www.grundig.com

REFRIGERATOR

USER INSTRUCTIONS

GKN 16920 XP

Contents

1. Safety and environment

instructions 5

2. Your Refrigerator 11

3. Installation 12

3.1 Appropriate installation

location .......................................12

3.2 Installing the plastic

wedges........................................13

3.3 Electrical connection ........13

3.4 Illumination lamp..............13

3.5 Open door warning ...........13

4. Preparation 14

4.1 Things to be done for energy

saving..........................................14

4.2 Initial use...........................15

5. Using your refrigerator 16

5.1 Temperature Control And

Adjustment .................................16

5.2 Thermostat setting button ...16

5.3 Chiller Compartment ...........17

5.4 Freezing fresh food...............17

5.5 Recommendations for

preservation of frozen food........17

5.6 Recommendations for the

fresh food compartment ............18

6. Maintenance and cleaning 20

6.1 Avoiding bad odours..........20

6.2 Protecting the plastic

surfaces .....................................20

7. Troubleshooting 21

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants

and checked under the most meticulous quality control procedures, will

provide you an effective service

For this, we recommend you to carefully read the entire manual of your

product before using it and keep it at hand for future references.

The user manual will help you use the product in a fast and safe way.

Will help you use your appliance in a fast and safe way.

Read the manual before installing and operating your product.

Follow the instructions, especially those for safety.

Keep the manual in an easily accessible place as you may need it later.

Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information

or useful usage tips.

AWarning against

dangerous conditions

for life and property.

BWarning against

electric voltage.

Packaging materials

of the product are

manufactured from

recyclable materials

in accordance with our

National Environment

Regulations.

1. Safety and environment instructions

This section provides the safety instructions

necessary to prevent the risk of injury and material

damage. Failure to observe these instructions will

invalidate all types of product warranty.

Intended use

AWARNING:

Keep ventilation openings, in the appliance

enclosure or in the built-instructure, clear of

obstruction.

WARNING:

Do not use mechanical

devices or other means to accelerate

the defrostingprocess, other than those

recommended by the manufacturer.

AWARNING:

Do not damage the refrigerant circuit.

WARNING:

Do not use electrical appliances inside the

food storage compartments of the appliance,

unless they are of the type recommended by

the manufacturer.

This appliance is intended to be used in household

and similar applications such as

– staff kitchen areas in shops, offices and other

working environments;

– farm houses and by clients in hotels, motels and

other residential type environments;

– bed and breakfast type environments;

– catering and similar non-retail applications.

1.1. General safety

• This product should not be used by persons with

physical, sensory and mental disabilities, without

sufficient knowledge and experience or by children.

The device can only be used by such persons under

supervision and instruction of a person responsible

for their safety. Children should not be allowed to

play with this device.

• In case of malfunction, unplug the device.

• After unplugging, wait at least 5 minutes before

plugging in again.

• Unplug the product when not in use.

• Do not touch the plug with wet hands! Do not pull

the cable to plug off, always hold the plug.

• Do not plug in the refrigerator if the socket is loose.

• Unplug the product during installation,

maintenance, cleaning and repair.

• If the product will not be used for a while, unplug

the product and remove any food inside.

• Do not use the product when the compartment with

circuit cards located on the upper back part of the

product (electrical card box cover) (1) is open.

• Do not use steam or steamed cleaning materials

for cleaning the refrigerator and melting the ice

inside. Steam may contact the electrified areas and

cause short circuit or electric shock!

• Do not wash the product by spraying or pouring

water on it! Danger of electric shock!

• In case of malfunction, do not use the product, as

it may cause electric shock. Contact the authorized

service before doing anything.

• Plug the product into an earthed socket. Earthing

must be done by a qualified electrician.

• If the product has LED type lighting, contact the

authorized service for replacing or in case of any

probælem.

• Do not touch frozen food with wet hands! It may

adhere to your hands!

• Do not place liquids in bottles and cans into the

freezer compartment. They may burst out!

• Place liquids in upright position after tightly closing

the lid.

• Do not spray flammable substances near the

product, as it may burn or explode.

• Do not keep flammable materials and products

with flammable gas (sprays, etc.) in the

refrigerator.

• Do not place containers holding liquids on top of

the product. Splashing water on an electrified part

may cause electric shock and risk of fire.

• Exposing the product to rain, snow, sunlight and

wind will cause electrical danger. When relocating

the product, do not pull by holding the door handle.

The handle may come off.

• Take care to avoid trapping any part of your hands

or body in any of the moving parts inside the

product.

• Do not step or lean on the door, drawers and

similar parts of the refrigerator. This will cause

the product to fall down and cause damage to the

parts.

• Take care not to trap the power cable.

1.1.1 HC warning

If the product comprises a cooling system using

R600a gas, take care to avoid damaging the cooling

system and its pipe while using and moving the

product. This gas is flammable. If the cooling system

is damaged, keep the product away from sources of

fire and ventilate the room immediately.

CThe label on the inner left side indicates the

type of gas used in the product.

1.1.2 For models with water dispenser

• Pressure for cold water inlet shall be maximum

90 psi (6.2 bar). If your water pressure exceeds

80 psi (5.5 bar), use a pressure limiting valve in

your mains system. If you do not know how to

check your water pressure, ask for the help of a

professional plumber.

• If there is risk of water hammer effect in your

installation, always use a water hammer

prevention equipment in your installation. Consult

Professional plumbers if you are not sure that there

is no water hammer effect in your installation.

• Do not install on the hot water inlet. Take

precautions against of the risk of freezing of the

hoses. Water temperature operating interval

shall be 33°F (0.6°C) minimum and 100°F (38°C)

maximum.

• Use drinking water only.

1.2. Intended use

• This product is designed for home use. It is not

intended for commercial use.

• The product should be used to store food and

beverages only.

• Do not keep sensitive products requiring controlled

temperatures (vaccines, heat sensitive medication,

medical supplies, etc.) in the refrigerator.

• The manufacturer assumes no responsibility for

any damage due to misuse or mishandling.

• Original spare parts will be provided for 10 years,

following the product purchasing date.

1.3. Child safety

• Keep packaging materials out of children’s reach.

• Do not allow the children to play with the product.

• If the product’s door comprises a lock, keep the key

out of children’s reach.

1.4. Compliance with WEEE Directive and Disposing of the Waste

Product

This product complies with EU WEEE Directive (2012/19/EU). This

product bears a classification symbol for waste electrical and electronic

equipment (WEEE).

This product has been manufactured with high quality parts

and materials which can be reused and are suitable for

recycling. Do not dispose of the waste product with normal

domestic and other wastes at the end of its service life. Take it

to the collection center for the recycling of electrical and

electronic equipment. Please consult your local authorities to

learn about these collection centers.

1.5. Compliance with RoHS Directive

• This product complies with EU WEEE Directive (2011/65/EU). It

does not contain harmful and prohibited materials specified in

the Directive.

1.6. Package information

Packaging materials of the product are manufactured from recyclable

materials in accordance with our National Environment Regulations.

Do not dispose of the packaging materials together with the domestic

or other wastes. Take them to the packaging material collection points

designated by the local authorities.
