Govee H70B1 Bedienungsanleitung
Govee Curtain Lights
Model: H70B1
Safety Instructions
●Move all cribs, beds, furniture and toys away from the lights. Do not tie
the bottom of the string lights and form loops as this could wrap
around a child’s neck and cause SUFFOCATION.
●This product is rated as IP65Waterproof. It can be used outdoors but
cannot be immersed in water.
●The power adapter israted as IP44Waterproof.It can be used outdoors
but cannot berinsedorimmersed in water.
●The internal light sources of the light bars and strip light cannot be replaced.
If the light sources sustain damage, the product should be replaced.
●Do not allow children to assemble and install this product without
adult supervision.
●Avoid installing this product near major heat sources.
●External dimmers cannot be used with this product.
●Use this product with the provided power adapter only.
●To reduce the risk of strangulation the flexible wiring connected to this
luminaire shall be effectively fixed to the wall if the wiring is within arm's
reach.
●Keep all strip lights out of the reach of children.
Introduction
ThanksforchoosingGovee Curtain Lights. The string lights are easy to
install and can be used both indoors and outdoors. They can not only be
used in/on curtains, bedrooms, bushes, dormitories, yards, balconies or
any other places for lights and decoration, but also can be applied during
holidays like Christmas, Valentine’s Day and Halloween. With the DIY
mode and Music mode, you can also design your own lighting effects and
bring more fun to your parties.
01
What You Get
Item
Curtain Light
Adapter
User Manual
Service Card
Quantity
1
1
1
1
7.5CM(0.25FT)
At a Glance
●Press to turn on or off.
●Press and hold for 5 seconds to reset.
Control Box
1.5M(5FT)
2M(6.6FT)
7.5CM(0.25FT)
1M(3.3FT)
3M(9.8FT)
What's in the box
1.5m*2m Lights String 1
G4 hooks Seamless Nails
10
1
Control Box Power Adapter
4
1
02
Caution
1. Move all cribs, beds, furniture and toys away from the lights.Do not tie
the bottom of the string lights and form loops as this could wrap
around a child’s neck and causeSUFFOCATION.
2. Check if the curtain lights can work properly before installation.
3. Clean the surface where the lights are going to be installed.
4. Keep the top cable on the same level while installing the lights.
3. Connect to the adapter and plug into power to test the device.
2. Hang the curtain lights with G4 hooks onto the curtain hooks.
1. Install the G4 hooks between the two wires.
Installing Your Device
Method 1: Use G4 Hooks
Method 2: Use G4 Hooks and VHB Gums
1. Clean the surface before installation.
2. Make marks on the surface that are
higher than 7.21ft/2.2m with intervals of
0.5ft/15cm. Keep all the marks on the
same level.
15CM
(0.5FT)
15CM
(0.5FT)
2.2M(7.21FT)
03
04
5. Connect to the adapter and plug into power to test the device.
3. Stick the provided VHB gums to the
back of the G4 hooks.
4. Stick the G4 hooks to where the marks
weremade on the surface.
Note:Press the G4 hooks more than 10
seconds.
Method 3: Use Seamless Nails
1. Clean the surface before installation.
2. Make 4 marks on the surface that
are higher than 7.21ft/2.2m with
intervals of 1.65ft/50cm. Keep
the 4 marks on the same level.
50CM
(1.65FT)
2.2M(7.21FT)
3. Fix the provided seamless nails to
where the marks were made on
the surface.
4. Hang the curtain lights on the fixed
nails.(Please prepare a string thatis
longer than 4.9ft/1.5m to fix on the
seamless nails).
1.5M (5FT)
Govee Home
Pairing Your Light with Govee Home App
What You Need
●A Wi-Fi router supporting the 2.4GHz and 802.11 b/g/n bands. 5GHz is
not supported.
●A smartphone or tablet running iOSor Android.
❶ Download Govee Home app from the App Store (iOSdevices) or Google
Play (Android devices).
❷ Turn on the Bluetooth on your smartphone.
❸ Open the app, tap the “+” icon in the top right corner and search for
“H70B1”.
❹ Tap the device icon and follow the on-screen instructions to complete
pairing.
Specifications
Power Input (Adapter)
Power Input(Curtain Light)
Power Cord Length
Size
Light Color
Waterproof
ControlMethod
Working Temperature
100-240VAC 50/60Hz
5VDC5A
13.1ft/4m
(Including Control Box)
4.9ft x 6.5ft (1.5m x 2m)
RGBIC
Adapter(IP44)
Control Box (IP65)
Curtain lights (IP65)
App, Control Box, Voice Control
-10° to 45°C(4° to 113°F)
05
Troubleshooting
❶ Failsto connect to Wi-Fi.
a.Make sure thedistancebetween the device and the router is less than
100ft.
b.Keep as few obstructions (e.g. wall, windows) as possible between the
device and the router.
c.Make sure the Wi-Fi name and the password you entered is correct.
d.Make sure the Wi-Fi you connect to is 2.4GHz. 5GHz is not supported.
❷Lost Wi-Fi connection./Cannot use the device with app.
a.Make sure your home Wi-Fi works well.
b.Check whether the Wi-Fi password has been modified.
c.Keep as few obstructions (e.g. wall, windows) as possible between the
device and the router.
d.Check whether the device has connected to Wi-Fi .
If the device is not connectedto Wi-Fi,please re-connect the device to
Wi-Fi as mentioned above.
❸Cannot pair or connect with Alexa or Google Assistant.
❺
Can multiple users control one device?
a. Ensure the stability of the Wi-Fi connection.
b. Go to the app Settings page and follow the instructions under “User
Guide” to pair the device again.
❹ The synchronization effect for Music Mode does not work properly.
a. Ensure the control box is close to the music source, which will help the
mic pick up sounds better.
a. Each device can only be controlled by one account.
b. If multiple users want to control the same device, ensure they are using
the same account.
06
Customer Service
Warranty: 12-Month Limited Warranty
Support: Lifetime Technical Support
Email: [email protected]
Official Website: www.govee.com
@Govee.smarthome@Goveeofficial
@govee.official
@govee_official
@Govee
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
FCC and ISED Canada Statement
This device complies with Part 15 of the FCC Rules and Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Le présent appareil est conforme aux CNR d'Industrie Canada applica-
bles aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélec trique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
07
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
FCC and IC Radiation Exposure Statement
This equipment complies with FCC and IC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.
Lors de l'utilisation du produit, maintenez une distance de 20 cm du
corps afin de vous conformer aux exigences en matière d'exposition RF.
1.
2.
3.
4.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Responsible party:
Name: GOVEE MOMENTS(US) TRADING LIMITED
Address: 2501 Chatham Rd Suite R Springfield IL 62704
Email: [email protected]
Contact information: https://www.govee.com/support
The trademark Govee has been authorised to Shenzhen Qianyan
Technology LTD.
Copyright ©2021 Shenzhen Qianyan Technology LTD.
All Rights Reserved.
This Class B digital apparatus complies with Canadian ICES-005.
Cet appareil numérique de la classe B est conforme à la norme
NMB-005 du Canada.
