storage
of frozen food (up to one year, depending on the type of food). This compartment is labeled with
four stars / asterisks.
EN
Refrigerator-freezer
2
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or metal capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
• Before connecting the appliance, carefully read the instructions for use which describe the appliance
and its correct and safe use. The instructions apply to several types / models; therefore, they may
include descriptions of settings and equipment that may not be available in your appliance.
• Before connecting to the power mains, the appliance should be left to stand still in upright position
for at least 2 hours. Thus, operation errors due to the effect of transport on the cooling system will be
much less likely to occur.
• The appliance must be connected to the power mains and grounded in compliance with the effective
standards and regulations.
• The appliance may not be used outdoors and should not be exposed to rain.
• The appliance must be disconnected from the power mains (unplug the power cord from the wall
outlet) before cleaning or before replacing the bulb.
• If the power cord is damaged, it should be replaced by a service technician or other authorized person.
• If the appliance is not used for a longer period of time, switch it off with the relevant button and
disconnect it from the power mains. Empty the appliance, defrost it, clean it, and leave the door ajar.
• To protect the environment, dispose of the appliance after its useful life by taking it to an authorized
waste collection center.
• The packaging is made of environment-friendly materials that can be recycled, disposed of, or
destroyed without hazard to the environment.
• Children should not play with the appliance.
• The label with basic information on the appliance is attached in the appliance interior. If the label is not
in your local language, replace it with the one supplied with the appliance.
• WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
• WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• WARNING! Do not damage the refrigerant circuit.
• WARNING! Do not use electric appliances in the
refrigerator or freezer interior, except for those expressly
allowed by the refrigerator-freezer manufacturer.
3
Important warnings
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of thisproduct. For more detailed information about
recycling of this product, please contact your local city offi ce, your household waste
disposal service or the shop where you purchased the product.
• Observe the installation instructions.
• Do not open the appliance door more frequently than necessary.
• Occasionally check whether air can circulate freely behind the appliance.
• Condenser unit mounted on the appliance back wall must be kept clean at all times (see section
“Cleaning the appliance”).
• If the seal is damaged or loose, replace it as soon as possible.
• Store your food in closed containers or other appropriate packaging.
• Before placing the food in the refrigerator, let it cool down to room temperature.
• Defrost your frozen food in the refrigerator compartment.
• Remove the freezer drawers and door as described in the instructions, in order to make use of
the entire capacity.
• Defrost your conventional freezer when a frost layer approximately 3-5 millimetres thick has
accumulated on the surfaces in the freezer compartment.
• Make sure the shelves are evenly distributed and that the food is arranged in a way that
allows free circulation of air (heed the recommended food arrangement as described in the
instructions).
• In appliances fi tted with a fan, do not block the fan slots.
4
A few tips on how to save power with your
refrigerator-freezer combo
A Freezer compartment
1 Shelf
B Refrigerator compartment
2 Control unit
3 Shelf (height adjustable)
4 Water discharge groove/
gutter
5 Fruit and vegetables bin /
drawer
6 Refrigerator door shelf
(deep and shallow version)
7 Adjustable feet
A
B
1
2
3
4
5
6
7
5
Appliance description
• The appliance should be installed in a dry and well ventilated
room. The appliance will operate correctly if the environment
temperature is within the ranges listed in the table below.
The appliance class is indicated on the label with the basic
information on the appliance.
Class Ambient temperature
SN (subnormal) from +10°C to +32°C
N (normal) from +16°C do +32°C
ST (subtropical) from +16°C do +38°C
T (tropical) from +16°C do +43°C
Appliance installation should be carried out by at least two
persons to avoid any physical injury or damage to the appliance.
• The appliance should stand fi rmly in an upright position on a
suffi ciently solid base. At the front, the appliance is fi tted with
two adjustable legs that can be used to level the appliance.
• If there is a kitchen furniture element above the appliance,
there should be a clearance of at least 5 centimeters between
this element and the refrigerator, to ensure suffi cient cooling of
the condenser unit.
• Do not expose the appliance to direct sunlight and do not
place it near sources of heat. If this cannot be avoided, install
an insulation panel.
Selecting the room
Installing the appliance
6
Installation and connection
Tools Required: Phillips style screwdriver / Flat blated screwdriver / Hexagonal spanner.
1) Remove the right top hinger cover (A).
2) Remove the screws (B) fi xed the top-hinge with cross-slot screwdriver.
3)Replace the top-hinge and the top-door limit block and the door bearing bush to the other side.
a) Remove the nut with sleeve.Take off the washer then remove the axes to the other side and
fi xed.
b) Remove the door limit block.
c) Please taking out another door limit block, with screw mounting to the door.
4) Disassemble the screws fi xed the bottom-hinge (C) with cross-slot screwdriver.
Note: the refrigerator-freezer incline angle less 45°.
5) Replace the bottom door bearing bush and the limit block.
6) Replace the bottom hinge to the other side then fi x it with screws.
7) Replace the mid-hinge.
8) Set the bottom door right position,fi x the mid-hinge.
9) Replace the top-hinge.
10) Set the top door right position,fi x the top-hinge and the cover.
11) Install the four screw caps and two catches to corresponding position.
Ensure the Appliance is unplugged and empty.
Adjust the two leveling feet to their highest position.
We recommend you have someone to assistyou
Changing the direction of door opening
7
1.
2. 3.
a.
b.
4.
C
B
A
c.
5.
6.
7.
8. 9.
10.
8
9
A Temperature setting and on/off knob
To switch on: rotate the A dial clockwise.
Switching off: Rotate the A knob back to the position in which
the arrow is aligned with the symbol (caution: appliance will
remain powered, i.e. there will still be electric current in the
appliance).
Switching the appliance
on/off
A
Operating the appliance
10
• To set the desired temperature, rotate the A dial in clockwise
direction, i.e. to the right.
• A change in the environment temperature will affect the
temperature in the appliance. Adjust the setting with the A
dial accordingly. Positions towards the thicker part of the
sign mean a lower temperature in the appliance (cooler).
Settings towards the thinner part of the sign mean a higher
temperature (warmer).
• If the temperature of the room where the appliance is installed
is below 16°C, we recommend setting the A dial temperature
to the thickest part of the sign.
Adjusting the
temperature
