GKN4582VW - GKN4582VN

Combi Fridge Freezer

EN /

58 9770 0000/AA

User manual

Contents

1. Safety and environment

instructions 5

1.1. General safety .....................5

1.1.1 HC warning ..........................7

1.1.2 For models with water

dispenser ......................................7

1.2. Intended use........................7

1.3. Child safety..........................8

1.4. Compliance with WEEE

Directive and Disposing of the

Waste Product ..............................8

1.5. Compliance with RoHS

Directive........................................8

1.6. Package information...........8

2. Your Refrigerator 9

3. Installation 10

3.1 Appropriate installation

location .......................................10

3.2 Installing the plastic

wedges........................................11

3.3 Electrical connection.........11

4. Preparation 13

4.1 Things to be done for energy

saving..........................................13

4.2 Initial use ...........................14

5. Using your appliance 16

5.1 Thermostat setting button 16

5.2 Defrost ...............................17

5.3 Open door warning............18

5.4 Recommendations for

freshfood compartment .............18

6 . Maintenance and cleaning 19

6.1 Avoiding bad odours..........19

6.2 Protecting the plastic

surfaces .....................................20

7. Troubleshooting 21

SUPPLIER’S NAME MODEL IDENTIFIER (*)

INFORMATION

The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

Please read these instructions first before using your appliance

Thank you for choosing a Grundig appliance.

Please take some time to read this user manual before using your

appliance, to ensure you know how to safely operate the controls

and functions.

Carefully follow all unpacking and installation instructions to

ensure the appliance is correctly connected and fitted prior to use.

Please write your product model and serial number on the last

page of this user manual, and store in a safe location close to the

appliance for easy future reference.

This user manual may also be applicable for several other models.

Differences between models will be listed.

If you have any questions or concerns, please call our contact

centre or find help and information online at www.grundig.co.uk

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful

usage tips.

AWarning against dangerous

conditions for life and property.

BWarning against electric voltage.

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations.

1. Safety and environment instructions

This section provides the safety

instructions necessary to

prevent the risk of injury and

material damage. Failure to

observe these instructions will

invalidate all types of product

warranty.

Intended use

WARNING:

Keep ventilation

openings, in the

appliance enclosure or

in the built-instructure,

clear of obstruction.

WARNING:

Do not use mechanical

devices or other

means to accelerate

the defrosting process,

other than those

recommended by the

manufacturer.

AWARNING:

Do not damage the

refrigerant circuit.

WARNING:

Do not use electrical

appliances inside

the food storage

compartments of the

appliance, unless

they are of the type

recommended by the

manufacturer.

This appliance is intended to be

used in household and similar

applications such as

– staff kitchen areas in shops,

offices and other working

environments;

– farm houses and by clients

in hotels, motels and other

residential type environments;

– bed and breakfast type

environments;

– catering and similar non-retail

applications.

1.1. General safety

• This product should not

be used by persons with

physical, sensory and mental

disabilities, without sufficient

knowledge and experience

or by children. The device

can only be used by such

persons under supervision

and instruction of a person

responsible for their safety.

Children should not be

allowed to play with this

device.

• In case of malfunction,

unplug the device.

• After unplugging, wait at

least 5 minutes before

plugging in again.

• Unplug the product when not

in use.

• Do not touch the plug with

wet hands! Do not pull the

cable to plug off, always hold

the plug.

• Do not plug in the refrigerator

if the socket is loose.

• Unplug the product during

installation, maintenance,

cleaning and repair.

• If the product will not be

used for a while, unplug the

product and remove any food

inside.

• Do not use the product when

the compartment with circuit

cards located on the upper

back part of the product

(electrical card box cover) (1)

is open.

• Do not use steam or steamed

cleaning materials for

cleaning the refrigerator and

melting the ice inside. Steam

may contact the electrified

areas and cause short circuit

or electric shock!

• Do not wash the product by

spraying or pouring water on

it! Danger of electric shock!

• In case of malfunction, do not

use the product, as it may

cause electric shock. Contact

the authorised service before

doing anything.

• Plug the product into an

earthed socket. Earthing

must be done by a qualified

electrician.

• If the product has LED

type lighting, contact the

authorised service for

replacing or in case of any

problem.

• Do not touch frozen food with

wet hands! It may adhere to

your hands!

• Do not place liquids in bottles

and cans into the freezer

compartment. They may

explode.

• Place liquids in upright

position after tightly closing

the lid.

• Do not spray flammable

substances near the product,

as it may burn or explode.

• Do not keep flammable

materials and products with

flammable gas (sprays, etc.)

in the refrigerator.

• Do not place containers

holding liquids on top of the

product. Splashing water on

an electrified part may cause

electric shock and risk of fire.

• Exposing the product to rain,

snow, sunlight and wind

will cause electrical danger.

When relocating the product,

do not pull by holding the

door handle. The handle may

come off.

• Take care to avoid trapping

any part of your hands or

body in any of the moving

parts inside the product.

• Do not step or lean on the

door, drawers and similar

parts of the refrigerator. This

will cause the product to fall

down and cause damage to

the parts.

• Take care not to trap the

power cable.

1.1.1 HC warning

If the product comprises a

cooling system using R600a

gas, take care to avoid

damaging the cooling system

and its pipe while using and

moving the product. This gas

is flammable. If the cooling

system is damaged, keep the

product away from sources

of fire and ventilate the room

immediately.

The label on the inner

left side indicates the

type of gas used in the

product.

1.1.2 For models with

water dispenser

• Pressure for cold water inlet

shall be maximum 90 psi (620

kPa). If your water pressure

exceeds 80 psi (550 kPa), use

a pressure limiting valve in

your mains system. If you

do not know how to check

your water pressure, ask for

the help of a professional

plumber.

• If there is risk of water

hammer effect in your

installation, always

use a water hammer

prevention equipment in

your installation. Consult

Professional plumbers if you

are not sure that there is no

water hammer effect in your

installation.

• Do not install on the hot

water inlet. Take precautions

against of the risk of

freezing of the hoses. Water

temperature operating

interval shall be 33°F (0.6°C)

minimum and 100°F (38°C)

maximum.

• Use drinking water only.

1.2. Intended use

• This product is designed for

home use. It is not intended

for commercial use.

• The product should be used

to store food and beverages

only.

• Do not keep sensitive

products requiring controlled

temperatures (vaccines,

heat sensitive medication,

medical supplies, etc.) in the

refrigerator.

• The manufacturer assumes

no responsibility for any

damage due to misuse or

mishandling.

• Original spare parts will

be provided for 10 years,

following the product

purchasing date.

1.3. Child safety

• Keep packaging materials

out of children’s reach.

• Do not allow the children to

play with the product.

• If the product’s door

comprises a lock, keep the

key out of children’s reach.

1.4. Compliance with WEEE

Directive and Disposing

of the Waste Product

This product complies

with EU WEEE Directive

(2012/19/EU). This product

bears a classification symbol for

waste electrical and electronic

equipment (WEEE).

This product has been

manufactured with

high quality parts and

materials which can be

reused and are

suitable for recycling.

Do not dispose of the waste

product with normal domestic

and other wastes at the end of

its service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment. Please

consult your local authorities to

learn about these collection

centers.

1.5. Compliance with

RoHS Directive

• This product complies with

EU WEEE Directive (2011/65/

EU). It does not contain

harmful and prohibited

materials specified in the

Directive.

1.6. Package information

Packaging materials of the

product are manufactured

from recyclable materials in

accordance with our National

Environment Regulations. Do

not dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by

the local authorities.

2. Your Refrigerator

Figures in this user manual are schematic and may not

match the product exactly. If the subject parts are not

included in the product you have purchased, then those

parts are valid for other models.

13*

1. Temperature setting control

2. Cabinet shelves

3. Defrost water collection chan-

nel

4. Salad crisper

5. Freezer fan

6. Frozen food storage drawers

7. Adjustable feet

8. Dairy compartment

9. Egg tray

10. Door shelves

11. Fridge compartment

12. Freezer compartment

13. Wine cellar

* May not be available in all models

3. Installation

To make the product ready

for use, make sure that the

electricity installation is

appropriate before calling the

Authorised Service Agent. If

not, call a qualified electrician

to have any necessary

arrangements carried out.

Preparation of the

location and electrical

installation at the

place of installation

is under customer's

responsibility.

Product must not be

plugged in during

installation. Otherwise,

there is the risk of

death or serious injury!

WARNING:

Manufacturer shall

not be held liable for

damages that may

arise from procedures

carried out by

unauthorised persons.

WARNING: Prior to

installation, visually

check if the product has

any defects on it. If so,

do not have it installed.

Damaged products

cause risks for your

safety.

Make sure that the

power cable is not

pinched or crushed

while pushing the

product into its place

after installation or

cleaning procedures.

3.1 Appropriate

installation location

• Choose a place at where

you can access the product

comfortably.

• Install the product at least 30

cm away from heat sources

such as hobs, ovens, heater

cores and stoves and at least

5 cm away from electrical

ovens. Product must not be

subjected to direct sun light

and kept in humid places

after installation.

• Appropriate air ventilation

must be provided around your

product in order to achieve

an efficient operation. If

the product is to be placed

in a recess in the wall, pay

attention to leave at least 5

cm distance with the ceiling

and side walls.

• Do not place the product on

materials such as rugs or

carpets.

• Place the product on an even

floor surface to prevent jolts.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Grundig Gefrierschrank Handbücher

Grundig

Grundig GKNI 15720 Bedienungsanleitung

Grundig

Grundig GFN 33810 W Bedienungsanleitung

Grundig

Grundig GFRN 66820 Bedienungsanleitung

Grundig

Grundig GFNEP5686PZ Bedienungsanleitung

Grundig

Grundig GKN 16820 W Bedienungsanleitung

Grundig

Grundig GFNI12430N Bedienungsanleitung

Grundig

Grundig GFN 13840 XN Bedienungsanleitung

Grundig

Grundig GKN16220DZ Bedienungsanleitung

Grundig

Grundig GKN4582VPZ Bedienungsanleitung

Grundig

Grundig GFNE 138E20 N Bedienungsanleitung

Grundig

Grundig GFN24840N Bedienungsanleitung

Grundig

Grundig GFN 13810 W Bedienungsanleitung

Grundig

Grundig GKN 26840 XN Bedienungsanleitung

Grundig

Grundig GFPN 66820 X Bedienungsanleitung

Grundig

Grundig GFNE 8440 Bedienungsanleitung

Grundig

Grundig GFN3671N Bedienungsanleitung

Grundig

Grundig GKF15810N Bedienungsanleitung

Grundig

Grundig GFPN 66820 Bedienungsanleitung

Grundig

Grundig GKN 16222 Bedienungsanleitung

Grundig

Grundig GKNI 15720 Bedienungsanleitung

Grundig

Grundig GKN 16820 W Montageanleitung

Grundig

Grundig GFNE 8440 Bedienungsanleitung

Grundig

Grundig GFN 13840 XN Bedienungsanleitung

Grundig

Grundig GFN 13621 X Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung
