Grain Audio PWS.01 Bedienungsanleitung
HEY THERE!
Congratulations on your purchase of your GRAIN AUDIO
PWS.01, you’re going to love it.
There are a few things you should know about the PWS. First,
your PWS is a rechargeable battery powered speaker, so use it
until it runs out, then charge it and start all over again. Second,
there is no storage on the PWS, you must have access to your
digital music libary through your phone, tablet or computer,
just pair it and play it. Third, the PWS is made of solid wood,
don’t get it wet.
Finally, the functions phases of the PWS are controlled through
and communitcated by the three buttons on the top of the unit.
Take a look at the graphic on the right hand side of the page for
a breakdown.
Now go out, have fun and Play Loud.
-Grain Audio
VOLUME DOWN
CONTROL BUTTON:
This button controls Power,
Pairing, Play/Pause. The
backlit “G” indicates current
mode and battery level.
VOLUME UP
POWER
1. To turn on the PWS 0.1, press and hold down the command
button for about 2 seconds until you hear the “power up”
tone. The power button will glow blue.
2. To turn off the PWS 0.1, hold the command button down for
1 second until you hear the “power down” tone. The power
button will dim.
Note: The power button may glow a different color depending
on the charging or battery state. Check the “Battery Level”
section of this manual for more information.
2 sec
power off
power on
BLUETOOTH
®
You will only need to pair to the PWS once. After that the PWS
will automatically pair to your
Bluetooth
®
enabled device each
time it is powered up.
1. Before pairing for the first time it is a good idea to have your
PWS fully charged.
2. While the PWS power is off place your
Bluetooth
®
enabled
device within 3 feet of the unit.
3. Press and hold the power button. The PWS will play
its “power up” tone which will be followed by the
announcement, “pairing mode on” after about 5 seconds.
The power button will also indicate pairing mode by flashing
blue.
4. Find the “Grain Audio PWS.01” on your
Bluetooth
®
enabled
device and select it for pairing. The PWS will announce,
“pairing complete” when properly connected.
5 sec
“pairing complete”
“pairing mode on”
Note:
1. For this step you may need to consult the owners manual
for the device you wish to pair with the PWS for any specific
instructions.
2. The PWS will remember up to 9 devices but can only pair
with one device at a time.
3. If password is requested during pairing mode use “0000”.
3.5MM CABLE
If you do not own a
Bluetooth
®
enabled device you can connect
to your PWS with the included 3.5mm cable.
Note: When you get a chance, buy a
Bluetooth
®
enabled
device... it’s like having a little bit of magic in your pocket.
CHARGING
1. To charge, connect the PWS to the wall adapter with the USB
cable included in the package. The PWS will announce that
it is, “charging” and the power button will glow red.
2. When the PWS is plugged in and has reached a full charge it
will announce, “charge complete” and the power button will
glow green.
Note: While charging the power button will glow red when the
power is turned on or off.
“charge complete”
“charging”
VOLUME
This is pretty simple. The “+” button increases the volume
while the “-“ button decreases it. The PWS will indicate its max
volume by giving you an auditory signal.
Note: The volume control on your paired device is controlled
independently from the PWS. Use both sets of controls to
achieve the right level for your use.
PLAY/PAUSE
During playback you can pause and restart your music by
giving the power button a quick press.
Note: If your
Bluetooth
®
device is separated from or not
streaming to your PWS for 10 minutes, the speaker will
automatically power off. x1
BATTERY LEVEL
The backlit control button indicates battery level by its activity.
- Constant Blue Glow- 50% full or better
- Alternating Blue and Red- 25% full
- Flashing Red- 10% full (accompanied by announcement)
Note: You can also check the battery level by pressing the
“+” and “-“ buttons at the same time.
50% full or better
25% full or better
10% full or better- “battery low, charge soon”
TROUBLESHOOTING
NO POWER?
- Check that your PWS.01 is charged
- If your PWS.01 is not charged plug it into a wall socket using
the supplied adapter or see the “Charging” section of this
manual.
WON’T PAIR?
- Power down the unit and restart things. Make sure you hear
the “pairing mode on” voice prompt or see the “Pairing”
section of this manual.
- Don’t know where to find your
Bluetooth
®
settings? Check
your device’s user manual for location, but it’s typically found
in the “Settings” portion of the device.
- If password is requested use “0000”.
NO MUSIC?
- Check that the PWS.01 is powered up
- Check that your device is properly paired with the PWS.01
- Check the volume of your PWS.01
- Check the volume of your
Bluetooth
®
enabled device
- Make sure your devices playback is not paused
- Refer to your phone, computer or other
Bluetooth
®
enabled device
manual
Note: Not all applications or devices support
Bluetooth
®
.
