Grundig AS-3D Bedienungsanleitung

ENGLISH

11 SAFETY AND SET-UP

13 OVERVIEW

13 Equipment list

14 Main features

15 OPERATION

15 General information for operation

15 Turning on the 3D glasses

15 Turning oﬀ the 3D glasses

16 RECHARGING THE BATTERY

17 INFORMATION

17 Service information for retailers

17 Environmental note

17 Technical data

CONTENTS -------------------------------------------------------------------------------------

ENGLISH

Please note the following instructions

when using the device:

The intended use of the 3D glasses

is viewing 3D content only. Do not

use it as any other general eye-

wear purpose, such as sunglasses,

protective goggles, general eye-

wear, as such use may result in

injury.

Do not place the glasses in a lo-

cation exposed to direct sunlight,

heat, fire or water. This may result

in product malfunction.

Do not apply force to the 3D

glasses. Dropping or bending

them may result in damage.

Only clean the 3D glasses with

the soft cloth supplied. Any chemi-

cal cleaning agent sprayed on

the 3D glasses may damage the

product surface or cause product

malfunction.

Do not use chemicals containing

alcohol, solvents or surfactants or

similar chemicals. These may re-

sult in discoloration or cracks on

the product surface and cause the

indication labels to peel from the

product surface.

Since the product surface and the

lens are easily scratched, make

sure to use

the soft cloth supplied

when cleaning to avoid scratching

either the surface or the lens. As the

product may become scratched if

there is any foreign material on the

cloth, make sure to shake off any

dust before using it.

Do not attempt to replace the bat-

tery. The battery is not replace-

able.

Parents careful supervision is re-

quired particularly when children

or teenagers view 3D images.

Photosensitive Seizure Warning

and Other Health Risks.

Some viewers may experience an

epileptic seizure or stroke when

exposed to certain flashing im-

ages or lights contained in certain

television pictures or video games.

If you or any of your relatives has

a history of epilepsy or strokes,

please consult with a medical spe-

cialist before using the 3D func-

tion.

Even though without a personal or

family history of epilepsy or stroke

may have an undiagnosed condi-

tion that can cause photosensitive

epileptic seizure.

SAFETY AND SET-UP-----------------------------------------------------------

ENGLISH

If you experience any of the fol-

lowing symptoms immediately stop

watching 3D pictures and consult a

medical specialist:

(1) altered vision; (2) lightheaded-

ness; (3) dizziness; (4) involuntary

movements such as eye or muscle

twitching; (5) confusion; (6) nau-

sea; (7) loss of awareness; (8)

cramps; (9) disorientation.

Parents should monitor and ask

their children about the above

symptoms. Children and teenagers

may be more likely than adults to

experience these symptoms.

Do not watch 3D pictures when you

feel incoherent, sleepy, tired or sick.

Avoid watching 3D pictures for long

periods of time. Take breaks.

Note that watching TV while sit-

ting too close to the screen for

an extended period of time may

weaken your eyesight.

Note that watching TV while wear-

ing 3D glasses for an extended

period of time may cause a head-

ache, fatigue, or dizziness. If you

have a headache, fatigue, or dizzi-

ness, stop watching TV and rest.

Some 3D pictures may startle view-

ers. Pregnant, elderly, epileptic,

and those suffering from serious

physical conditions are advised to

avoid utilizing the unit’s 3D func-

tionality.

SAFETY AND SET-UP-----------------------------------------------------------

If you are in bad physical condi-

tion, sleep deprived, or you have

drunk alcohol, we strongly recom-

mend you not use 3D glasses or

view 3D pictures.

Please take care to be aware of

the world around you. This prod-

uct is designed to be immersive.

Do not use this product near open

stairwells, cables, balconies or

other objects that can be tripped

over, run into, knocked down,

broken or knocked over. If you

are startled or misconstrue the 3D

images as real, you may crush a

nearby object or injure yourself

trying to move your body.

When watching a 3D video, do

not place anything nearby that

can be easily broken. Involuntary

movements or surprised reactions

may occur as a result of watching

3D TV, causing you to break sur-

rounding objects or hurt yourself.

ENGLISH

OVERVIEW -------------------------------------------------------------------------------------

Equipment list

Following items are included in the package.

1 3D shutter glasses

2 Cleaning cloth.

3 Storage pouch.

4 User’s guide.

5 Micro USB cable.

ENGLISH

OVERVIEW -------------------------------------------------------------------------------------

Main features

1 LCD lens.

2 IR signal receiver.

3 Earpiece.

4 Power button / led indicator.

5 USB in.

ENGLISH

OPERATION ----------------------------------------------------------------------------------

General information for

operation

Follow these informations, other-

wise, you may not be able to

enjoy 3D effects.

When watching 3D images under

a fluorescent lamp (50Hz/60Hz)

or 3 wavelength lamp, you may

notice a small amount of screen

flickering. If so, dim the light or

turn the lamp off.

If you change the channel or input

mode when watching 3D, 3D

glasses are turned off, and the

screen could be displayed abnor-

mally. After a while, 3D glasses

are automatically turned off.

If the TV emitter becomes discon-

nected due to either a change in

the viewing angle or distance, the

3D glasses turn off automatically

after 10 seconds. If this occurs, the

red LED blinks three times.

3D glasses may not work prop-

erly due to noise interference from

other electric devices such as a

PDP or LCD TV or direct Sunlight

under specific conditions.

Be sure to stay within the viewing

angle and optimum TV viewing dis-

tance when watching 3D pictures.

Turning on the 3D glasses

1 Press the power button.

– The green LED glows for 2 sec-

onds.

Turning oﬀ the 3D glasses

1 Press and hold down the power

button for 2 seconds.

– The red LED is blinking one

time.

Note:

7 Turn off 3D glasses while not us-

ing. If you leave 3D glasses on,

battery lifespan is shortened.

ENGLISH

RECHARGING THE BATTERY -------------------------------------

If the red LED is blinking every three

seconds continuously, the battery

should be recharged. 3D glasses are

charged via computer or the USB

socket on the TV.

1 Connect the supplied USB cable

to the »USB« port on the glasses.

2 Connect the glasses to be re-

charged to the »USB« socket of

the television, PC or laptop with

the USB cable.

– While the battery is charging,

the LED glows orange.

Notes:

7 3 hours of charging provides

40 hours of operation.

7 If TV is in stand-by mode, the

battery may not be charged.

ENGLISH

INFORMATION ------------------------------------------------------------------------

Service information for

retailers

The product complies

with the following EU

directive:

2004/108/EC.

Environmental note

This product has been manufactured

with high quality parts and materials

which can be reused

and are suitable for

recycling.

Therefore, do not dis-

pose of the product with normal do-

mestic waste at the end of its service

life. Take it to a collection point for

the recycling of electrical and elec-

tronic equipment. This is indicated

by this symbol on the product, in the

operating manual and on the pack-

aging.

Batteries, including those which do

not contain heavy metal, may not be

disposed of with household waste.

Always dispose of used batteries

in accordance with local environmen-

tal regulations. Make enquiries about

the applicable disposal regulations

where you live.

Please consult your local authorities

to learn the nearest collection point.

Help protect the environment by

recycling used products.

Technical data

Power supply:

One 3.7V Li-Polymer battery.

Working current:

2.0 mA

Lens:

Liquid crystal

Max. signal receiving

distance:

7 m

Operating time when on:

30 hours

Working temperature:

0˚C to 40˚C

Storage temperature:

-20˚C to 60˚C

Weight:

39 gr
