CONTACT GRILL

PANINI PRESS / TEPPANYAKI / WAFFLE MAKER

INSTRUCTION MANUAL

& WARRANTY

CONTENTS

General Safety Instructions

Description Of The Parts

Before First Use

General Use

Cooking Guide

Disposal Of The Appliance

Commercial Warranty

PRECISION

ENGINEERED

FOR MAXIMUM

PERFORMANCE

Before using this

appliance, please

read the following

instructions

carefully. We

recommend that

you keep these

instructions. For

your own safety,

you must follow

these safety

instructions when

using electrical

appliances.

GENERAL SAFETY

INSTRUCTIONS

1. This appliance can

be used by children

aged from 8 years and

above and persons

with reduced physical,

sensory or mental

capabilities or lack

of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance in a

safe way and understand

the hazards involved.

Children shall not play

with the appliance.

Cleaning and user

maintenance shall not be

made by children unless

they are older than 8 and

supervised.

2. Keep the appliance and

cable out of reach of

children under 8.

3. Do not leave the

appliance unattended

when in use.

4. Do not immerse the

appliance, or its power

supply connector in water

or other liquids and do

not allow it to become

wet.

5. Do not operate any

appliance with a

damaged cord or plug

or after the appliance

malfunctions or has been

damaged in any manner.

Return appliance to

the nearest authorized

service facility for

examination, repair, or

adjustment.

6. Only use the appliance

for its intended domestic

use. We will not accept

any liability if the

appliance is subject to

improper use, or failure

to comply with these

instructions.

7. Intended for counter top

use only as directed.

8. Do not use outdoors.

9. Do not place on or near

a hot gas / naked flame

or electric burner, or in a

heated oven.

10. Do not use this appliance

near bathtubs, showers,

basins or other vessels

containing water.

11. Do not use the

appliance near or below

combustible materials

(e.g. curtains).

12. Do not let the power

cable hang over the edge

of the table or worktop

or touch hot surfaces.

(This also applies to an

extension lead if used).

13. The appliance must be

connected to a socket-

outlet having an earthing

contact.

14. To disconnect, turn the

unit off, then remove the

plug from the wall outlet.

15. If this appliance is

used with an extension

lead, ensure that it is

suitable for the rating of

the appliance and that

the extension lead is

reliably earthed. If unsure

check with a qualified

electrician.

16. The supply cord should

be regularly examined

for signs of damage and

the appliance must not

be used if the cord is

damaged.

17. Unplug the appliance

from the power supply

when not in use.

18. Do not connect the

appliance via a timer or

remote control system.

19. DO NOT touch hot

surfaces .

Accessible surfaces are

liable to get hot during

use. Always use the

handle and controls.

20. The use of accessory

attachments not

recommended by the

appliance manufacturer

may cause injuries.

21. Use tongs or other

heat safe utensils to

remove food. Do not lift

appliance.

22. With some foods large

quantities of smoke are

emitted - ensure there is

adequate ventilation.

23. Do not wrap food in

plastic film, polythene

bags, or metal foil. This

will damage your grill /

teppanyaki plate and you

may cause a fire hazard.

24. Do not use your grill for

any purpose other than

cooking food.

25. Do not use your grill

if it is damaged or

malfunctions.

26. Prior to first use, please

make sure that the

electrical rating of

the appliance is in

conformity with the

current electric rating.

27. WARNING: Charcoal or

similar combustible fuels

must not be used with this

appliance.

28. This appliance complies

with European Economic

Community Directive

2014/30/EU.

29. THIS APPLIANCE IS FOR

HOUSEHOLD USE ONLY.

DESCRIPTION OF

THE PARTS

1. BASE AND COVER

Solid construction with self-adjusting cover.

2. HANDLE

Panini-style handle to help adjust cover to

accommodate thickness of food.

3. ADJUSTABLE HEIGHT SETTINGS AND

LOCKING MECHANISM

Features preset height positions for top

melting. Locks cover closed to store.

4. LCD DISPLAY / CONTROL PANEL

Start / Stop and sear buttons with indicator

lights; dial controls and LCD display screen.

5. REVERSIBLE GRILL / TEPPANYAKI

GRIDDLE PLATES

Removable and reversible with ThermolonTM

Volt ceramic non-stick coating.

(5A: Grill plate) (5B: Teppanyaki plate)

6. DRIP TRAY

Collects grease and removes from base for

easy cleanup.

7. PLATE RELEASE BUTTONS

Push in to release and remove cooking

plates.

8. HINGE RELEASE BUTTON

Allows cover to extend back to the Flat

position.

9. POWER CABLE STORAGE

Conveniently located underneath to hide

away the cord.

1. 2.

6. 9.

(5A) Grill plate (5B) Teppanyaki plate Belgian Waffle plate

(Buy additional Belgian Waffle plates

suitable for this Contact Grill!)

CONTACT GRILL PLATES

BEFORE FIRST USE

• Remove all packaging, stickers and various

accessories on the inside and outside of

the appliance and check that all items have

been received in good condition or check

for any defects.

• Tear up all plastic bags and dispose of

properly as they can pose a suffocation or

choking risk to children.

Note: When you unpack the appliance,

the cover will be in the locked position. To

unlock, use the slider to move to the open

position. Please do no attempt to open the

cover at any point during the operation, with

the slider in the locked position.

CLEAN BEFORE FIRST USE:

• Remove the removable / reversible plates

and wash with warm soapy water and dry

thoroughly before returning to the base unit.

• Wipe body clean with a dry cloth.

• Confirm plates are securely fastened to the

upper lid and lower base unit.

• Before plugging in, make sure your

electricity supply is the same as the one

shown on the underside of your appliance.

• WARNING: THIS APPLIANCE MUST BE

EARTHED.

Note: if a non-rewireable plug is cut off

it must be DESTROYED IMMEDIATELY.

An electric shock hazard may arise if

an unwanted non-rewireable plug is

inadvertently inserted into a 13A socket

outlet.

• Your Contact Grill / Panini Press /

Teppanyaki is now ready for use.

• Only the removable / reversible plates

are dishwasher safe. NOTE: Do not use

harsh abrasive cleaners, scouring pads or

products that are not considered safe to use

on ceramic non-stick coatings. If washing in

the dishwasher, a slight discolouration to the

plates may occur. This is cosmetic only and

will not affect performance.

GENERAL USE

ASSEMBLY INSTRUCTIONS

To get Started, place the GreenPanTM Contact

Grill / Panini Press / Teppanyaki on a clean,

flat surface. The appliance has three different

positions:

CLOSED POSITION

Top plate / cover rests flat on lower plate /

base. This is the standard Starting and heating

position for the contact Teppanyaki / Griddle or

panini press functions.

OPEN POSITION

Top plate / cover is open. Open the cover to

this position before using the appliance as a

contact Teppanyaki / Griddle or a panini press.

To adjust the appliance into the open position,

lift the handle until you feel it move to a steady

position.

The Teppanyaki / Griddle will remain in the

steady position until you close the cover or

move it to the flat open Teppanyaki / Griddle

position. The top plate / cover will stay in an

upright position until you lower the handle

for cooking. When you lower the handle for

cooking the hinge will self-release to allow the

top plate / cover to lie flat on your food and

ensure total contact and cook your food evenly.

FLAT POSITION

Top plate / cover is opened so that the top

and lower plates are level and create a single

cooking surface.

When opening the cover to the flat position,

hold onto the handle, press the cover release

button on the right of the unit and pull

the handle back until the grill touches the

countertop. Remember to put the drip tray into

position to support the upper grill at the centre.

INSTALLING COOKING PLATES

The appliance should be off and cooled. Put the

appliance in the flat position. Insert each plate

individually. Find the metal holding brackets at

the centre of the housing. Tilt the back end of

the plate and line up the cut-outs with the metal

brackets. Slide the plate beneath the brackets

and push down on the front end of the plate.

You should hear it snap into place. Turn the

appliance 180° and install the second plate into

the upper housing the same way.

REMOVING COOKING PLATES

The appliance should be off and cooled. Put

your appliance in the flat position. Find the

plate release buttons on one side. Press one

button firmly and the cooking plate will pop up

from the base. Grab the cooking plate with both

hands, slide it from under the metal brackets

and lift from the base. Press on the other button

to release the other cooking plate the same

way.

OPERATION

Prior to using this appliance for the first time,

wash the grill / teppanyaki plate, base, lid and

drip tray in accordance with the instructions

given under the “Before First Use” section. Dry

thoroughly and then lightly brush the surface of

the grill plate with cooking oil. Place the drip

tray into the base, then place the grill plate onto

the drip tray. Never use the grill plate directly

on the work surface, always use with the drip

tray and base.

This appliance should only be used on a heat

resistant and easy to wipe clean surface.

Once your appliance is properly assembled,

plug the cord into a standard electrical outlet

and you will be ready to get cooking. The

LCD will illuminate, after any button or dial is

selected, but no cooking function is selected

yet. To turn on the product for function selection,

press the Start / Stop button.

Put your appliance in the preferred cooking

position and use the temperature control to

choose your cooking temperature. Settings

range from Low (80°C) to High (230°C). If you

wish to use the appliance in the flat position

but you do not need the entire surface, it is

recommended that you only use the bottom

plate.

GETTING STARTED

Selecting Plates & Temperature

• To Start using your appliance, turn the plate

select dial to select which plate(s) you need

to adjust setting.

• Select “Lower” or “Upper” if you want to

select a different temperature for each plate.

Select “Both” if want to adjust the setting of

both plates simultaneously.

• Default timer and temperature will appear

on the LCD display.

• Turn the dial to adjust your temperature.

• To adjust your countdown timer, turn the dial

to select the number of minutes.

• Press the Start / Stop button, and you

will notice the LCD screen will display

“PREHEAT” and bars running from left to

right.

• Once it’s done preheating, it will beep three

times and the “PREHEAT” disappears and

the minutes will Start blinking.

• Press Start / Stop to Start the timer counting

down and add your food to the plate(s).

NOTE: If both plates complete preheat and

the Start / Stop button is not pressed within

60 minutes, the appliance will go into OFF

mode and LCD turns Off.

• When the countdown timer runs out, the

appliance will beep three times. The time

will reset to the previously selected values

and will Start flashing to indicate that it’s

ready to Start the next cycle.

• To Stop cooking, select the plate to turn off,

then turn the temperature dial to beyond

minimum value, “OFF” will display for the

selected plate. If both plates are during

cooking or preheat, pressing Start / Stop

button will turn off the product.

DURING USE

As the appliance will become hot during

use, always use caution when operating the

appliance. Always use the front handle to

open the appliance, as this part of the handle

is designed to stay-cool to the touch while

cooking. The top cover will become hot during

use.

DO NOT TOUCH THE COVER OR ARMS

DURING OR IMMEDIATELY AFTER COOKING

The top cover should not be touched during or

immediately after cooking. Use an oven mitt if

you need to adjust the cover to prevent burns.

The base of the appliance will be very hot

too. If you need to move the appliance for

any reason allow the appliance to cool before

handling (at least 30 minutes).

NOTE: During first use, the appliance may have

a slight odour and it may smoke a little. This is

perfectly normal and will disappear with use.

SEAR FUNCTION

You can sear foods at 260°C for up to 2

minutes. Pressing the Sear button will toggle

among Upper / LOWER / BOTH / No action.

Pressing it once will have “SEAR” appear on

the upper plate section. Pressing it a second

time will have “SEAR” appears on the lower

plate section. The third press will have “SEAR”

appear on both upper and lower plate sections.

Fourth press will have “SEAR” disappear on

both upper and lower plate section.

EXPLORE NEW CULINARY TERRITORY

The Contact Grill, Panini Press, Teppanyaki

& Waffle Maker delivers ultimate versatility

with many different cooking modes. Use it as

a contact grill, contact Teppanyaki / Griddle,

panini press, open grill, or open Teppanyaki /

Griddle, or grill on one side and Teppanyaki /

Griddle on the other. See Assembly Instructions

and Operating Instructions for additional

information on use.

CONTACT TEPPANYAKI / GRIDDLE

(CLOSED POSITION)

Perfect for sausages, boneless chicken and

veggies, the contact Teppanyaki / Griddle

saves time because you’re griddling both

sides of your food at once. The Contact Grill,

Panini Press, Teppanyaki & Waffle Maker

was designed with convenience in mind, so

our handle and hinge let the cover adjust to

your food, so you get total contact. Evenly

Teppanyaki / Griddle everything from thin hash

browns to a thick steak. When cooking multiple

items, it’s important to take the thickness of your

food into consideration. Make sure your food

is a consistent thickness so the cover will close

evenly.

CONTACT GRILL (CLOSED POSITION)

Get classic sear marks faster with the closed

grill position. Utilizing two grill plates, you can

get grill flavour in half the time. Just put your

food in and close the grill to cook both sides

at the same time. That means faster burgers,

steaks, pork chops, and so much more. Always

consider the thickness of your food before using

this mode. Keeping your food to the same

thickness will ensure it all cooks evenly.

PANINI PRESS (CLOSED POSITION)

Crispy paninis and wraps are easy with the

Contact Grill, Panini Press, Teppanyaki &

Waffle Maker. The Contact Grill, Panini Press,

Teppanyaki & Waffle Maker is designed with

a self-adjusting handle and hinge that lets you

cover your sandwich or wrap completely so

it cooks evenly. You can apply light pressure

to the handle to press your food to your

liking. Remember to take the thickness of your

sandwiches into consideration when cooking so

the cover will close evenly.

WAFFLE (CLOSED POSITION)

To use your Contact Grill, Panini Press,

Teppanyaki & Waffle Maker to make waffles,

insert the top and bottom waffle plates. Select

both plates for your browning from 1 to 7. The

time is pre-set for you after adding the batter.

Close the cover and press Start / Stop button to

Start cooking. You will hear 3 beeps when the

waffle is done (approximately 5 to 9 minutes).

Prepare the next batch or turn off. Note: Waffle

plates should always be used in the closed

position, and should never be mixed with other

plates.

FLAT GRILL (OPEN POSITION)

Bring outdoor flavour inside with the flat grill

position. Just open the cover flat against the

counter. This position utilizes two grill plates

to deliver a full-sized healthy ceramic non-stick

grill. Sear a classic steak, make a juicy burger,

and make hot dogs for the kids all on the same

device. The extra room and easy to clean grill

plates make getting the perfect sear marks

effortless.

Inhaltsverzeichnis

Andere GreenPan Waffeleisen Handbücher

GreenPan

GreenPan 2-SQUARE WAFFLE MAKER Bedienungsanleitung

Beliebte Waffeleisen Handbücher anderer Marken

Kenwood

Kenwood PG-2000 Bedienungsanleitung

BRAYER

BRAYER BR2300 Bedienungsanleitung

Ricardo

Ricardo Mini Waffle Maker Installationsanleitung

KYOWA

KYOWA KW-2616 Bedienungsanleitung

Herenthal

Herenthal EWM-1200 Bedienungsanleitung

MPM

MPM MGO-30M Bedienungsanleitung

Nostalgia

Nostalgia MyMini MWF5AQ Kurzanleitung

SEVERIN

SEVERIN WA 2101 - Benutzerhandbuch

Trebs

Trebs Comfortbakery 99255 Bedienungsanleitung

Black & Decker

Black & Decker WMB505C Bedienungsanleitung

Wilfa

Wilfa WM-623BELL Bedienungsanleitung

Cuisinart

Cuisinart WAF-350C Series Betriebshandbuch

SEVERIN

SEVERIN WA 2110 Benutzerhandbuch

Villaware

Villaware UNO 2000 Handbuch

Unold

Unold 48266 Bedienungsanleitung

Royal Catering

Royal Catering RCWM-1400-B Bedienungsanleitung

Curtis Stone

Curtis Stone CSWB100 Bedienungsanleitung

Trebs

Trebs Comfortbakery 99257 Bedienungsanleitung
