Grimac TERRY TECH Bedienungsanleitung
OUR BEST COMPLIMENTS
FOR CHOOSING GRIMAC QUALITY
CE Declaration of Conformity
We: Grimac s.r.l.
via Morazzo, 2 (angolo via Rigosa)
40069 - Zola Predosa (BO) ITALY
declare under our sole responsibility the following Coffee Machine
product and its derivatives, to which this declaration relates
Model: TERRY TECH
is in conformity with the following standards:
CEI EN 50366 : 2004
CEI EN 60335 - 1 A55 : 1993
CEI EN 60335 - 2 - 15 : 1990
CEI EN 60335 - 1 A6 : 1989
and with the EEC directives:
LOW VOLTAGE DIRECTIVE 73/23
and successive amendments 93/68
DIRECTIVE EMC 89/336
Zola Predosa, 23rd December 2004 Company President
Ms SILVIA GARDOSI
OPERATING INSTRUCTIONS
1 7
ENGLISH
1 8
Index
0 - INTRODUCTION
pg.
0.1 - Foreword 19
0.2 - Symbols 19
0.3 - Basic safety warnings 20
0.4 - Protection covers 20
0.5 - Safety precautions to follow when repairing or servicing the coffee maker 21
0.6 - Practical tips for brewing a quality cup of coffee 21
1 - TECHNICAL DETAILS
1.1 - General information 22
1.2 - Receiving the coffee maker and unpacking 22
1.3 - Positioning and installation 22
1.4 - Technical specifications 23
1.5 - Guarantee 23
2 - GENERAL DESCRIPTION
2.1 - General description 24
2.2 - Operating principles 24
3 - USING THE COFFEE MAKER
3.1 - Controls and control functions 25
3.2 - Operating instructions 25
4 - TROUBLESHOOTING AND REMEDIES
4.1 - Malfunctions 26
4.2 - General checks 27
5 - MAINTENANCE
5.1 - Cleaning 27
5.2 - Descaling instructions 28
5.3 - Changing coffee brewing time, temperature and language settings 29
6 - S P A R E P A R T S 30
1 9
Chapter 0 - Introduction
0.1 - FOREWORD
These OPERATING INSTRUCTIONS are a guide to using and maintaining the GRIMAC
TERRY TECH pod coffee maker.
Before USING OR SERVICING the coffee maker, read this MANUAL carefully and
thoroughly.
This manual provides information, advice and precautions about how to use the TERRY
TECH pod coffee maker to ensure longevity and perfect performance in time. It is very
simple to use and brews a cup of excellent coffee in just a few seconds.
This coffee maker uses pods which contain a specific measure of ground roasted coffee
tampered to the right pressure and encapsulated in paper.
The pods are packed in a controlled atmosphere preventing moisture penetrating the
inside of the pod to make perfect coffee with excellent results.
Carefully follow all the information and guidelines provided in this manual to ensure machi-
ne performance and to extend the service life of your coffee maker. As these Operating
Instructions are an integral part of the coffee maker they must be kept for its entire
service life.
If the coffee maker is sold or given to another user, it is of utmost importance
that these “Operating Instructions” are supplied together with the machine.
This symbol, crossed out wheelie bin, on products or on product packaging
indicates that the product, in all EU member States, must be disposed of and
treated as specific and separate waste.
This product must not be disposed of with your other household
waste.
0.2 - SYMBOLS
The below symbols are used to draw the reader’s attention to important information
regarding personal safety, machine safety and to specific operating conditions.
General operating
information.
General warning,
damage may caused
to things or to the
coffee maker.
WARNING !
Hazard to persons
or to the coffee
maker.
WARNING !
Hazard of electric
shock to persons or
electrical damage to
the coffee maker.
2 0
0.3 - BASIC SAFETY WARNINGS
• The TERRY TECH pod coffee maker is designed for the specific purpose described
herein and any other use or the use of other products which were not approved at the
time of purchase of this coffee maker, GRIMAC srl shall not be held responsible nor
liable for injury to persons, animals or damage to things caused by an incorrect or
improper use.
THE PREMISES WIRING SYSTEM MUST BE EARTHED.
• Never place hands, metal objects or other inside the coffee maker when
it is connected to the mains power supply.
• Always contact one of our service centres for repair or servicing work
which is not covered in this manual.
• Before performing any type of work on the coffee maker ALWAYS discon-
nect the plug at the mains socket-outlet.
• Check the power cable regularly. A worn or damaged cable creates a po-
tential hazard of electric shock (see Chapter 4.2).
• Before using the coffee maker become familiar with all its parts, controls
and technical specifications which are provided in these instructions.
0.4 - PROTECTION COVERS
The TERRY TECH pod coffee maker has a number of protection covers and lids to prevent
the user from coming into direct contact with the various components and electrics.
A - Removable top lid: protects the
water tank compartment. As this lid
is for accessing the water tank when
refilling the coffee maker with water,
it is not secured in place by fixture
screws.
B - Fixed top protection cover:
ONLY specialised and authorised per-
sonnel may remove this cover. This
cover is for accessing coffee maker
components and electrics.
AB
Chapter 0 - Introduction
2 1
Chapter 0 - Introduction
0.5 - SAFETY PRECAUTIONS TO FOLLOW WHEN
REPAIRING OR SERVICING THE COFFEE MAKER
• Switch off the coffee maker and disconnect the plug at the mains socket-outlet before
performing routine maintenance, repair work or cleaning.
• To extend the service life and performance of your coffee maker, parts must be repla-
ced only with original spares and by qualified personnel.
• After performing any type of servicing or repair work, ensure that all parts are in proper
working order.
• Repair work to wiring must be performed only by qualified personnel and only after the
plug has been disconnected at the mains socket-outlet.
• Never use running water or pour water on the coffee maker when it is switched on or
when cleaning.
• Never use solvents, paint thinners, alcohol, etc to clean the coffee maker. To clean we
recommend you use a warm water and neutral detergent solution to prevent damaging
the external and internal parts of the coffee marker.
0.6 - PRACTICAL TIPS FOR BREWING A QUALITY
C U P O F C O F F E E
The TERRY TECH coffee maker brews an excellent cup of coffee thanks to the simple
“pod” system (ground roasted coffee tampered to the right pressure and encapsulated in
paper). Although this pod system is very simple to use, the user must follow the instruc-
tions provided in Chapter 3, Paragraph 3.2 and make sure that the pod sits evenly in the
pod holder.
Keep your coffee pods in a dry place away from heat sources and direct light.
The coffee pods are pre-portioned for one cup.
ENGLISH
2 2
1.1 - GENERAL INFORMATION
All machine components and materials used in manufacturing this pod coffee marker all
conform to the new standards in force. The TERRY TECH pod coffee maker has been de-
signed and developed with meticulous care above all to wiring, electrics and parts which
come into direct contact with the coffee.
1.2 - RECEIVING THE COFFEE MAKER AND UNPACKING
The TERRY TECH pod coffee maker is packed in a box to protect it from damage when
handling. To remove the coffee maker from its packaging, open the box and remove the
cardboard protection and with both hands grip the coffee maker at the bottom and gently
and slowly lift it out of the box.
Place the coffee maker on a flat surface or table before proceeding with installation.
Before using the coffee maker check for signs of damage or missing parts.
If you have any doubts, contact one of our service centres for further information.
The TERRY TECH pod coffee maker before dispatch is tested and packed ready for use
by GRIMAC s.r.l..
Any damage or other is the carrier’s sole responsibility.
Check the machine carefully upon receipt.
In the event of damage or faults, please contact and inform the retailer where
you purchased the coffee maker.
Before connecting to the mains power supply, check that the mains voltage
corresponds to the voltage provided in the technical specifications of the
coffee maker.
The premises wiring system must be earthed.
1.3 - POSITIONING AND INSTALLATION
After having checked that there are no missing parts or damage, position the pod coffee
maker in its operating position. Make sure the surface is stable and that there is sufficient
room around the coffee maker to be able to use it correctly (moving pod holder lever,
filling up with water, inserting coffee pod etc.)
Place the coffee maker at a suitable height so that it is out of reach of children.
To prevent people from walking into or knocking over the coffee maker, do
not position it in a location where there is a lot of traffic or in narrow corridors
creating an obstacle.
Chapter 1 - Technical details
2 3
The coffee maker is sold pre-assembled and ready for use and does not requi-
re additional installation work.
Simply plug it into the mains socket-outlet.
Before using the coffee maker for the first time, rinse the water tank. To re-
move the tank disconnect the two tubes and remove from its compartment.
Rinse and then fill with water, replace and reconnect the two tubes previously
disconnected in their respective holes (fig. 6).
Nonetheless, we recommend that the coffee maker is installed by qualified
personnel.
1.4 - TECHNICAL SPECIFICATIONS
Supply voltage and absorbed power:
- 230 V, 400 W (Europe)
- 110 V, 400 W (USA)
Energy consumption: - less than 1 kW/h round-the-clock*
Measurements: H = Height = 315 mm
D = Depth = 350 mm
W = Width = 210 mm
Weight: 7.5 Kg
Tank capacity: 3 litres
1 Thermostat with manual reset: 145° C
2 electronic probes for temperature readings
* Energy consumption has been calculated on 20 cups of coffee with the coffee maker switched
on for 24 hours.
1.5 - GUARANTEE
The coffee maker is guaranteed for a period of 12 months from the date of purchase and
covers both electrical and mechanical components.
This guarantee is void if the product has been damaged by incorrect or improper use,
neglect or repairs by unauthorised personnel.
Furthermore, this guarantee does not cover damaged parts caused by insufficient or ne-
glect of cleaning (refer to Chapter 5.1). All faulty parts considered and acknowledged by the
manufacturer as defective shall be replaced free of charge during the guarantee period.
All handling and carrier costs are at purchaser’s expense.
GRIMAC s.r.l. reserves the right to alter and modify its products at any time, and shall not be
held responsible nor liable for injury to persons or animals or damage to things caused by
neglect in observing the provisions provided in this manual.
Chapter 1 - Technical details
ENGLISH
2 4
1
12
3
4
5
6
7
8
9
11
10
2
Chapter 2 - General description
2.1 - GENERAL DESCRIPTION
The TERRY TECH pod coffee maker is supplied with the following parts:
1) removable tank lid
2) main ON/OFF switch
3) single serving button
4) double serving button
5) “hot water/steam” button (optional accessory)
6) “power/coffee” indicator light (for standard model only)
7) top and bottom pod holder
8) lever for opening and closing pod holder
9) drip tray with grille
10) snap-in socket for power cable
11) frothing arm hot water/steam (optional accessory)
12) display (only for mod. w/display feature)
2.2 - OPERATING PRINCIPLES
After having inserted the pod in the pod holder (refer to recommendations and tips pro-
vided in Chapter 3 at point 3.2) and closed the pod holder utilising the lever, the coffee
maker is now ready for brewing a cup of coffee. Hot water cycles through the top of the
pod holder and then through the pod and the coffee is dispensed through the spout into
the cup.
fig.1
2 5
Chapter 3 - Using the coffee maker
3.1 - CONTROLS AND CONTROL FUNCTIONS
• Main ON/OFF switch: switch to ”I“to turn the coffee maker on and to ”¢“ to turn
it off.
• “Power/Coffee” indicator light: when on this light indicates the coffee maker is
powered:
- on/flashing indicates the heating element is heating to the right temperature;
- on/fixed indicates the coffee maker is at the correct temperature and ready for brewing
coffee.
• Display (only for models with display feature included): indicates that the coffee
maker is heating to the required temperature: ‘WAIT HEATING’, then utilising the chip
card it is possible to program temperature and language settings.
• Single and double serving buttons: when one of these two buttons is pres-
sed the coffee maker dispenses coffee and stops automatically after a set time.
Brewing time for both single and double servings are default factory settings. It is
however possible to change brewing times depending on preference (for further
details refer to the paragraph “Changing coffee brewing time, temperature and
language settings”).
• “Hot water/Steam” button (optional accessory): when pressed this button dispen-
ses steam or hot water (depending on coffee maker model) through the frothing arm
(pos. 11 fig. 1).
To stop dispensing press this button again.
N.B. when dispensing hot water or steam position the lever as illustrated in fig.1
this is to prevent the two halves of the pod holder - top and bottom - from closing
together.
WARNING: hot water and steam are dispensed at a high temperature.
Hazard of scalding.
• Lever: by moving this lever to the right the bottom half of the pod holder locks together
with the top half.
3.2 - OPERATING INSTRUCTIONS
• Switch ON/OFF power switch to pos. I(fig.1) and wait until the indicator light (n. 6
fig. 1) remains on without flashing.
• Lower the pod holder by pushing the lever to the left (n. 8 fig. 1).
ENGLISH
Inhaltsverzeichnis
Andere Grimac Kaffeemaschine Handbücher
Grimac
Grimac TWENTY Series PUL 2 Handbuch
Grimac
Grimac TWENTY Handbuch
Grimac
Grimac DADA VAPOR DOPPIA Bedienungsanleitung
Grimac
Grimac G 11 Bedienungsanleitung
Grimac
Grimac TERRY OPALE Capsule Bedienungsanleitung
Grimac
Grimac OPALE Bedienungsanleitung
Grimac
Grimac Ambra Bedienungsanleitung
Grimac
Grimac G 11 Bedienungsanleitung
Grimac
Grimac Minigrimac Bedienungsanleitung
Grimac
Grimac Espressione BABY GRACE PG Bedienungsanleitung
