Grandbeing EX0101-OP5 Bedienungsanleitung

Model No.: EX0101-OP5/OP6

Operating Instructions

Thanks for purchasing our product.

Please be sure to read this instruction manual

carefully before using our product.

Introduction

EX0101-OP5/OP6 is a HDMI extender while using single mode optical fiber as

transmission media.

Benefits from using EX0101-OP5/OP6:

1) By using EX0101-OP5/OP6, the transmission distance for 1080P reaches

5Km. For general HDMI cables, cables must be customized when the

length over 10 meters.

2) EX0101-OP5/OP6 has the ability of buffering and amplifying. Series

connection of EX0101-OP5/OP6 achieves long distance transmission of

HDMI signal. When two pairs or more EX0101-OP5/OP6 are sacked

together, they can be used to create a larger distribution (Daisy chained.)

EX0101-OP5/OP6 offers solutions for digital entertainment center, HDTV retail

and show site, HDTV, STB, DVD and Projector factory, noise, space and security

concerns, data center control, information distribution, conference room

presentation, school and corporate training environments.

Contents

HDMI Extender................................................................................................1

Product Overview ............................................................................................1

Features...........................................................................................................1

Package Contents............................................................................................3

Connections and Operations ...........................................................................3

Specifications...................................................................................................4

Panel Descriptions...........................................................................................5

Typical Application...........................................................................................7

Maintenance....................................................................................................7

Product Service ...............................................................................................8

●Provided Service ..........................................................................................8

●Mail-In Service..............................................................................................8

●Warranty.......................................................................................................9

●Warranty Limits And Exclusions....................................................................9

HDMI Extender(By single mode optical fiber)

■Product Overview ( Model Number: EX0101-OP5/OP6 )

■Features

zUse single mode optical fiber to substitute HDMI cable to achieve long

distance transmission.

zTransmission distance reaches up to 5Km under the video format of 1080P.

zAuto-adjustment of feedback, equalization and amplify, the user does not

need to care about the length of the fiber.

zHDMI V1.3 supported.

zHDCP compliant.

zFull HD support: 1080p@60Hz.

zWith LEDs indicators to show the power status and the signal staus.

zWith ESD protection inside.

zMounting ears supplied.

zThis model could be cascaded.

"Notice

We reserve the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

Warning

To reduce the risk of fire, electric shock or product damage:

1. Do not expose this apparatus

to rain, moisture, dripping or

splashing and that no objects

filled with liquids, such as vases,

shall be placed on the apparatus.

6. Clean this apparatus

only with dry cloth.

2. Do not install or place this unit

in a bookcase, built-in cabinet or

in another confined space.

Ensure the unit is well ventilated.

3. To prevent risk of electric

shock or fire hazard due to

overheating, do not obstruct

the unit’s ventilation openings

with newspapers, tablecloths,

curtains, and similar items.

4. Do not install near any heat

sources such as radiators, heat

registers, stoves, or other

apparatus (including amplifiers)

that produce heat.

5. Do not place sources of naked

flames, such as lighted candles,

on the unit.

7. Unplug this apparatus

during lightning storms or

when unused for long

periods of time.

8. Protect the power cord

from being walked on or

pinched particularly at

9. Only use attachments /

accessories specified by

the manufacturer.

10. Refer all servicing to

qualified service

personnel.

■Package Contents

① Main unit NO.1. P/N_EX0101-OP5.

② Main unit NO.2. P/N_EX0101-OP6.

③ Operating instructions. P/N_INSEX0101-OP5/OP6.

④ 2x 5VDC power supply P/N_VDC0502.(One for OP5, one for OP6)

NOTE: PART NUMBER (Abbreviation as P/N)

■Connections and Operations

1) Connect the HDMI input source ( such as HD-DVD、PS3、STB etc. ) to

EX0101-OP5.

2) Connect a single mode optical fiber from optical output of EX0101-OP5 to

optical input of EX0101-OP6.

3) Connect the HDMI sink( such as HD-LCD、HD-DLP) to EX0101-OP6.

Attention: Please insert and extract cables gently.

※DIP switch setting instruction:

EX0101-OP5

Position1 Function

0 Range scaling disenable.

1 Range scaling enable.

Position2 Position3 Function

0 0 1080P stereo (Using Embedded EDID) (note1)

0 1 1080P 5.1 (Using Embedded EDID) (note2)

0 1

1080P 7.1 (Using Embedded EDID) (note3)

1 1

1080I stereo (Using Embedded EDID) (note4)

Note1: The OP5 will use the embedded 1080P-stereo EDID when the DIP switch is in this

mode. The EDID will be 1080P video and stereo audio.

Note2: The OP5 will use the embedded 1080P-5.1 EDID when the DIP switch is in this mode.

The EDID will be 1080P video and 5.1 audio.

Note3: The OP5 will use the embedded 1080P-7.1 EDID when the DIP switch is in this mode.

The EDID will be 1080P video and 7.1 audio.

Note4: The OP5 will use the embedded 1080I-stereo EDID when the DIP switch is in this

mode. The EDID will be 1080I video and stereo audio.

EX0101-OP6

Position1 Position2 Position3 Function

0 0 0 Normal mode, 8bit color depth

0 0 1 LC mode(note1), 8bit color depth

0 1 0 Normal mode,color depth decided by the sink.

0 1 1

LC mode (note1), color depth decided by the

sink.

others Normal mode,8bit color depth

Note1: if video appears noise or interference when the long HDMI cable is used or the quality

of HDMI cable is not so good, use this mode.

■Specifications

Operating Temperature Range -5 to +35°C (-41 to +95 °F)

Operating Humidity Range 5 to 90 % RH (no condensation)

Input Video Signal 0.5-1.0 volts p-p

Input DDC Signal 5 volts p-p (TTL)

Video Format Supported DTV/HDTV; 1080P/720/1080i/576i/480i

Output Video HDMI 1.3+HDCP

(repeat the source to the sink)

Output Audio Support 7.1/5.1/stereo audio (PCM

only)

Maximum Transmission Distance 5Km

Power Supply 5VDC

Power Consumption 5Watts (EX0101-OP5)

5Watts (EX0101-OP6)

Dimensions 125mmH×120mmW×31mmD

/5.98’’W×4.13’’H×1.22’’D

Mass (Main unit) 0.9Kg / 1.98lb (Pairs)

NOTE1: Specifications are subject to change without notice. Mass and dimensions are

approximate.

■Panel Descriptions

1. EX0101-OP5

1. Status of power input. When power input on, the LED inside lights.

2. Status of signal connection. When this works well, the LED inside lights.

3. HDMI input.

4. Power input, 5VDC.

5. Mode setting. Use for setting the EDID.

6. Optical output.

7. ISP port. Use for updata the firmware.

2. EX0101-OP6
