GRASS VALLEY Thomson EDIUS SP Benutzerhandbuch

Hardware Setup Manual

EDIUS SP / EDIUS SP-SDI / EDIUS SD / EDIUS HD

F095807233

Cautions

(1) It is prohibited to copy a part or all of this product without prior permission.

(2) The contents or specifications of this product may be changed without prior notice.

(3) We have prepared the contents of this product to the best of our ability; however if you have any questions

about the contents, or if there are any errors or missing items, please contact Thomson Grass Valley.

(4) However we do not take any responsibility for malfunctions arising from use, irrespective of the points

outlined in (3).

(5) Irrespective of whether it was due to a usage error, Thomson Grass Valley takes no responsibility for

extraordinary, incidental or derivative claims, including those for lost earnings generated by the application of

this product.

(6) It is prohibited to analyze, reverse engineer, decompile or disassemble any of the items included with this

product, including the software, hardware and manual.

(7) Microsoft and Windows are registered trademarks of the Microsoft Corporation, USA.

(8) QuickTime is the registered trademark of the Apple Computer, Inc., USA.

(9) Adobe, Adobe logo, Adobe Photoshop, Premiere and After Effects are registered trademarks of Adobe Systems

Incorporated.

(10) Intel, Pentium and Xeon are the trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States of America and other countries.

(11) HDV and HDV logos are the trademarks of Sony Corporation and Victor Company of Japan, Limited (JVC).

(12) Dolby, Dolby and the Double D symbol are registered trademarks of Dolby Laboratories.

They are manufactured based on their own license.

(13) Other product names or related brand names are trademarks or registered trademarks of their respective

companies.

Manual Explanation

■Information not described in this manual may be displayed in some cases. Make sure to read the text file attached

to the disc.

■If there are any variations between the explanation in this manual and the actual application method, priority is

given to the actual application method.

■The screens used as examples in this manual are those of the development stage, so they may vary from those in

the final product.

■This manual is written for people who have a basic knowledge of how to use a computer. If there are no special

instructions, perform the same operation as a normal computer operation.

■In this manual, EDIUS 5 and EDIUS series are called 'EDIUS'.

■In this manual, Microsoft®Windows®XP Professional operating system is called Windows XP Professional or

Windows XP. Microsoft®Windows®XP Home Edition operating system is called Windows XP Home Edition or

Windows XP.

■In this manual, Windows Vista™ Home Basic, Windows Vista™ Home Premium, Windows Vista™ Business,

Windows Vista™ Ultimate is called Windows Vista Home Basic, Windows Vista Home Premium, Windows

Vista Business, Windows Vista Ultimate or Windows Vista.

■In this manual, Adobe Photoshop is called Photoshop, and Adobe After Effects is called After Effects.

■Information in this manual is subject to change without notice, due to the change in product specifications etc.

Hardware Setup Manual

July 23, 2008

Table of Contents

1 Before Using

Notices&Warranties ....................................... 3

Notices&Warranties ...............................................3

DANGER.........................................................4

CAUTION ........................................................4

FCCNotice.......................................................5

DeclarationofConformity............................................5

Operationenvironment..............................................6

Limitations........................................................9

Support................................................. 10

CustomerSupport.................................................10

Web-site ........................................................10

OnlineUserRegistration............................................10

2 Hardware Setting

SettingtheMainBoard......................................11

SettingtheSDIbracket..................................... 13

SettingtheSubBoard...................................... 13

Expansionboard(HX-HD1) .........................................13

Audiooutput .....................................................15

ConnectingtoHDBX....................................... 16

SettingHDBXconnectingterminal....................................16

EDIUS HD + HDBX-1000H or HDUP-1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

UpgradingHDBX..................................................20

ConnectingHDBX.................................................21

Partnames.............................................. 24

EDIUS SP Main board (SHX-E1 / E2) rear panel . . . . . . . . . . . . . . . . . . . . . . . . . 24

EDIUSHD/SD(RX-E1)Rearpanel ..................................25

Expansionboard(HX-HD1)rearpanel.................................26

SDIbracketrearpanel .............................................26

HDBXfrontpanel .................................................27

HDBXrearpanel..................................................28

EDIUSSPBreakoutBox............................................33





3 Software Installation / Uninstallation

InstallingEDIUS.......................................... 35

Installing Attached Application Software . . . . . . . . . . . . . . . . . . . . . . . 40

InstallingTitleMotionPro ...........................................40

ToolsFoldercontents..............................................41

InstallingDVCapture ..............................................43

Conrmation after installation ................................ 46

Conrming resource (in Windows Vista)................................46

Conrming resource (in Windows XP) .................................47

Uninstallation ............................................ 50

Uninstalling driver and application software from Windows Vista ............50

Uninstalling driver and application software from Windows XP ..............51

4 License Transfer

Transferringlicense........................................ 52

UsingLicenseTransfertool .........................................52

Transfer between a USB key and a local disk of a PC . . . . . . . . . . . . . . . . . . . . . 53

Transfer between a USB key and another USB key . . . . . . . . . . . . . . . . . . . . . . . 54

5 Hardware Specications

MainBoard.............................................. 55

EDIUS SP (SHX-E1) ...............................................55

EDIUS SP-SDI (SHX-E2) ...........................................56

EDIUS SD (RX-E1) ................................................57

EDIUS HD (RX-E1) ................................................58

Expansion board (HX-HD1) ................................. 61

Unbalancedoutput........................................ 61



Before Using

1Before Using

Notices & Warranties

It is illegal for anyone to violate any of the rights provided by the copyright laws to

the owner of copyright, except for fair use (mainly private noncommercial use). Also,

in certain cases copying is prohibited with no exceptions. In no event shall Thomson

Grass Valley be liable for any direct or indirect damages whatsoever arising from the

use of captured materials.

Warranty

This product is covered by a limited warranty when you register your Thomson Grass

Valley product. This warranty is for a period of one year from the date of purchase from

Thomson Grass Valley or an authorized Thomson Grass Valley agent. This warranty

applies only to the original purchaser of the Thomson Grass Valley product and is not

transferable, Thomson Grass Valley warrants that for this period the product will be

in good working order. Should our product fail to be in good working order, Thomson

Grass Valley will, at its option, repair or replace it at no additional charge, provided

that the product has not been subjected to misuse, abuse or non-Thomson Grass Valley

authorized alternations, modications and/or repair. Proof of purchase is required to

validate your warranty.

Thomson Grass Valley is not responsible for any lost prots, lost savings or other

incidental or consequential damages arising out of the use of, or inability to use, this

product. This includes damage to property and, to the extent permitted by law, damages

for personal injury. This warranty is in lieu of all other warranties of merchantability

and tness for a particular purpose.



DANGER

The following conditions indicate the potential for serious bodily injury or loss of life.

Health precautions

In rare cases, ashing lights or stimulation from the bright light of a computer display

or TV monitor may trigger temporary epileptic seizures or loss of consciousness. It is

believed that even individuals whom have never experienced such symptoms may be

susceptible. If you or close relatives have experienced any of these symptoms, consult a

doctor before using this product.

Do not use in environments requiring a high degree of reliability

and safety

This product is not to be used in medical devices or life support systems. The

characteristics of this product are not suited for use with such systems.

Protect against static electricity

An electrostatic discharge may damage components of this product. Do not directly

touch any of the connectors or component surfaces.

Static electricity can be generated on clothing and on people. Before handling the

product, discharge static electricity from your body by touching a grounded metal

surface.

Do not disassemble

Do not remove the cover or modify the Product. Fire, electric shock or malfunction

may result. For internal inspection or repair, please contact your system integrator or

Thomson Grass Valley directly.

CAUTION

The following conditions indicate the potential for bodily harm, damage to hardware or

loss of data.

Do not setup in areas subject to heat

Do not setup in an area exposed to direct sunlight or near a heating apparatus. The heat

can accumulate, causing burns, re or damage. Also, the unit may become deformed or

change color.

Only setup using the prescribed method

Do not setup in a manner other than prescribed. Do not use while wrapped in cloth or

plastic. Heat can accumulate, causing burns, re or damage.



Before Using

FCC Notice

This equipment has been tested and found to comply with the limits for the class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and if not installed,

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on,the

user is encouraged to try and correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This equipment has been certied to comply with the limits for a class B computing

device, pursuant to FCC Rules. In order to maintain compliance with FCC regulations,

shielded cables must be used with this equipment. Operation with non-approved

equipment or unshielded cables is likely to result in interference to radio and TV

reception. The user is cautioned that changes and modications made to the equipment

without the approval of manufacturer could void the user's authority to operate this

equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1)This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause

undesired operation.

Declaration of Conformity

According to FCC Part 15

Responsible party Name: Grass Valley, Inc

Address: 400 Providence Mine Road, Nevada City, CA 95959

Telephone: 530-478-3890



Operation environment

Notes EDIUS operation is not necessarily guaranteed even in the environments

satisfying all conditions below.

•

EDIUS SP

CPU: Intel Pentium 4 2.8GHz or higher

(Xeon 2.8GHz Dual Processor (hyper-threading) recommended.)

* EDIUS complies with multi-processor and hyper threading technology.

* CPU supporting SSE2 instructions is necessary in operating EDIUS.

PCI bus

The below PCI slots are required:

64bit / 66MHz PCI (PCI Spec. Revision 2.2) x1

32bit / 33MHz PCI (PCI Spec. Revision 2.2) x1

* You can also use two 32bit / 33MHz PCI (PCI Spec. Revision 2.2) slots, if you are

editing in SD resolutions only.

Memory

Memory space with 1GB or larger required, larger than 2GB recommended.

Hard disk drive

800MB or larger space required for software installation.

Drive with ATA100 / 5400rpm or faster is necessary for video storage.

* Ultra SCSI160 or faster is necessary to playback two or more streams in SD

uncompressed.

* RAID 0 is recommended for HD resolution editing.

Graphics

Direct3D 9.0c or later, PixelShader 3.0 or later

SD 128 MB or larger required, 256 MB or larger recommended

HD 256 MB or larger required, 512 MB or larger recommended

Sound system

Support for WDM driver is required.

DVD-ROM drive

Required for software installation.

DVD-R / RW or DVD+R / RW drive is required when creating DVD-Video with

Canopus DVD Creator.

►



Before Using

Windows XP SP2 or later (32bit)

Windows Vista SP1 or later (32bit)*

Windows Vista SP1 or later (64bit)*

* Windows Vista SP1 includes the following operation systems.

Windows Vista Home Basic

Windows Vista Home Premium

Windows Vista Ultimate

Windows Vista Business

EDIUS SP-SDI

CPU: Intel Pentium 4 2.4GHz or higher

* EDIUS complies with multi-processor and hyper threading technology.

* CPU supporting SSE2 instructions is necessary in operating EDIUS.

PCI bus

The below PCI slots are required:

Main board : PCI Express x 1 (PCI Express Spec. Revision 1.0a)

Expansion board : 32bit / 33MHz PCI (PCI Spec. Revision 2.2)

Memory

Memory space with 1GB or larger required, larger than 2GB recommended.

Hard disk drive

800MB or larger space required for software installation.

Drive with ATA100 / 5400rpm or faster is necessary for video storage.

* Ultra 160 SCSI or faster is necessary to playback two or more streams in SD

uncompressed.

* RAID0 is recommended for HD resolution editing.

Graphics

Direct3D 9.0c or later, PixelShader 3.0 or later

SD 128 MB or larger required, 256 MB or larger recommended

HD 256 MB or larger required, 512 MB or larger recommended

Sound system

Support for WDM driver is required.

DVD-ROM drive

Required for software installation.

DVD-R / RW or DVD+R / RW drive is required when creating DVD-Video with

Canopus DVD Creator.

►



Windows XP SP2 or later (32bit)

Windows Vista SP1 or later (32bit)*

Windows Vista SP1 or later (64bit)*

* Windows Vista SP1 includes the following operation systems.

Windows Vista Home Basic

Windows Vista Home Premium

Windows Vista Ultimate

Windows Vista Business

EDIUS SD / EDIUS HD

CPU: Intel Xeon 3.06GHz (3.2GHz recommended) Dual Processor

Chipset

Intel E7505 Chipset based M/B

(with PCI 64bit / 66MHz or PCI-X one slot)

(Recommend M/B Intel SE7505VB2)

Memory

2GB Main Memory

Hard disk drive

System HDD and Data HDD should be separate drives.

* System HDD

System HDD: Windows XP Professional / EDIUS 5 software installed

One Ultra-ATA drive or Ultra 160 SCSI drive

* Data HDD

Data HDD: Digitized video data, EDIUS 5 project data.

HDD speed : Read 70MB/s Write 60MB/s required for 2 streams video and audio +

1title realtime playback(Test tool: Storm test)

(Ex)

Serial ATA RAID set

Two or four S-ATA drive and RAID0 set

Card Silicon image SII13112(4) chip based RAID Card

SCSI drive RAID set

More then 2 drive Ultra160 or 320 RAID0 set

Card: Adaptec AHA29160 SCSI controller

Graphics

Nvidia GeForce 5700 or higher class video card

Direct3D 9.0c or later, PixelShader 3.0 or later

SD 128 MB or larger required, 256 MB or larger recommended

HD 256 MB or larger required, 512 MB or larger recommended

Nvidia Quadra series Not supported

►

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere GRASS VALLEY Grafikkarte Handbücher

GRASS VALLEY

GRASS VALLEY Thomson HD Spark Bedienungsanleitung

Beliebte Grafikkarte Handbücher anderer Marken

Gainward

Gainward GeForce GTX 690 4GB Bedienungsanleitung

ATI Technologies

ATI Technologies RADEON 137-40225-20 Bedienungsanleitung

MSI

MSI N220GT series Bedienungsanleitung

ATI Technologies

ATI Technologies RADEON 7000 MAC EDITION Bedienungsanleitung

SIIG

SIIG aurora Bedienungsanleitung

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Bedienungsanleitung

MSI

MSI R7850 series Bedienungsanleitung

DVS

DVS Atomix HDMI Bedienungsanleitung

Aztech

Aztech VGS3D-AGP Bedienungsanleitung

Advoli

Advoli TB4 Standard Bedienungsanleitung

ELSA

ELSA ERAZOR III LT Bedienungsanleitung

Gigabyte

Gigabyte GV-R7500L Bedienungsanleitung

Themis

Themis TGA-7000 PMC Bedienungsanleitung

EMS

EMS XtremeRGB-Ex1 Bedienungsanleitung

Nvidia

Nvidia Quadro Workstation Bedienungsanleitung

Pioneer

Pioneer PDA-5003 Bedienungsanleitung

QDI

QDI N2 Bedienungsanleitung

NEC

NEC N8116-48 Bedienungsanleitung
