SERIES

USER MANUAL

IMPORTANT

Please read this manual carefully before using the crane scale.

Table of content

Safety guide--------------------------------------------------------------------------------------2

Chapter 1. Product Description -------------------------------------------------------------3

Chapter 2. Use Method------------------------------------------------------------------------3

2.1 Information on the panel-----------------------------------------------------------------------------------3

2.2 Operation------------------------------------------------------------------------------------------------------4

1. Tare------------------------------------------------------------------------------------------------------------4

2. Tare cancel--------------------------------------------------------------------------------------------------4

3. Accumulation function------------------------------------------------------------------------------------4

4. To check the weights and times accumulated------------------------------------------------------4

5. Zero-----------------------------------------------------------------------------------------------------------5

6. Accumulation clear----------------------------------------------------------------------------------------5

Chapter 3. Calibration--------------------------------------------------------------------------5

3.1 Illustration---------------------------------------------------------------------------------------------------5

3.2 Method------------------------------------------------------------------------------------------------------5

Chapter 4. Display Illustration ---------------------------------------------------------------6

Safety guide

Read carefully the following instruction and advice before using this scale.

u Over-loading this scale is harshly prohibited

u Refrain from long-time loading that could lead to excessive fatigue on loadcell used inside

the scale. Excessive fatigue on loadcell would decrease the accuracy and shorten the

life of scale.

u Check the shackle and hook regularly.

u Check the battery power level before/after use and recharge the scale in time.

u In order to maximize the battery life, periodic recharging is necessary for scales even not in

use for long time.

u Do not try to repair the scale by yourselves.

u Use privately attached charger only.

u The scale can show the cell capacity when power on. For example when U 86 is shown,

meaning the current cell capacity is 86%. If the cell capacity is 20%, please charge the

scale as soon as possible to avoid damaging the battery.

Chapter 1. Product Description

C9 digital electronic crane scale is high accuracy, one-side direct display measuring unit which

combines load cell and power supply together. It can be directly hung on the hook of a hoist and

ensure the scale to complete the tasks of loading and weighing goods synchronously. The screen is

made up of super-bright tube (LED), which can be easily seen in 25 meters. The scale body is made

of strong alloy aluminum. The structure is compact and operation is quite easy.

The product is equiped with wireless communication, ranged up to 500m with data

transmission.

Chart 1-1 Main technical characters

Accuracy

OIML

Ⅲ

Taring range

100% FS

Result steady display

3~7 Seconds

Alarm of over weight

110% FS

Max safe load

125% FS

Limit coefficient

Power supply

Full seal airtight recharge battery

6v/10AH

Display tube

Super-bright LED or LCD(height

30mm/5 bits)

Working temperature range

-10

℃

~+40

℃

Remote controller distance

≤

20m

Chapter 2. Use Method

2.1 Information on the panel

(1) In the different status, different information is showed. User can operate scale according to the

notes showed on displayer.

(2) The light on upper right to the displayer means the charging of the battery. It’ll be on when

charging the scale.

(3) The light on the left side indicates stable status. When the scale becoming stable during operating,

the light will be on.

(4) View of outline of figure:

(5) View of remote controller:

2.2 Operation:

Explanation of key-press:

Key-press

Explanation

Key-press

Explanation

0(FUNC)

Setup Parameter

←

)

Turn left

5(Confirm)

To c onf i rm

→

)

Turn right

*(Zero)

Zero

↑

)

Digit minus1

#(Accu)

Accumulate

↓

)

Digit add 1

1. Tare:

In the normal weighing status, press [Tare] and displays “0”.

2. Tare cancel:

In the status of tare, press [Tare] again to cancel.

3. Accumulation function:

Press [Accu] on the remote controller can accumulate the current weights. After pressing [Accu] it

displays “N—XX”

→

“H XX”

→

“L XXXX” automatically then back to weighing status. “N—

XX” means the times of accumulation, “H XX”+“L XXXX” is total weight of accumulation. (After

pressing [Accu] every time, the value of N will be added 1.)

4. Accumulation clear:

The max time of accumulation is 99, it’ll display N—OF if exceed, please clear the current

accumulation at that time. Press [Zero] during accumulation station, which will be cleared.

5. Zero:

In normal weighing status, press [Zero] to setup “0”.

6. [Func] usage:

Press [Func] can setup parameter, press [Enter] it displays code of parameter.

List of Code

Code

Explanation

Code

Explanation

Calibration

Check inner code

Wireless Communication Mode

Canceled

Press “↑”“↓”“←”“→”to choose and adjust.

Note: Wireless communication mode is not default equipment.

The scale has power saving mode, it’ll enter power saving mode after 30mins during stable

status and power off after 2 hours.

Chapter 3. Calibration

3.1 Illustration:

When scale is stable, press [Func] and press [Enter], it displays parameter code XX. Press “↑”“↓”

“←”“→” to choose code 09 and press [Enter], which displays “SET” and entering calibration status.

Step 1: Setup parameter (e.g.: Max capacity 5t, standard weights 4t)

After displaying “---SET---”, operate as table 3-1 as followed.

Table 3-1 Operation of Step 1

Step

Operation

Display

Explanation

---SET---

Status of parameter setup

Press [Enter]

d 1

Displaying current division value

Press “←”or

“→”

d 2

Choose division value: 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50

optional (2 is default division value for 5t crane

scale)

Press [Enter]

00000

Setup F.S.

Press “↑”

“↓”“←”

“→”

05000

Input F.S.

Press [Enter]

---CAL---

Finished setting; entering calibration.

Step 2: Calibration, operate as table 3-2 as followed.

Table 3-2 Operation of Step 2

Step

Operation

Display

Explanation

---CAL---

Status of calibration of weight

Press [Enter]

UloAd

Wait until the light of stable on

Press [Enter]

05000

Displaying F.S.

Load weights (e.g.: 4t)

Press “↑”

“↓”“←”

“→”

04000

Input 4000kg

Press [Enter]

4000

Calibration finishes, displaying current weight.

Chapter 4. Display Illustration

No.

Display

Illustration

FULL

Attention of overweight

U 86

Current cell capacity

N---XX

Times of accumulation

N---oF

Accumulated times exceed

AddoF

Accumulated weight exceed

LJoFF

Clear accumulation

--SET--

Status of setting up division value

--CAL--

Calibration status

--Ad--

Check the status of AD

ULoAd

Zero position status
